Datasheet
300mA Variable / Fixed Output
LDO Regulators
BDxxGA3WEFJ / BDxxGA3WNUX
●General
Description
BDxxGA3WEFJ / BDxxGA3WNUX series devices are LDO regulators with an output current of 300mA. The output
accuracy is ±1% of the output voltage. Both fixed and variable output voltage devices are available. The output voltage of
the variable output voltage device can be varied from 1.5V to 13V using external resistors. Various fixed output voltage
devices that do not use external resistors are also available. It can be used for a wide range of digital appliance applications.
It has small package types : HTSOP-J8 (4.90mm x 6.00mm x 1.00mm) / VSON008X2030 (2.00mm x 3.00mm x 0.60mm).
These devices have built-in over current protection to protect the device when output is shorted, 0μA shutdown mode, and
thermal shutdown circuit to protect the device during thermal over-load conditions. These LDO regulators are usable with
ceramic capacitors that enable a smaller layout and longer life.
●Package
HTSOP-J8 (EFJ)
VSON008X2030 (NUX)
●Features
+/-1% output voltage accuracy
Built-in Over Current Protection (OCP)
Built-in Thermal Shut Down circuit (TSD)
Zero
µA
shutdown mode
(Typ.)
(Typ.)
(Max.)
4.90mm x 6.00mm x 1.00mm
2.00mm x 3.00mm x 0.60mm
●Key
Specifications
Input power supply voltage range:
4.5V to 14.0V
Output voltage range(Variable type):
1.5V to 13.0V
Output voltage(Fixed type): 1.5V/1.8V/2.5V/3.0V/3.3V
5.0V/6.0V/7.0V/8.0V/9.0V/10V/12V
Output current:
0.3A (Max.)
Shutdown current:
0μA(Typ.)
Operating temperature range:
-25℃ to +85℃
HTSOP-J8
(EFJ)
VSON008X2030
(NUX)
●Typical
Application Circuit
V
CC
C
IN
EN
GND
FIN
V
O
R
1
FB
R
2
C
OUT
C
IN
V
CC
V
O
V
O_S
C
OUT
EN
GND
FIN
C
IN
, C
OUT
: Ceramic Capacitor
C
IN
, C
OUT
: Ceramic Capacitor
Output voltage variable type
Output voltage fixed type
○Product
structure：Silicon monolithic integrated circuit
www.rohm.com
© 2013 ROHM Co., Ltd. All rights reserved.
TSZ22111½14½001
○This
product is not designed to have protection against radioactive rays.
1/20
TSZ02201-0R6R0A600180-1-2
17.May.2013 Rev.004
BDxxGA3WEFJ / BDxxGA3WNUX
●Ordering
Information
Datasheet
B
D
x
x
G
A
3
W
y
y
y
-
zz
Part
Output
Number voltage
Input
voltage
range
G:15V
Output
current
Shutdown
mode
Package
Packaging and forming specification
00:Variable
15:1.5V
18:1.8V
25:2.5V
30:3.0V
33:3.3V
50:5.0V
60:6.0V
70:7.0V
80:8.0V
90:9.0V
J0:10.0V
J2:12.0V
A3:0.3A “W”:Included EFJ :HTSOP-J8
E2:Emboss tape reel
NUX:VSON008X2030
(HTSOP-J8)
TR:Emboss tape reel
(VSON008X2030)
●Line
up
xx
00
15
18
25
30
33
50
60
70
80
90
J0
J2
Output
Voltage(V)
variable
1.5
1.8
2.5
3.0
3.3
5.0
6.0
7.0
8.0
9.0
10.0
12.0
BD00GA3WEFJ-E2
BD15GA3WEFJ-E2
BD18GA3WEFJ-E2
BD25GA3WEFJ-E2
BD30GA3WEFJ-E2
BD33GA3WEFJ-E2
BD50GA3WEFJ-E2
BD60GA3WEFJ-E2
BD70GA3WEFJ-E2
BD80GA3WEFJ-E2
BD90GA3WEFJ-E2
BDJ0GA3WEFJ-E2
BDJ2GA3WEFJ-E2
Product Name
BD00GA3WNUX-TR
BD15GA3WNUX-TR
BD18GA3WNUX-TR
BD25GA3WNUX-TR
BD30GA3WNUX-TR
BD33GA3WNUX-TR
BD50GA3WNUX-TR
BD60GA3WNUX-TR
BD70GA3WNUX-TR
BD80GA3WNUX-TR
BD90GA3WNUX-TR
BDJ0GA3WNUX-TR
BDJ2GA3WNUX-TR
www.rohm.com
© 2013 ROHM Co., Ltd. All rights reserved.
TSZ22111½15½001
2/20
TSZ02201-0R6R0A600180-1-2
17.May.2013.Rev.004
BDxxGA3WEFJ / BDxxGA3WNUX
●Block
Diagram
BD00GA3WEFJ / BD00GA3WNUX (Variable output voltage type)
Datasheet
V
CC
SOFT
START
V
O
Figure 1. Block Diagram
●Pin
Configuration (TOP VIEW)
V
O
FB
GND
N.C.
1
2
3
4
8
7
6
5
V
CC
N.C.
