Technical Data
4399
Effective
June
2017
Supersedes
October
2011
HALOGEN
PTR016V
HF
FREE
16 Volt DC radial leaded, PolyTron™ PTC devices
Applications
•
•
•
•
Pb
Medical equipment
Telecommunications
White goods
Computers and peripherals
cURus: Recognized Card: File E343021 (Ihold 3A-15A)
TUV File: J 50194729
Agency information
•
•
Product features
•
•
•
•
•
•
Ordering
information/
part number system
PolyTron™ radial leaded thru-hole PTC device
Maximum 16 volts
Current ratings from 0.9 to 15 amps
Fast time-to-trip
Low resistance
Halogen free, lead free, RoHS compliant
PT
R 016V 0090
-TR
PolyTron™ PTC Device Series
Radial Leaded
Maximum Voltage
Current Holding (Ihold)
Packaging and Lead Type Code
Lead Codes:
TR & BK - Straight Leads, TR1 & BK1 - Kinked Leads
TR & TR1 On Reels
• 0.9-1.85A - 3000 devices
• 2.5-4A - 2500 devices
• 5-7A - 1500 devices
• 8-15A - 1000 devices
BK & BK1 In Poly Bags
• 0.9-1.60A - 1000 devices
• 1.85-9.00A - 500 devices
• 10.00-15.00A - 250 devices
Catalog
Number
PTR016V0090
PTR016V0110
PTR016V0135
PTR016V0160
PTR016V0185
PTR016V0250
PTR016V0300
PTR016V0400
PTR016V0500
PTR016V0600
PTR016V0700
PTR016V0800
PTR016V0900
PTR016V1000
PTR016V1100
PTR016V1200
PTR016V1300
PTR016V1400
PTR016V1500
Notes:
Vmax
(Vdc)
16
16
16
16
16
16
16
16
16
16
16
16
16
16
16
16
16
16
16
Ihold
Itrip
Imax @23°C @23°C
(Amps) (Amps) (Amps)
40
0.90
1.80
40
1.10
2.20
40
1.35
2.70
40
1.60
3.20
40
1.85
3.70
40
2.50
5.00
100
3.00
5.10
100
4.00
6.80
100
5.00
8.50
100
6.00
10.20
100
7.00
11.90
100
8.00
13.60
100
9.00
15.30
100
10.00
17.00
100
11.00
18.70
100
12.00
20.40
100
13.00
22.10
100
14.00
23.80
100
15.00
25.50
Pd
Typ.
(W)
0.60
0.70
0.80
0.90
1.00
1.20
2.30
2.40
2.60
2.80
3.00
3.00
3.30
3.60
3.70
4.20
4.60
4.60
4.60
Time to
Trip (Max.)
(Amps) (Sec)
8.00
1.20
8.00
2.30
8.00
4.50
8.00
9.00
8.00
10.00
8.00
40.00
15.00
1.00
20.00
1.70
25.00
2.00
30.00
3.30
35.00
3.50
40.00
5.00
45.00
5.50
50.00
6.00
55.00
7.00
60.00
7.50
65.00
8.50
70.00
9.00
75.00
10.00
Resistance (Ω)
Agency
Initial (Ri)
Post Trip (R )
Information
1
Min.
Max.
Max.
cURus TUV
0.070
0.120
0.180
X
0.050
0.095
0.140
X
0.040
0.074
0.120
X
0.030
0.061
0.110
X
0.030
0.051
0.090
X
0.020
0.036
0.070
X
0.038
0.065
0.098
X
X
0.021
0.038
0.060
X
X
0.010
0.023
0.034
X
X
0.006
0.018
0.028
X
X
0.006
0.013
0.020
X
X
0.005
0.011
0.018
X
X
0.005
0.009
0.014
X
X
0.004
0.007
0.010
X
X
0.003
0.006
0.009
X
X
0.003
0.006
0.009
X
X
0.002
0.006
0.008
X
X
0.002
0.005
0.007
X
X
0.002
0.005
0.007
X
X
I
I
– Hold current: Maximum current device will pass without interruption in 23°C still air.
hold
I
trip
– Trip current: Minimum current that will switch the device from low resistance to high resistance in 23°C still air.
