Surface Mountable Inductors
Actual Size
Physical Parameters
Inches
A
0.490 to 0.520
B
0.230 to 0.250
C
0.210 to 0.230
D
0.050 Min.
E
0.055 to 0.095
F
0.330 (Ref. only)
G
0.120 (Ref. only)
Weight Max.
(Grams) 1.5
Millimeters
12.44 to 13.21
5.84 to 6.35
5.33 to 5.84
1.27 Min.
1.397 to 2.413
8.38 (Ref. only)
3.04 (Ref. only)
Mechanical Configuration
Units are encapsulated in an
epoxy molded surface mount package.
Operating Temperature Range
–55°C to +125°C
Current Rating at 90°C Ambient
35°C Rise
Maximum Power Dissipation at 90°C
0.405 W
Marking
API/SMD; 5022; inductance with units and
tolerance; date code (YYWWL). Note: An R after 5022
indicates a RoHS component.
Example: 5022R-102G
API/SMD
5022R
1.0uH±2%
0542A
Packaging
Tape & reel (24mm): 13" reel, 800 pieces
max.; 7" reel not available
Made In the U.S.A.
-151J
-161J
-181J
-201J
-221J
-241J
-271J
-301J
-331J
-361J
-391J
-431J
-471J
-511J
-561J
-621J
-681J
-751J
-821J
-911J
-102J
-112J
-122J
-132J
-152J
-162J
-182J
-202J
-222J
-242J
-272J
-302J
-332J
-362J
-392J
-432J
-472J
0.15
0.16
0.18
0.20
0.22
0.24
0.27
0.30
0.33
0.36
0.39
0.43
0.47
0.51
0.56
0.62
0.68
0.75
0.82
0.91
1.00
1.10
1.20
1.30
1.50
1.60
1.80
2.00
2.20
2.40
2.70
3.00
3.30
3.60
3.90
4.30
4.70
SERIES 5022 PHENOLIC CORE
50
25.0
525
50
25.0
525
50
25.0
500
50
25.0
475
50
25.0
450
45
25.0
415
45
25.0
400
45
25.0
380
45
25.0
360
45
25.0
345
45
25.0
330
45
25.0
315
45
25.0
310
45
25.0
300
50
25.0
280
50
25.0
260
50
25.0
250
50
25.0
230
50
25.0
220
50
25.0
210
50
25.0
200
33
7.9
190
33
7.9
180
33
7.9
170
33
7.9
160
33
7.9
155
33
7.9
150
33
7.9
140
33
7.9
135
33
7.9
130
33
7.9
120
33
7.9
115
33
7.9
110
33
7.9
105
33
7.9
100
33
7.9
95
33
7.9
90
0.030
0.040
0.043
0.047
0.055
0.060
0.070
0.080
0.090
0.098
0.100
0.110
0.120
0.130
0.135
0.140
0.150
0.180
0.220
0.240
0.290
0.420
0.420
0.480
0.500
0.600
0.650
0.800
0.950
1.100
1.200
1.800
2.000
2.150
2.300
2.400
2.600
3500
3025
2915
2790
2580
2470
2285
2140
2015
1935
1915
1825
1750
1680
1645
1615
1555
1425
1300
1240
1125
930
930
875
855
780
755
675
620
575
550
455
430
415
395
390
375
Optional Tolerances: H = 3% G = 2% F = 1%
*Complete part # must include series # PLUS the dash #
For surface finish information, refer to www.delevanfinishes.com
270 Quaker Rd., East Aurora NY 14052 • Phone 716-652-3600 • Fax 716-652-4814 • E-mail: apisales@delevan.com • www.delevan.com
5/2010
F
R
ST
TE
0%
±1
H)
(µ
CE
AN
*
CT