N.C.
EN
V
O
FB
GND
N.C.
1
2
3
4
8
7
6
5
V
CC
N.C.
N.C.
EN
(HTSOP-J8)
(VSON008X2030)
●Pin
Description
Pin No.
Pin name
1
V
O
2
FB
3
GND
4
N.C.
5
EN
6
N.C.
7
N.C.
8
V
CC
Reverse
FIN
Pin Function
Output pin
Feedback pin
GND pin
No Connect (Connect to GND or leave OPEN)
Enable pin
No Connect (Connect to GND or leave OPEN)
No Connect (Connect to GND or leave OPEN)
Input pin
Substrate(Connect to GND)
www.rohm.com
© 2013 ROHM Co., Ltd. All rights reserved.
TSZ22111½15½001
3/20
TSZ02201-0R6R0A600180-1-2
17.May.2013.Rev.004
BDxxGA3WEFJ / BDxxGA3WNUX
●Block
Diagram
BDxxGA3WEFJ / BDxxGA3WNUX (Fixed output voltage type)
Datasheet
V
CC
OCP
SOFT
START
V
O
EN
TSD
V
O_S
GND
Figure 2. Block Diagram
●Pin
Configuration (TOP VIEW)
V
O
V
O_S
GND
N.C.
1
2
3
4
8
7
6
5
V
CC
N.C.
N.C.
GND
EN
N.C.
3
4
6
5
V
O
V
O_S
1
2
8
7
V
CC
N.C.
N.C.
EN
(HTSOP-J8)
(VSON008X2030)
●Pin
Description
Pin No.
1
2
3
4
5
6
7
8
Reverse
Pin name
V
O
V
O_S
GND
N.C.
EN
N.C.
N.C.
V
CC
FIN
Pin Function
Output pin
Output voltage monitor pin
GND pin
No Connect (Connect to GND or leave OPEN)
Enable pin
No Connect (Connect to GND or leave OPEN)
No Connect (Connect to GND or leave OPEN)
Input pin
Substrate(Connect to GND)
www.rohm.com
© 2013 ROHM Co., Ltd. All rights reserved.
TSZ22111½15½001
4/20
TSZ02201-0R6R0A600180-1-2
17.May.2013.Rev.004
BDxxGA3WEFJ / BDxxGA3WNUX
●Absolute
Maximum Ratings (Ta=25℃)
Parameter
Power supply voltage
EN voltage
HTSOP-J8
Power dissipation
VSON008X2030
Operating Temperature Range
Storage Temperature Range
Junction Temperature
Symbol
V
CC
V
EN
Pd
*2
Pd
*3
Topr
Tstg
Tjmax
Ratings
15.0 *
1
15.0
2110
*2
1700
*3
-25 to +85
-55 to +150
+150
Unit
V
V
mW
℃
℃
℃
Datasheet
*1 Not to exceed Pd
*2 Reduced by 16.9mW/℃ for temperature above 25℃. (When mounted on a two-layer glass epoxy board with 70mm×70mm×1.6mm dimension)
*3 Reduced by 13.6mW/℃ for temperature above 25℃. (When mounted on a four-layer glass epoxy board with 114.3mm×76.2mm×1.6mm dimension)
●Recommended
Operating Range (Ta=25℃)
Parameter
Input power supply voltage
EN voltage
Output voltage setting range
Output current
Symbol
V
CC
V
EN
V
O
I
O
Ratings
Min.
4.5
0.0
1.5
0.0
Max.
14.0
14.0
13.0
0.3
Unit
V
V
V
A
●Electrical
Characteristics (Unless otherwise specified, Ta=25℃, EN=3V, V
CC
=6V, R
1
=43kΩ, R
2
=8.2kΩ)
Parameter
Circuit current at shutdown mode
Bias current
Line regulation
Load regulation
Minimum dropout voltage1
Minimum dropout voltage2
Minimum dropout voltage3
Output reference voltage(Variable type)
Output voltage(Fixed type)
EN Low voltage
EN High voltage
EN bias current
Min.
I
SD
-
I
CC
-
Reg.I
-1
Reg I
O
-1.5
V
CO1
-
V
CO2
-
V
CO3
-
V
FB
0.792
V
O
V
O
×0.99
V
EN
(Low)
0
V
EN
(High)
2.4
I
EN
1
Symbol
Limits
Typ.
0
600
-
-
0.15
0.30
0.45
0.800
V
O
-
-
3
Max.
5
900
1
1.5
0.30
0.60
0.90
0.808
V
O
×1.01
0.8
14.0
9
Unit
μA
μA
%
%
V
V
V
V
V
V
V
µA
Conditions
V
EN
=0V, OFF mode
V
CC
=( V
O
+0.9V )→14.0V
I
O
=0→0.3A
V
CC
=5V, I
O
=100mA
V
CC
=5V, I
O
=200mA
V
CC
=5V, I
O
=300mA
I
O
=0A
I
O
=0A
www.rohm.com
© 2013 ROHM Co., Ltd. All rights reserved.
TSZ22111½15½001
5/20
TSZ02201-0R6R0A600180-1-2
17.May.2013.Rev.004
