IBEK
€
www.ibek.ch
3 Watt
DC-DC-Converter
Family IPS3
Single, double, dual & triple outputs
Input to output isolated
Dual & triple outputs: Output1 to output2(3) isolated
•
•
•
•
•
•
•
•
•
Ultra wide 1:4 input voltage ranges
Shutdown input
Very high efficiency up to 83%
High reliability
Continuous no-load and short-circuit proof
Extended ambient temperature range -40…+85‚C
No derating
Made in Switzerland, accordingly ISO 9001:2000
2 years warranty
Standard Types
2
Input voltage
VDC
Output 1
VDC mA
5
12
15
€ 5
€ 12
€ 15
5
5
5
12
15
5
5
500
250
200
€ 250
€ 125
€ 100
250
250
250
125
100
300
300
Output 2
VDC mA
-
-
-
-
-
-
5
12
15
12
15
-
-
-
-
-
-
250
125
100
125
100
Electromagnetic emission EN 55022 < B
Conducted and radiated emissions
(Triple outputs upon request)
5 IPS
24 IPS
48 IPS
No load input current
25
5
3
mA typ.
Input current in shutdown condition 1.3 mA typ.
Switching frequency
130 kHz typ.
Output voltage accuracy
€ 2% max.
Static line regulation
€ 15 mV typ.
Static load regulation FL to • L
0…2%; 5 VDC outputs 0…5% typ.
Output voltage noise (20 MHz BW) 100 mVpp typ.
Efficiency
79% to 83% typ.
I/O Electric strength test voltage
1500 VDC
O/O Electric strength test voltage
700 VDC
Coupling capacitance
300 pF
Shutdown input (SD)
Apply -0.3…+1.35 VDC / 100…200
A
1
to
shut down (switch off) the output voltage(s).
Normal operation with open pin.
Ambient temperature range
-T: -25…+71ƒC; -S: -40…+85ƒC
Case temperature range
-T: -25…+95ƒC; -S: -40…+105ƒC
Storage temperature range
-T: -55…+105ƒC; -S: -55…+105ƒC
Case material
Non-conductive plastic, UL94 V-0 rated
MTBF, GB @ 40ƒC case
2.200.000 hours
(MIL-HDBK-217F, Notice 2)
1
Single output
xx IPS3-05-T
RoHS
4.75…16
xx IPS3-12-T
RoHS
(nominal 5)
xx IPS3-15-T
RoHS
Double output
3
9…36
xx IPS3-0505-T
RoHS
(nominal 24)
xx IPS3-1212-T
RoHS
45 V for 10 ms
xx IPS3-1515-T
RoHS
repetition rate 10 s
Dual output
xx IPS3-05-05-T
RoHS
18…75
xx IPS3-05-12-T
RoHS
(nominal 48)
xx IPS3-05-15-T
RoHS
xx IPS3-12-12-T
RoHS
xx IPS3-15-15-T
RoHS
Triple output
4
xx IPS3-05-1212-T
RoHS
xx IPS3-05-1515-T
RoHS
2
€ 12 € 62
€ 15 € 50
To complete type number replace "xx" by the required nominal input
voltage, e.g. 5 IPS3-05-12-T
RoHS
.
3
Double outputs should have symmetrical load conditions to comply
with the specifications listed on the left side.
4
Not available with input voltage range 4.75…16 VDC.
Extended temperature range -S is available for all types.
Replace -T by -S on type number, e.g. 24 IPS3-05-1515-S
RoHS
.
Modifications and customs are available upon request.
Pin
1
2
9
10
11
12
13
15
16
17
20
23
24
Single
output
+Vi
+Vi
No Pin
No Pin
No Pin
-Go
+Vo
No Pin
No Pin
No Pin
SD
-Gi
-Gi
Pin Configuration
Double
Dual
output
output
+Vi
+Vi
+Vi
+Vi
No Pin
-Go1
Go
No Pin
Go
No Pin
No Pin
+Vo1
-Vo
+Vo2
+Vo
No Pin
No Pin
-Go2
No Pin
No Pin
SD
SD
-Gi
-Gi
-Gi
-Gi
Triple
output
+Vi
+Vi
No Pin
Go1
No Pin
Vo1
+Vo2
Go2
No Pin
-Vo2
SD
-Gi
-Gi
5 IPS3-types: -0.3…+0.6 VDC / 500…700
A
Dimensions in mm (inches)
Specifications subject to change without notice
15.12.2008
More power with IBEK
€
!
Page 6