ER
DU
MB
IN
NU
SERIES
5022R
5022
s
or
ct
du
In
NG
TI )
RA A
T (m
EN UM
RR IM
CU X
MA
CE
AN )
ST S
SI HM
RE M (O
DC MU
XI
)
MA
Hz
(M
M
MU
NI
MI
F
)
SR
Hz
(M
Y
NC
UE
EQ
FR
SH
DA
Q
M
MU
NI
MI
Surface Mountable Inductors
Actual Size
-512J
-562J
-622J
-682J
-752J
-822J
-912J
-103J
-113J
-123J
-133J
-153J
-163J
-183J
-203J
-223J
-243J
-273J
-303J
-333J
-363J
-393J
-433J
-473J
-513J
-563J
-623J
-683J
-753J
-823J
-913J
-104J
-114J
-124J
-134J
-154J
-164J
-184J
-204J
-224J
-244J
-274J
-304J
-334J
-364J
-394J
-434J
-474J
-514J
-564J
-624J
-684J
-754J
-824J
-914J
-105J
5.10
5.60
6.20
6.80
7.50
8.20
9.10
10.0
11.0
12.0
13.0
15.0
16.0
18.0
20.0
22.0
24.0
27.0
30.0
33.0
36.0
39.0
43.0
47.0
51.0
56.0
62.0
68.0
75.0
82.0
91.0
100.0
110.0
120.0
130.0
150.0
160.0
180.0
200.0
220.0
240.0
270.0
300.0
330.0
360.0
390.0
430.0
470.0
510.0
560.0
620.0
680.0
750.0
820.0
910.0
1000.0
SERIES
35
45
45
50
50
50
55
55
60
65
65
65
70
75
75
75
60
60
65
65
60
60
60
55
55
55
55
55
55
50
50
50
60
65
65
65
65
65
65
65
65
65
65
65
65
65
65
65
65
65
65
65
65
65
65
65
5022 IRON CORE
7.9
65
7.9
60
7.9
60
7.9
55
7.9
55
7.9
50
7.9
50
7.9
45
2.5
44
2.5
42
2.5
40
2.5
40
2.5
38
2.5
34
2.5
30
2.5
30
2.5
26
2.5
25
2.5
21
2.5
19
2.5
15.5
2.5
14.5
2.5
13.7
2.5
13.0
2.5
12.7
2.5
12.0
2.5
11.5
2.5
11.0
2.5
10.5
2.5
10.3
2.5
10.0
2.5
9.5
0.79
8.9
0.79
8.7
0.79
8.5
0.79
8.0
0.79
7.5
0.79
7.0
0.79
6.5
0.79
6.2
0.79
5.9
0.79
5.7
0.79
5.4
0.79
5.1
0.79
4.8
0.79
4.5
0.79
4.2
0.79
3.9
0.79
3.7
0.79
3.8
0.79
3.3
0.79
3.1
0.79
2.9
0.79
2.7
0.79
2.5
0.79
2.3
0.300
0.320
0.470
0.500
0.550
0.600
0.800
0.900
1.050
1.100
1.200
1.400
1.800
2.250
2.500
2.500
2.500
2.600
2.800
3.000
2.500
2.600
2.700
2.750
2.850
3.000
3.150
3.300
3.700
3.900
4.300
4.500
4.900
5.200
5.450
6.050
6.400
6.750
7.100
7.450
7.800
11.000
11.500
12.000
12.500
16.300
17.100
17.900
18.800
19.500
25.900
27.200
28.600
30.000
31.500
33.000
1040
1030
830
820
765
748
638
610
565
555
520
495
420
388
372
368
368
360
348
337
368
361
353
351
344
335
328
320
302
295
280
275
262
255
250
237
230
224
219
213
210
182
178
173
171
149
147
143
139
136
119
116
112
110
107
105
Optional Tolerances: H = 3% G = 2% F = 1%
*Complete part # must include series # PLUS the dash #
For surface finish information, refer to www.delevanfinishes.com
270 Quaker Rd., East Aurora NY 14052 • Phone 716-652-3600 • Fax 716-652-4814 • E-mail: apisales@delevan.com • www.delevan.com
5/2010
