DG202AK/883B

Description
SPST, 4 Func, 1 Channel, CMOS, CDIP16,
CategoryAnalog mixed-signal IC    The signal circuit
File Size792KB,5 Pages
ManufacturerRochester Electronics
Websitehttps://www.rocelec.com/
Related ProductsFound7parts with similar functions to DG202AK/883B
Download Datasheet Parametric Compare View All

DG202AK/883B Overview

SPST, 4 Func, 1 Channel, CMOS, CDIP16,

DG202AK/883B Parametric

Parameter NameAttribute value
package instruction,
Reach Compliance Codeunknow
Analog Integrated Circuits - Other TypesSPST
JESD-30 codeR-GDIP-T16
Nominal Negative Supply Voltage (Vsup)-15 V
Number of channels1
Number of functions4
Number of terminals16
Nominal off-state isolation70 dB
Maximum on-state resistance (Ron)175 Ω
Maximum operating temperature125 °C
Minimum operating temperature-55 °C
Package body materialCERAMIC, GLASS-SEALED
Package shapeRECTANGULAR
Package formIN-LINE
Certification statusNot Qualified
Nominal supply voltage (Vsup)15 V
surface mountNO
Maximum disconnect time450 ns
Maximum connection time600 ns
technologyCMOS
Temperature levelMILITARY
Terminal formTHROUGH-HOLE
Terminal locationDUAL
Base Number Matches1
