AG240128B ( 240 DOTS X 128 DOTS )
FEATURES
BUILT-IN CONTROLLER (T6963C OR EQUIVALENT)
+5 V POWER SUPPLY
1/128 DUTY CYCLE
8-BIT PARALLEL INTERFACE
4.2V LED FORWARD VOLTAGE
MECHANICAL DATA
ITEM
Module Size (W x H x T)
Viewing Area ( W x H )
Active Area ( W x H )
Dot Size ( W x H )
Dot Pitch ( W x H )
DIMENSIONS
144 x 104 x 10.3 ( 15.1 LED )
114.0 x 64.0
107.95 x 57.55
0.40 x 0.40
0.45 x 0.45
UNIT
mm
mm
mm
mm
mm
INTERFACE PIN CONNECTIONS
NO.
1
2
3
4
5
6
7
8
9
10
11~18
19
20
ABSOLUTE MAXIMUM RATINGS
ITEM
Supply Voltage For Logic
Supply Voltage For LCD Drive
Input Voltage
SYMBOL LEVEL
V
SS
V
DD
V
O
C/D
/RD
/WR
DB0~DB7
/CE
/RST
Vout
MD
FS
NC
0V
5V
FUNCTION
Power Supply Ground
Power Supply Voltage
Contrast Adjustment Voltage
H : Data, L : Instruction Code
Read
Write
Data Bus Line
Enable Signal
Reset Signal
Power Supply Voltage For LCD
H : 32 / L : 40 Select Of Columns
H : 6*8 , L : 8*8 Select Of Columns
No Connection
SYMBOL
V
DD
-V
SS
V
DD
-V
o
V
I
MIN.
0
0
Vss
TYP.
-
-
-
MAX.
7
28
V
DD
UNIT
V
V
V
-
H/L
L
L
H/L
L
L
ELECTRICAL CHARACTERISTICS
ITEM
Supply Voltage For Logic
LCD Supply Voltage
Supply Current
Input
Voltage
Output
Voltage
"HIGH" Level
"LOW" Level
"HIGH" Level
"LOW" Level
SYMBOL CONDITION
V
DD
-V
SS
V
DD
-V
o
I
DD
V
IH
V
IL
V
OH
V
OL
MIN.
4.5
16.9
-
2.2
-
2.4
-
TYP.
5
18
15
-
-
-
-
MAX.
5.5
19.2
24
VDD
0.6
-
0.4
UNIT
V
V
mA
V
V
V
V
-
V
DD
=5V Ta=25
V
DD
=5V
-
H/L
H/L
-
-
-
-
-
EXTERNAL DIMENSIONS
144.0 0.5
5.0
15.0
134.0
114.0
107.95
10.3(LED=15.1)
H
9.3
17.0
3.5
5.2(LED=10.0)
0.05
45.5
0.40
104.0 0.5
97.0
79.4
64.0
57.55
BL1
0.05
BL2
LH-3
0.40
SCALE 10/1
20
1
6- 3.5
(Paid 6.0)
69.0
138.0
3.0
3.5
15.3
23.0
P2.54x19=48.26
59.0
3.0
2.5
