Synthesizer , SMT
400 MHz
Features
♦
♦
♦
♦
RoHS Compliant
Fully Integrated VCO, PLL, Loop Filter
High Performance, Low Cost
Miniature SMT Package (LSM6)
MAVC-060103-130400
Rev: C
Description
This synthesizer design integrates a high performance VCO, PLL,
IC and discrete loop filter in a surface mount package. This SMT
package provides electrical shielding, easy PCB assembly and re-
peatable performance. The synthesizer is designed for use in wire-
less base stations.
M/A-COM synthesizers are manufactured in an ISO9001 certified
facility, incorporating surface mount assembly and automated elec-
trical testing. This ensures consistent electrical performance and
quality over volume production quantities.
Electrical Specifications
1
:
T
A
= +25°C, Z
0
= 50 Ohms, V
cc1
= 5V, V
cc2
= 3.3V.
Parameter
Frequency Range
RF Output Power
Phase Noise
Test Conditions
Over T
op 2
Over T
op 2
SSB at 100 Hz offset from carrier
SSB at 1 kHz offset from carrier
SSB at 10 kHz offset from carrier
SSB at 100 kHz offset from carrier
SSB at 1000 kHz offset from carrier
Units
MHz
dBm
dBc/Hz
dBc/Hz
dBc/Hz
dBc/Hz
dBc/Hz
dBc
Phase comparison frequency
Other spurious
dBc
dBc
dBc
Over F
out
, +/- 500Hz
Recommended operating condition
Recommended operating condition
Recommended operating condition
Recommended operating condition
mS
mA
mA
V
V
4.75
3.1
20
27
9
5.0
3.3
-3.0
-83
-83
-110
-130
-148
-25
-73
-85
Min
Typ
400
+3.0
-80
-80
-105
-127
-145
-20
-70
-80
-80
30
30
10
5.25
3.5
Max
Harmonic Suppression
Spurious Suppression
(Non-Harmonic)
Reference breakthrough
Frequency Lock Time
VCO Supply Current (I
CC1
)
PLL Supply Current (I
CC2
)
VCO Power Supply (V
CC1
)
PLL Power Supply (V
CC2
)
1. All specification limits are indicated values @ +25 ºC and apply over F
out
unless otherwise stated.
2. See “Absolute Maximum Ratings” for T
op.
1
M/A-COM Inc. and its affiliates reserve the right to make changes to the
product(s) or information contained herein without notice. M/A-COM makes
no warranty, representation or guarantee regarding the suitability of its
products for any particular purpose, nor does M/A-COM assume any liabil-
ity whatsoever arising out of the use.
or application of any product(s) or information.
•
North America
Tel: 800.366.2266 / Fax: 978.366.2266
•
Europe
Tel: 44.1908.574.200 / Fax: 44.1908.574.300
•
Asia/Pacific
Tel: 81.44.844.8296 / Fax: 81.44.844.8298
Visit
www.macom.com
for additional data sheets and product information.
Synthesizer , SMT
400 MHz
Electrical Specifications
1
: (cont’d)
Parameter
Step Size (ΔF)
Reference Frequency (F
R
)
PLL Programming
PLL Lock Monitor Output
Test Conditions
Recommended operating limit
1.0 V pp ± 0.2V square wave with input filter
MAVC-060103-130400
Units
kHz
MHz
Min
Typ
1000
Max
6
10
100
3-wire serial CMOS IAW ADF4113, Charge Pump max current
Logic high = V
CC2
x 0.8 Min and Logic low = V
CC2
x 0.2 Max
Locked = V
CC2
- 0.4 Min , Unlocked = 0.4V Max
Pin Configuration
Pin No.
1
2
3
4
5
6
7
Function
V
CC2
GND
REF I/P
GND
V
CC1
GND
RF O/P
Pin No.
