SMT POWER INDUCTORS
Toroid - Tomcat Series
Height:
7.6mm Max
Footprint:
18.2mm x 15.0mm Max
Current Rating:
up to 14.4A
Inductance Range:
1.5µH to 139µH
Electrical Specifications @ 25°C — Operating Temperature -40°C to +130°C
10
Part
Number
P0395NL
P0396NL
P0397NL
P0398NL
P0395NL
P0399NL
P0396NL
P0400NL
P0397NL
P0401NL
P0398NL
P0402NL
P0399NL
P0403NL
P0400NL
P0401NL
P0403NL
P0402NL
8,9
Inductance
@ Irated
(µH)
1.5
2.4
4.2
5.8
6.1
7.6
9.7
12.1
17.0
18.0
23.1
27.0
30.6
34.8
48.5
72.0
139.1
108.0
Irated
(A)
14.40
11.20
8.20
6.80
7.20
5.70
5.60
5.40
4.10
4.40
3.40
3.54
2.85
3.00
2.70
2.20
1.50
1.77
DCR (TYP)
(mΩ)
4.41
6.54
10.47
14.94
17.60
20.99
26.20
23.24
41.90
38.15
59.70
53.21
84.00
73.89
93.00
152.60
295.60
212.80
ET
(V-µsec)
4.80
6.00
7.85
9.05
9.60
10.25
12.00
13.85
15.70
16.50
18.10
20.50
20.50
22.50
27.70
33.00
45.00
41.00
Storage
Capacity
(µJoules)
159.01
152.83
142.57
133.80
159.01
124.18
152.83
176.62
142.57
174.26
133.80
169.14
124.18
156.47
176.62
174.26
156.47
169.14
Inductance
@ 0A
DC
(µH ±20%)
2.2
3.5
5.9
7.9
9.0
10.1
14.0
18.5
23.7
27.4
31.5
40.5
40.5
50.5
74.1
109.8
202.2
161.8
100 Gauss
ET
100
(V-µsec)
1.71
2.14
2.78
3.21
3.42
3.64
4.28
4.92
5.56
5.99
6.42
7.27
7.27
8.13
9.84
11.98
16.26
14.55
1 Amp DC
H
1
(Orsted)
3.77
4.71
6.12
7.06
7.53
8.00
9.42
10.83
12.24
13.18
14.12
16.01
16.01
17.89
21.66
26.36
35.78
32.01
Connection
Parallel
Parallel
Parallel
Parallel
Series
Parallel
Series
Parallel
Series
Parallel
Series
Parallel
Series
Parallel
Series
Series
Series
Series
NOTES:
1. The reference inductance is a typical value at the AC and DC excitation listed.
2. Temperature rise is 55°C in typical buck or boost circuits at 100kHz and with the
reference ET applied to the inductor.
3. Total loss in the inductor is 634mW for a 55°C temperature rise above ambient.
4. To estimate temperature rise in a given application, determine copper and core
losses, divide by 634 and multiply by 50.
5. For the copper loss (mW), calculate I
DC
2
X R
N
.
6. For core loss (mW), using frequency (f in Hertz) and operating flux density (B in
Gauss), calculate 2.24 x 10
-10
x B
2.11
x f
1.26
.
7. For flux density (B in Gauss), calculate ET (V-µsec) for the application, divide by
ET
100
from the table, and multiply by 100.
8. Optional Tape & Reel packaging can be ordered by adding a "T" suffix to
the part number (i.e. P0395NL becomes P0395NLT). Pulse complies to indus-
try standard tape and reel specification EIA481.
9. The "NL" suffix indicates an RoHS-compliant part number. Non-NL suffixed
parts are not necessarily RoHS compliant, but are electrically and mechanically
equivalent to NL versions. If a part number does not have the "NL" suffix, but
an RoHS compliant version is required, please contact Pulse for availability.
10. The temperature of the component (ambient plus temperature rise) must be within
the stated operating temperature range.
Mechanical
.590 MAX
14,99
.370
9,40
R
Schematic
1
4
2
.600
15,24
P0XXX
Date Code
Country of Origin
1
.715 MAX
18,16
4X .060
1,52
.610
15,49
4X .175
4,45
2
1:1 ±1%
3
3
4
Suggested Pad Layout
.300 MAX
7,62
.005 MIN
0,13
.365
9,27
.005/0,13
4 SURFACES
Weight
. . . . . . . . 4.2 grams
Tape & Reel
. . . . . . 300/reel
Tube
. . . . . . . . . . . . 35/tube
Dimensions:
Inches
mm
Unless otherwise specified,
all tolerances are ± .010
0,25
USA 858 674 8100
•
Germany 49 7032 7806 0
•
Singapore 65 6287 8998
•
Shanghai
86 21 54643211 / 2
•
China 86 755 33966678
•
Taiwan 886 3 4641811
www.pulseeng.com
73
SPM2007 (11/07)
