SOLID TANTALUM ELECTROLYTIC CAPACITORS
F72
Low Profile
Conformal
coated Chip
F75
Maximum CV
Conformal
coated Chip
Compliant to the RoHS directive (2002/95/EC).
Specifications
Item
Per formance Characteristics
Category
--55 to + 125
˚C
(Rated temperature : + 85
˚C
)
Temperature Range
Capacitance Tolerance ± 20%, ± 10% (at 120Hz)
Dissipation Factor
(120Hz)
ESR (100kHz)
Refer to next page
Refer to next page
•
After 1 minute's application of rated voltage, leakage current at 20˚C is not
more than 0.01CV or 0.5µA, whichever is greater.
Leakage Current
•
After 1 minute's application of rated voltage, leakage current at 85˚C is not
more than 0.1CV or 5µA, whichever is greater.
•
After 1 minute's application of derated voltage, leakage current at 125˚C is
not more than 0.125CV or 6.3µA, whichever is greater.
Capacitance Change
by Temperature
+15% Max. (at +125
˚C
)
+10% Max. (at +85
˚C
)
--10% Max. (at --55
˚C
)
At 40
˚C
, 90 to 95% R.H., For 500 hours (No voltage applied)
Capacitance Change
• • • • • •
Refer to * 1
Dissipation Factor
• • • • • • • • • •
Initial specified value or less
Leakage Current
• • • • • • • • • • •
Initial specified value or less
At --55
˚C
/ +125
˚C
, 30 minutes each, For 5 cycles,
Capacitance Change
• • • • • •
Refer to * 1
Dissipation Factor
• • • • • • • • • •
Initial specified value or less
Leakage Currentv
• • • • • • • • • •
Initial specified value or less
10 seconds reflow at 260
˚C, 10 seconds
immersion at 260
˚C
Capacitance Change
• • • • • •
Refer to * 1
Dissipation Factor
• • • • • • • • • •
Initial specified value or less
Leakage Current
• • • • • • • • • • • •
Initial specified value or less
After application of surge in series with a 33Ω resistor at the rate of 30
seconds ON, 30 seconds OFF, for 1000 successive test cycles at 85
˚C
,
capacitors shall meet the characteristic requirements table below.
Capacitance Change
• • • • • •
Refer to * 1
Dissipation Factor
• • • • • • • • • •
Initial specified value or less
Leakage Current
• • • • • • • • • • • •
Initial specified value or less
After 2000 hours' application of rated voltage at 85
˚C
,
capacitors shall meet the characteristic requirements table below.
Capacitance Change
• • • • • •
Refer to * 1
Dissipation Factor
• • • • • • • • • •
Initial specified value or less
Leakage Current
• • • • • • • • • • • •
Initial specified value or less
After applying the pressure load of 5N
for 10±1 seconds horizontally to the
center of capacitor side body which has
no electrode and has been soldered
beforehand on a substrate, there shall be
found neither exfoliation
nor its sign at the terminal electrode.
Applications
Wireless modem
Tablet PC
e-book
SSD
Smart meter
F72
Type numbering system (Example : 10V 100µF)
1
2
3
4
5
6
7
8
9
10
11
12 13 14
Damp Heat
(Steady State)
Temperature Cycles
F 7 2 1 A 1 0 7 M R
AQ 2
Single face electrode
Taping code(Refer to page 333 for details)
Case code
Capacitance tolerance
Rated capacitance Rated voltage
Series
Resistance to
Soldering Heat
Surge
∗
Drawing
H
A
B
D
L
W
Endurance
∗
Solder electrode
Dimensions
Case code
R
M
L
W
(mm)
H
A
B
(D)
(6.2)
(6.2)
Shear Test
7.2
±
0.3 6.0
±
0.3 1.2
±
0.3 1.3
±
0.4 3.8
±
0.6
7.2
±
0.3 6.0
±
0.3
2.0MAX.
1.3
±
0.4 3.8
±
0.6
5N (0.51kg
•
f)
For 10
±
1 seconds
D dimension only for reference
F75
Type numbering system (Example : 16V 150µF)
1
2
3
4
5
6
7
8
9
10
11
12 13 14
F 7 5 1 C 1 5 7 M D
AQ 2
Single face electrode
Taping code(Refer to page 333 for details)
Case code
Capacitance tolerance
Rated capacitance Rated voltage
Series
Keeping a capacitor surface-mounted on a substrate upside
down and supporting the substrate at both of the opposite
bottom points 45mm apart from the center of capacitor,
the pressure strength is applied with
20
R230
Terminal Strength a specified jig at the center of
substrate so that the substrate may
bend by 1mm as illustrated. Then,
there shall be found no remarkable
45
45
abnormality on the capacitor terminals.
∗
As for the surge voltage, refer to page 332 for details.
Drawing
H
A
B
D
L
W
Dimensions
Case code
U
C
D
R
L
W
H
A
B
7.1 ± 0.3 3.2 ± 0.3 2.0MAX. 1.3 ± 0.3 3.6 ± 0.6
7.1 ± 0.3 3.2 ± 0.3 2.5 ± 0.3 1.3 ± 0.3 3.6 ± 0.6
7.3 ± 0.3 4.3 ± 0.3 2.8 ± 0.3 1.3 ± 0.4 3.9 ± 0.6
7.2 ± 0.3 6.0 ± 0.3 3.5 ± 0.3 1.3 ± 0.4 3.8 ± 0.6
(mm)
(D)
(6.0)
(6.0)
(6.4)
(6.2)
Standard Ratings
D dimension only for reference
F72
Cap.(µF)
V
Code
4
0G
6.3
0J
10
1A
R
16
1C
R
R
R
F75
Cap. (µF)
V
Code
4
0G
6.3
0J
10
1A
033
047
068
100
150
220
330
470
680
1000
1500
336
476
686
107
157
227
337
477
687
108
158
M
M
R
R
R
R
R
R
R
R
R
R
R
R
R
(R)
M
M
M
( )
The series in parentheses
are being developed. Please
contact to your local Nichicon
sales office when these
series are being designed in
your application.
068
100
150
220
330
470
680
1000
1500
2200
686
107
157
227
337
477
687
108
158
228
C
C
C
•
D
D
D
•
R
R
R
C
•
D
U
•
D
(U)
•
D
•
R
(U)
•
R
C
C
•
D
D
U
•
R
16
1C
C
C
D
R
CAT.8100B
1mm
PCB Design
