C44A
ALUMINIUM CASE CAPACITORS
GENERAL PURPOSE APPLICATION
SCREW TERMINALS
MKP Series
TECHNICAL DATA
General technical data
Application class ( DIN 40040 )
Temperature range ( Case )
Max permissible ambient temperature
Capacitance tolerance code ( 15
th
digit )
Test voltage terminal to case U
TT
Test voltage terminal to case U
TC
Rated insulation voltage U
i
Permissible relative humidity
IEC climatic category
Degree of protection
Capacitance deviation in the operating temperature
range of –40 to +85
°C
Change of capacitance versus operating time
Case components
Terminals
Installation
Life Expectancy
Failure quota
VDE 0560 , IEC 071 , EN 61071
GPD / LS
-40 to + 85
°C
+70
°C
J = ± 5% ; K = ± 10%
1.5 U
RMS
for 60 seconds
3kV - 50Hz for 60 seconds
700 V - 50 Hz - Insulation group B ( VDE 0110 part 1 )
Annual average
≤
95% on 30 days / year, continuously 100% on
other days occasionally 100%. Dewing not admissible
40 / 85 / 21
IP00
±1.5% max on capacitance value measured at +20
°C
-3% after 30.000 hours at U
RMS
or after 100.000 hours at Un
Aluminium case plus plastic insulating deck flame retardant
execution ( UL class 94 V1 ) .
Tinned brass fastons or screws ( See figure on top )
Whatever Position
≥
30.000 hours at U
RMS
;
≥
100.000 hours at Un
300 / 10
9
components hour
27
C44A
DRAWINGS
ALUMINIUM CASE CAPACITORS
GENERAL PURPOSE APPLICATION
SCREW TERMINALS
MKP Series
MECHANICAL CHARACTERISTICS
20.5
Case
D
45
50
55
60
65
70
85
22.3
±0.5
1.3
Bolt
M
M8
M8
M 12
M 12
M 12
M 12
M 12
Brass screw terminals
Driving
Torque
Nm
4
4
4
4
4
4
7
M6
6
Creepage
Distance
14
14
16
18
20
22
22
Clearance
In air
10
10
10
10
10
10
10
H
10
10
12.5
12.5
12.5
12.5
12.5
Driving
Torque
Nm
6
6
10
10
10
10
10
L
H
±2
6.5
M
ØD
±0.5
TERMINATIONS
35
±0.5
11.5
M10
22.3
±0.5
22.5
6.3
6
22.3
±0.5
M8
6
4.5
M
ØD
±0.5
19.5
7
31.5
25
H
±2
6.5
H
±2
8
L
M
L
L
M
ØD
±0.5