V
max
: Maximum continuous voltage device can withstand without damage at rated current.
I
max
: Maximum fault current device can withstand without damage at rated voltage.
Pd: Power dissipated from device when in the tripped state in 23°C still air.
R
i
(min.): Minimum resistance of device as supplied at 23°C unless otherwise specified.
R
1
(max.): Maximum resistance of device when measured one hour post reflow (SMD) or one hour post trip (radial-leaded device) at 23°C unless otherwise specified.
Technical Data
4399
Effective
June
2017
PTR016V
16 Volt DC radial leaded, PolyTron™ PTC devices
Dimensions - mm
B Max
Lead Type
Straight Kink
(-TR) (-TR1)
12.2 12.2
14.2 14.2
13.5 13.5
15.2 15.2
15.7 15.7
18.3 20.5
11.0 14.0
12.8 14.8
14.3 16.0
17.1 19.0
19.7 22.0
20.9 23.0
21.9 24.0
25.2 28.0
26.0 29.0
28.0 31.0
29.2 32.0
27.9 30.0
29.0 32.0
Figure/
Lead Style
Straight Kink
TR
TR1
2
1
2
1
2
1
2
1
2
1
2
1
2
1
2
1
2
1
2
1
2
1
2
1
2
1
2
1
2
1
2
1
2
1
2
1
2
1
Style 1
Part
Number
PTR016V0090
PTR016V0110
PTR016V0135
PTR016V0160
PTR016V0185
PTR016V0250
PTR016V0300
PTR016V0400
PTR016V0500
PTR016V0600
PTR016V0700
PTR016V0800
PTR016V0900
PTR016V1000
PTR016V1100
PTR016V1200
PTR016V1300
PTR016V1400
PTR016V1500
A
Max.
7.4
7.4
8.9
8.9
10.2
11.4
7.1
8.9
10.4
10.7
11.2
12.7
14.0
16.5
17.5
17.5
21.6
23.5
25.1
C
5.0±0.8
5.0±0.8
5.0±0.8
5.0±0.8
5.0±0.8
5.0±0.8
5.0±0.8
5.0±0.8
5.0±0.8
5.0±0.8
5.0±0.8
5.0±0.8
5.0±0.8
5.0±0.8
5.0±0.8
10.0±0.8
10.0±0.8
10.0±0.8
10.0±0.8
D
Min.
7.6
7.6
7.6
7.6
7.6
7.6
7.6
7.6
7.6
7.6
7.6
7.6
7.6
7.6
7.6
7.6
7.6
7.6
7.6
E
Max.
3.1
3.1
3.1
3.1
3.1
3.1
3.1
3.1
3.1
3.1
3.1
3.1
3.1
3.1
3.1
3.1
3.1
3.1
3.1
F
0.5±0.02
0.5±0.02
0.5±0.02
0.5±0.02
0.5±0.02
0.5±0.02
0.8±0.02
0.8±0.02
0.8±0.02
0.8±0.02
0.8±0.02
0.8±0.02
0.8±0.02
0.8±0.02
0.8±0.02
1.0±0.02
1.0±0.02
1.0±0.02
1.0±0.02
Style 2
Packaging/Taping Specifications
Description
Sprocket hole pitch
Ordinate to adjacent component lead:
PTR016V0090~PTR016V0250
PTR016V0300~PTR016V1100
PTR016V1200~PTR016V1500
Device pitch:
PTR016V0090~PTR016V0600
PTR016V0700~PTR016V1400
PTR016V1500
Lead spacing
Carrier tape width
Top distance between tape edges
Hold-down tape width
Sprocket hole position
Abscissa to top:
PTR016V0090~PTR016V0600
PTR016V0700~PTR016V1500
Abscissa to plane
(straight lead)
(kinked lead)
Sprocket hole diameter
Lead protrusion
Tape thickness
Body lateral deviation
Body tape plane deviation
Reel width
Reel diameter
Arbor hole diameter
Core diameter
* See Dimensions table.