8
9
10
11
12
13
14
Function
GND
Lock Detect
Clock
Data
Load Enable
GND
GND
Absolute Maximum Ratings
T
A
= +25°C
Parameter
VCO Supply Voltage (V
CC1
)
PLL Supply Voltage (V
CC2
)
Reference Frequency Level
Data, Clock, Strobe
Voltages
Operating Temperature
Storage Temperature
Solder Assembly
Temperature
Weight
TO CONTROLLER
Absolute Maximum
-0.3V to 6.5 V
-0.3V to 6.5 V
-0.3V to 6.5 V
-0.3V to V
cc
+ 0.3 V
-40°C to +85°C
-45°C to +120°C
See App Note M2032
3.0 grams
2
Class 1
Functional Block Diagram
Moisture Sensitivity Level
2
ESD Rating
13
1
10nF
2
GND
DATA
11
GND
VCC2
LOAD ENABLE
12
3
REF IN
CLOCK
10
1. Operation of this device above any one of these parameters
may cause permanent damage.
2. As per JEDEC-STD-020.
4
GND
LOCK DETECT
9
Environmental Specifications
Devices are designed to function after exposure to the
shock, vibration, thermal shock and moisture conditions
typically encountered in base station and other infra-
structure environments.
50R
5
10nF
6
VCC1
GND
8
GND
GND
14
RF OUT
7
Ordering Information
1. The diagram above shows a typical application.
2. The Reference input and RF output are internally AC cou-
pled.
3. The diagram applies when digital lock detect is selected. For
analog open-drain mode, a filter is required.
Part Number
MAVC-060103-130400
1. See application note M513.
Package
Tape and Reel (300/Reel)
1
2
M/A-COM Inc. and its affiliates reserve the right to make changes to the
product(s) or information contained herein without notice. M/A-COM makes
no warranty, representation or guarantee regarding the suitability of its
products for any particular purpose, nor does M/A-COM assume any liabil-
ity whatsoever arising out of the use.
or application of any product(s) or information.
•
North America
Tel: 800.366.2266 / Fax: 978.366.2266
•
Europe
Tel: 44.1908.574.200 / Fax: 44.1908.574.300
•
Asia/Pacific
Tel: 81.44.844.8296 / Fax: 81.44.844.8298
Visit
www.macom.com
for additional data sheets and product information.
Synthesizer , SMT
400 MHz
Recommended PCB Layout
MAVC-060103-130400
1.
2.
3.
Tolerance: ±0.1mm
Both views are shown from top of device.
Crossed hatched areas to be left clear. These areas may have active vias.
Outline Drawing
1.
2.
3.
4.
5.
Plating: Au, 0.05μm — 0.15μm over Ni barrier of 2.5μm — 5.0μm.
Internal Solder: Sn95.5/Ag4.0/Cu0.5, lead free.
Substrate: FR4
Cover: mild steel
Tolerance: ±0.2mm unless otherwise noted.
ECO History
Rev
A
B
C
3
Date
Dec 8th 2005
Create datasheet
Description
By
JS
JS
JS
Dec 15th 2005 Change of the reference frequency specification from Min=10, Typ=, to Min=6, Typ=10,
Feb 20th 2005 Change of 1000kHz SSB Phase noise from Typically
Change of 1000kHz SSB Phase noise from Max
–150 to –148dBc/Hz,
-147 to -145dBc/Hz.
M/A-COM Inc. and its affiliates reserve the right to make changes to the
product(s) or information contained herein without notice. M/A-COM makes
no warranty, representation or guarantee regarding the suitability of its
products for any particular purpose, nor does M/A-COM assume any liabil-
ity whatsoever arising out of the use.
or application of any product(s) or information.
•
North America
Tel: 800.366.2266 / Fax: 978.366.2266
•
Europe
Tel: 44.1908.574.200 / Fax: 44.1908.574.300
•
Asia/Pacific
Tel: 81.44.844.8296 / Fax: 81.44.844.8298
Visit
www.macom.com
for additional data sheets and product information.
