DA100 SERIES
Transformers for Digital Audio Data Transmission
SELECTION GUIDE
Order Code
DA101
mH
1:1
1.00 - 1.59
H
0.22
Vµs
15
dB
46.80
dB
52.10
FEATURES
s
Compatible with Leading Chip Sets
s
2kVrms Isolation
s
Standard Pinout
s
Surface Mount Option
s
CECC00802 IR Reflow Profile
s
UL 94V-0 Package Materials
s
Low Profile
s
Suitable for Both 75 & 110Ω Circuits
DESCRIPTION
The Digital Audio Range of transformers is
designed to improve the balance of
transmitter and receiver circuitry in hi-fi
equipment, video games and other
applications requiring high-performance
digital audio transmission. Compliant with
AES/EBU recommendations for the digital
audio interface offering optimised shunt
capacitance between primary and secondary
windings. Capable of operating over the
audio data rate frequency range, providing
isolation from 60Hz noise.
DA102
1:1
2.00 - 3.00
0.39
20
40.40
49.70
DIP
DA103
1:1
4.00 - 5.96
0.91
28
36.30
46.40
DA101M/R
1:1
1.00 - 1.59
0.22
15
46.80
52.10
DA102M/R
1:1
2.00 - 3.00
0.39
20
40.40
49.70
SM
DA103M/R
1:1
4.00 - 5.96
0.91
28
36.30
46.40
ABSOLUTE MAXIMUM RATINGS
Operating free air temperature range
Storage temperature range
Specifications typical at T
A
=25°C
For tape and reel packaging details refer to datasheet NDC AN002.
0°C to 70°C
–40°C to 125°C
www.dc-dc.com
DA100 SERIES
Transformers for Digital Audio Data Transmission
MECHANICAL DIMENSIONS
6 Pin DIP
9.52
Top View
2.54
1
8.89
1
3
1
6
DA101
XYYWW
4
+0.15
Ø1.20 –0.00
6.35
3.44±0.50
0.30
0.20
10.16
5.08
0.63
0.53
6 Pin SM
12.70
9.52
Top View
1.60
1
8.89
2
3
1
1
6
5
4
1.00
11.50
2.54
DA103M
XYYWW
6.35
0.30
0.20
0.90
2.54
0.63
0.53
All dimensions in mm XX.XX ±0.25mm. All pins on a 2.54mm pitch and within ±0.25mm of true position.
C&D Technologies (NCL) Limited reserve the right to alter or improve the
specification, internal design or manufacturing process at any time, without
notice. Please check with your supplier or visit our web site to ensure that
you have the current and complete specification for your product before use.
© C&D Technologies (NCL) Limited 2000
NMP DA100.3
No part of this publication may be copied, transmitted or stored in a
retrieval system or reproduced in any way including, but not limited to,
photography, photocopy, magnetic or other recording means, without prior
written permission from C&D Technologies (NCL) Limited.
Instructions for use are available from www.dc-dc.com
