LCD MODULES
SG320240B ( 320 DOTS X 240 DOTS )
FEATURES
RECOMMENDED CONTROLLER
(HD64646/MSM6225/SED1335)
+5 V POWER SUPPLY
1/240 DUTY CYCLE
EDGE LIGHTING TYPE CCFL BACKLIGHT
MECHANICAL DATA
ITEM
Module Size (W x H x T)
Viewing Area ( W x H )
Active Area ( W x H )
Dot Size ( W x H )
Dot Pitch ( W x H )
DIMENSIONS
160.0 x 109.0 x 11.0
122 .0 x 92.0
115.19 x 86.39
0.35 x 0.35
0.36 x 0.36
UNIT
mm
mm
mm
mm
mm
INTERFACE PIN CONNECTIONS
NO.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
ABSOLUTE MAXIMUM RATINGS
ITEM
Supply Voltage For Logic
Supply Voltage For LCD Drive
Input Voltage
SYMBOL
DB0
DB1
DB2
DB3
/DISPOFF
FLM
NC
CL1
CL2
V
DD
V
SS
V
EE
V
O
FGND
LEVEL
H/L
H/L
H/L
H/L
H/L
H
Data Bit0
Data Bit1
Data Bit2
Data Bit3
FUNCTION
SYMBOL
V
DD
-V
SS
V
DD
-V
o
V
I
MIN.
0
0
Vss
TYP.
-
-
-
MAX.
7
30
V
DD
UNIT
V
V
V
Display OFF . Active LOW .
Frame Start Signal
No Connection .
ELECTRICAL CHARACTERISTICS
ITEM
Supply Voltage For Logic
LCD Supply Voltage
Supply Current
Input
Voltage
Output
Voltage
"HIGH" Level
"LOW" Level
"HIGH" Level
"LOW" Level
SYMBOL
V
DD
-V
SS
V
DD
-V
o
I
DD
V
IH
V
IL
V
OH
V
OL
CONDITION
-
V
DD
=5V Ta=25 C
V
DD
=5V
o
MIN.
4.5
22.4
-
2.2
-
2.4
-
TYP.
5
23.5
16
-
-
-
-
MAX.
5.5
24.3
25
VDD
0.6
-
0.4
UNIT
V
V
mA
V
V
V
V
-
H
H
5V
0V
L
L
Common Driver Data Shift Signal
Clock Pulse For Segment Shift Register
Power Supply Voltage
Power Supply Ground
Power Supply Voltage For LCD
Contrast Adjustment Voltage
Frame Ground
-
-
-
-
-
-
-
EXTERNAL DIMENSIONS
