This document was generated on 02/14/2018
PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
Part Number:
Status:
Overview:
Description:
0015247060
Active
Mini-Fit Products
Mini-Fit BMI Receptacle Header, 4.20mm Pitch, Dual Row, Vertical, with Snap-In
Plastic Pegs, Post 2.54µm Tin (Sn), UL 94V-2, 6 Circuits
Documents:
3D Model
Drawing (PDF)
Product Specification PS-5556-002-001 (PDF)
Product Specification TS-5556-002-001 (PDF)
Agency Certification
CSA
UL
General
Product Family
Series
Application
Comments
Overview
Product Name
UPC
Physical
Circuits (Loaded)
Circuits (maximum)
Color - Resin
Durability (mating cycles max)
Flammability
Glow-Wire Compliant
Guide to Mating Part
Keying to Mating Part
Lock to Mating Part
Material - Metal
Material - Plating Mating
Material - Resin
Net Weight
Number of Rows
Orientation
PCB Locator
PCB Retention
PCB Thickness - Recommended
Packaging Type
Pitch - Mating Interface
Pitch - Termination Interface
Polarized to Mating Part
Polarized to PCB
Surface Mount Compatible (SMC)
Temperature Range - Operating
Termination Interface: Style
Electrical
Current - Maximum per Contact
Grounding to PCB
Voltage - Maximum
Packaging Specification PK-42385-999 (PDF)
Test Summary 423850000-TS-000 (PDF)
RoHS Certificate of Compliance (PDF)
Series image - Reference only
EU ELV
Not Relevant
LR19980
E29179
PCB Receptacles
42385
Board-to-Board, Power
Solder Type|With Pegs
Mini-Fit Products
Mini-Fit BMI
800754209052
6
6
Natural
30
94V-2
No
Yes
None
None
Brass
Tin
Nylon
1.296/g
2
Vertical
Yes
Yes
1.00mm
Tray
4.20mm
4.20mm
Yes
Yes
No
-40°C to +105°C
Through Hole
9.0A
No
600V AC (RMS)/DC
EU RoHS
China RoHS
Compliant
REACH SVHC
Not Contained Per -
ED/30/2017 (7 July
2017)
Halogen-Free
Status
Low-Halogen
Need more information on product
environmental compliance?
Email productcompliance@molex.com
Please visit the Contact Us section for any
non-product compliance questions.
China ROHS
ELV
RoHS Phthalates
Green Image
Not Relevant
Not Contained
Search Parts in this Series
42385 Series
Mates With
42475 Panel Mount Plug, 42404 Right Angle
Header, 42440 Vertical Header, 43879
Vertical Header, 44068 Vertical Header
Solder Process Data
Duration at Max. Process Temperature (seconds)
Lead-freeProcess Capability
Max. Cycles at Max. Process Temperature
Process Temperature max. C
Material Info
Engineering Number
Reference - Drawing Numbers
Packaging Specification
Product Specification
Sales Drawing
Test Summary
005
WAVE
001
240
42385-06A1
PK-42385-999
PS-5556-002-001, TS-5556-002-001
SDA-42385-*
423850000-TS-000
This document was generated on 02/14/2018
PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
