1,5
1,5
Verpackt im Gurt nach DIN IEC 60286-3
3,27
2
Anforderungsstufe 1
Tape on Reel Packaging according to DIN IEC 60286-3
Verpackungseinheit: 560 Stück
Performance Level 1
1
12,7
9,57
1,8
1,27
Kontaktbereich vergoldet
Packaging unit: 560 pcs
Mating Area gold plating
Anschlussbereich verzinnt 4-6 µm
Terminal Area 4-6 µm tin plating
Koplanarität der Anschlüsse
≤
0,1 mm
3,1
Coplanarity Area of Termination
≤
0,1 mm
8,57
10,77
±0,03
5 x 1,27 = 6,35
b1
1,5
-0,03
1,27
b6
330
Abspulrichtung -
Reel off Direction
7,2
+0,2
4
-0,1
5
0,75
-0,05
4,2
24
10,37
6,4
8,8
10
b1
16
Leiterplatten-Layout Vorschlag für SMT
PCB-Layout Proposal for SMT
10,77
±0,03
2,21
±0,03
1,27
1,27
2
±0,05
5 x 1,27 = 6,35
BA7-03 - Standard Bauhöhe für Verriegelung
type7-03 - Standard Assembly Height for locking mechanism
Copyright by ERNI GmbH
Proprietary notice pursuant to ISO 16016 to be observed.
Information:
Tolerances
All Dimensions
in mm
Scale
3:1
7,6
2,2
0,3
1,2
0,8
1,6
-0,03
All rights reserved.
Only for Information.
To ensure that this is the latest
version of this drawing, please
contact one of the ERNI companies
before using.
c
Index
25.06.2015
Date
Designation
Subject to modification without
prior notice.
Drawing will not be updated.
Messerl. SMC-B 12-SMD-BA7-03
Male SMC-B 12-SMD-type7-03
www.ERNI.com
Class
254273
SMCB
I
A3
