LM224-LM324 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > semiconductor> Analog mixed-signal IC> LM224-LM324

LM224-LM324: DescriptionQUAD OP-AMP, 7000 uV OFFSET-MAX, 1.3 MHz BAND WIDTH, PDSO14; Categorysemiconductor Analog mixed-signal IC; File Size134KB，14 Pages; ManufacturerSTMicroelectronics; Websitehttp://www.st.com/

Download Datasheet Parametric Compare View All

LM224-LM324 Overview

QUAD OP-AMP, 7000 uV OFFSET-MAX, 1.3 MHz BAND WIDTH, PDSO14

LM224-LM324 Parametric

Parameter Name	Attribute value
Number of functions	4
Number of terminals	14
Maximum supply/operating voltage	32 V
Maximum operating temperature	105 Cel
Minimum operating temperature	-40 Cel
Rated supply voltage	5 V
Rated bandwidth	1.3 kHz
Rated rotation rate	0.4000 V/us
Maximum input offset voltage	7000 mV
Processing package description	ROHS COMPLIANT, MICRO, PLASTIC, SOP-14
Lead-free	Yes
EU RoHS regulations	Yes
state	ACTIVE
Craftsmanship	BIPOLAR
packaging shape	RECTANGULAR
Package Size	SMALL OUTLINE
surface mount	Yes
Terminal form	GULL WING
Terminal spacing	1.27 mm
terminal coating	NICKEL PALLADIUM GOLD
Terminal location	DUAL
Packaging Materials	PLASTIC/EPOXY
Temperature level	INDUSTRIAL
Amplifier type	OP-AMP
Rated common mode rejection ratio	80 dB
Maximum input bias current IIB	0.3000 uA

Preview

Download Datasheet

View All

LM124

LM224 - LM324

LOW POWER QUAD OPERATIONAL AMPLIFIERS

WIDE GAIN BANDWIDTH : 1.3MHz

INPUT COMMON-MODE VOLTAGE RANGE

INCLUDES GROUND

LARGE VOLTAGE GAIN : 100dB

VERY LOW SUPPLY CURRENT/AMPLI : 375µA

LOW INPUT BIAS CURRENT : 20nA

LOW INPUT OFFSET VOLTAGE : 5mV max.

(for more accurate applications, use the equivalent parts

LM124A-LM224A-LM324A which feature 3mV max)

DIP14

(Plastic Package)

SO14

(Plastic Micropackage)

LOW INPUT OFFSET CURRENT : 2nA

WIDE POWER SUPPLY RANGE :

SINGLE SUPPLY : +3V TO +30V

DUAL SUPPLIES :

±1.5V

±15V

TSSOP14

(Thin Shrink Small Outline Package)

DESCRIPTION

These circuits consist of four independent, high

gain, internally frequency compensated operational

amplifiers . They operate from a single power supply

over a wide range of voltages. Operation from split

power supplies is also possible and the low power

supply current drain is independent of the magni-

tude of the power supply voltage.

PIN CONNECTIONS

(top view)

ORDER CODES

Part

Number

LM124

LM224

LM324

Temperature

Range

-55 C, +125 C

-40

C, +105

0 C, +70 C

Package

•

Example :

LM224N

Output 1 1

Inve rting Input 1 2

Non-inve rting Input 1 3

Output 4

Inve rting Input 4

Non-inve rting Input 4

Non-inve rting Input 3

Inve rting Input 3

Output 3

Non-inve rting Input 2

Inve rting Input 2

Output 2

June 1999

1/14

LM224-LM324 Related Products

	LM224-LM324	LM324P	LM224P	LM124P
Description	QUAD OP-AMP, 7000 uV OFFSET-MAX, 1.3 MHz BAND WIDTH, PDSO14	QUAD OP-AMP, 7000 uV OFFSET-MAX, 1.3 MHz BAND WIDTH, PDSO14	QUAD OP-AMP, 7000 uV OFFSET-MAX, 1.3 MHz BAND WIDTH, PDSO14	QUAD OP-AMP, 7000 uV OFFSET-MAX, 1.3 MHz BAND WIDTH, PDSO14
Number of functions	4	4	4	4
Number of terminals	14	14	14	14
Maximum operating temperature	105 Cel	70 °C	105 °C	125 °C
Minimum operating temperature	-40 Cel	-	-40 °C	-55 °C
Maximum input offset voltage	7000 mV	9000 µV	7000 µV	7000 µV
surface mount	Yes	YES	YES	YES
Terminal form	GULL WING	GULL WING	GULL WING	GULL WING
Terminal location	DUAL	DUAL	DUAL	DUAL
Temperature level	INDUSTRIAL	COMMERCIAL	INDUSTRIAL	MILITARY
Amplifier type	OP-AMP	OPERATIONAL AMPLIFIER	OPERATIONAL AMPLIFIER	OPERATIONAL AMPLIFIER
Is it Rohs certified?	-	incompatible	incompatible	incompatible
Parts packaging code	-	TSSOP	TSSOP	TSSOP
package instruction	-	TSSOP, TSSOP14,.25	TSSOP-14	TSSOP-14
Contacts	-	14	14	14
Reach Compliance Code	-	_compli	_compli	_compli
ECCN code	-	EAR99	EAR99	EAR99
Architecture	-	VOLTAGE-FEEDBACK	VOLTAGE-FEEDBACK	VOLTAGE-FEEDBACK
Maximum average bias current (IIB)	-	0.3 µA	0.3 µA	0.3 µA
Maximum bias current (IIB) at 25C	-	0.15 µA	0.15 µA	0.15 µA
Nominal Common Mode Rejection Ratio	-	80 dB	80 dB	80 dB
frequency compensation	-	YES	YES	YES
JESD-30 code	-	R-PDSO-G14	R-PDSO-G14	R-PDSO-G14
JESD-609 code	-	e0	e0	e0
length	-	5 mm	5 mm	5 mm
low-dissonance	-	NO	NO	NO
micropower	-	YES	YES	YES
Package body material	-	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY
encapsulated code	-	TSSOP	TSSOP	TSSOP
Encapsulate equivalent code	-	TSSOP14,.25	TSSOP14,.25	TSSOP14,.25
Package shape	-	RECTANGULAR	RECTANGULAR	RECTANGULAR
Package form	-	SMALL OUTLINE, THIN PROFILE, SHRINK PITCH	SMALL OUTLINE, THIN PROFILE, SHRINK PITCH	SMALL OUTLINE, THIN PROFILE, SHRINK PITCH
power supply	-	5/30 V	5/30 V	5/30 V
Certification status	-	Not Qualified	Not Qualified	Not Qualified
Maximum seat height	-	1.2 mm	1.2 mm	1.2 mm
Nominal slew rate	-	0.4 V/us	0.4 V/us	0.4 V/us
Maximum slew rate	-	3 mA	3 mA	3 mA
Supply voltage upper limit	-	32 V	32 V	32 V
Nominal supply voltage (Vsup)	-	5 V	5 V	5 V
technology	-	BIPOLAR	BIPOLAR	BIPOLAR
Terminal surface	-	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)
Terminal pitch	-	0.65 mm	0.65 mm	0.65 mm
Nominal Uniform Gain Bandwidth	-	1300 kHz	1300 kHz	1300 kHz
Minimum voltage gain	-	25000	25000	25000
width	-	4.4 mm	4.4 mm	4.4 mm