IEC
Mark
P0
P1
P1
P1
P
P
P
C
W
W0
W1
W2
H1
H1
H
H0
D0
L1
t
Δ
h
Δ
p
W3
n0
n
Dimension Tolerance
(mm)
(mm)
12.7
±0.3
3.6
4.5
7.2
12.7
25.4
38.1
*
18
3.0
12
9.0
32.2
47.5
18.0
16.0
4
1
0.9
0
0
56
340
31
80
±1.0
±1.0
±1.0
±1.0
±1.0
±1.0
--
±1.0
Max.
±1.0
+0.75/-0.5
Max.
Max.
+2/-0
±0.5
±0.2
Max.
Max.
±1.0
±1.3
Max.
±10
±1
Min.
Style 1 - PTR016V0090, PTR016V0110, PTR016V0135,
PTR016V0160-PTR016V1000
Style 2 - PTR016V1200-PTR016V1500
Reel Specifications
2
www.eaton.com/electronics
Technical Data
4399
Effective
June
2017
PTR016V
16
Volt DC radial leaded, PolyTron™ PTC devices
Thermal Derating Curve
P erc entage of D erated C urrent
200.0
180.0
160.0
140.0
120.0
100.0
80.0
60.0
40.0
20.0
0.0
-40
-20
0
20
40
Tem perature (°C)
60
80
Recommended Wave Solder Profile
P re h e a tin g
260°C max
Environmental Specifications
Co o lin g
So ld e rin g
Characteristic
Operating Temperature Range
Surface Temperature Trip State
Thermal Shock
Solvent Resistance
Humidity Age Test
No te 2
No te 3
130 ± 200°C
No te 1
T am b
Notes:
1. (1-3)°C/sec
3 0 ~9 0 se c
2. Approximately 200°C/sec
3. 5°C/sec Maximum
<1 se c
<1 0 sec
t
Storage Temperature Range
Storage Duration
Storage Relative Humidity
Storage Conditions
Value
-40°C to +85°C
125°C max.
+85°C to -40°C , 10 cycles,
5% typical resistance change
MIL-STD-202 Method 215, no change
+85°C, 85% R.H., 1000 hours
±5% typical resistance change.
Specified temperature (23°C ± 3°C)
-10°C to +40°C
One year
<75%
_
Keep away from corrosive atmosphere and sunlight
T e m p e ra ture
T im e
Material Composition
• Lead material:
- PTR016V0090-PTR016V0250 Tin-plated copper clad steel
- PTR016V0300-PTR016V1500 Tin-plated copper
• Insulating material: Cured epoxy resin meeting UL 94V0 requirements
Recommended Reworking Conditions with Soldering Iron
• Soldering Iron Tip Temperature: 360°C max.
• Solder Time: 3 seconds max.
• Distance from Thermistor: 2mm min.
Life Support Policy: Eaton does not authorize the use of any of its products for use in life support devices or systems without the express written
approval of an officer of the Company. Life support systems are devices which support or sustain life, and whose failure to perform, when properly
used in accordance with instructions for use provided in the labeling, can be reasonably expected to result in significant injury to the user.
Eaton reserves the right, without notice, to change design or construction of any products and to discontinue or limit distribution of any products. Eaton also
reserves the right to change or update, without notice, any technical information contained in this bulletin.
Eaton
Electronics Division
1000 Eaton Boulevard
Cleveland, OH 44122
United States
www.eaton.com/electronics
© 2017 Eaton
All Rights Reserved
Printed in USA
Publication No.
4399
BU-SB111164
June
2017
Eaton is a registered trademark.
All other trademarks are property
of their respective owners.
