HCF4026B datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > HCF4026B

Preview

HCF4026B: DescriptionDECADE COUNTER/DIVIDER WITH DECODED 7-SEGMENT DISPLAY OUTPUT AND DISPLAY ENABLE; File Size737KB，11 Pages; ManufacturerSTMicroelectronics; Websitehttp://www.st.com/

Download Datasheet Compare View All

HCF4026B Overview

DECADE COUNTER/DIVIDER WITH DECODED 7-SEGMENT DISPLAY OUTPUT AND DISPLAY ENABLE

Preview

Download Datasheet

View All

HCF4026B

DECADE COUNTER/DIVIDER WITH DECODED

7-SEGMENT DISPLAY OUTPUT AND DISPLAY ENABLE

COUNTER AND 7-SEGMENT DECODING IN

ONE PACKAGE

EASILY INTERFACED WITH 7-SEGMENT

DISPLAY TYPES

FULLY STATIC COUNTER OPERATION : DC

TO 6MHz (Typ.) AT V

= 10V

IDEAL FOR LOW POWER DISPLAYS

DISPLAY ENABLE OUTPUT

QUIESCENT CURRENT SPECIF. UP TO 20V

STANDARDIZED SYMMETRICAL OUTPUT

CHARACTERISTICS

INPUT LEAKAGE CURRENT

= 100nA (MAX) AT V

= 18V T

= 25°C

100% TESTED FOR QUIESCENT CURRENT

MEETS ALL REQUIREMENTS OF JEDEC

JESD13B " STANDARD SPECIFICATIONS

FOR DESCRIPTION OF B SERIES CMOS

DEVICES"

DIP

SOP

ORDER CODES

PACKAGE

DIP

SOP

TUBE

HCF4026BEY

HCF4026BM1

T&R

HCF4026M013TR

DESCRIPTION

The HCF4026B is a monolithic integrated circuit

fabricated in Metal Oxide Semiconductor

technology available in DIP and SOP packages.

The HCF4026B consists of a 5-stages Johnson

decade counter and an output decoder which

converts the Johnson code to a 7 segment

decoded output for driving one stage in a

numerical display. This device is particularly

advantageous in display applications where low

power dissipation and/or low package count are

PIN CONNECTION

important. This device has CLOCK, RESET,

CLOCK INHIBIT, DISPLAY ENABLE input and

CARRY OUT, DISPLAY ENABLE, UNGATED "C"

SEGMENT and 7 DECODED outputs (a to g).

A high RESET signal clears the decade counter to

its zero count. The counter is advanced one count

at the positive clock signal transition if the CLOCK

INHIBIT signal is low. Counter advancement via

the clock line is inhibited when the CLOCK

INHIBIT signal is high. Antilock gating is provided

on the JOHNSON counter, thus assuring proper

counting sequence. The CARRY-OUT (C

OUT

)

signal completes one cycle every ten CLOCK

INPUT cycles and is used to clock the succeeding

decade directly in a multi-decade counting chain.

September 2001

1/11

HCF4026B Related Products

	HCF4026B	HCF4026BM1	HCF4026BEY
Description	DECADE COUNTER/DIVIDER WITH DECODED 7-SEGMENT DISPLAY OUTPUT AND DISPLAY ENABLE	DECADE COUNTER/DIVIDER WITH DECODED 7-SEGMENT DISPLAY OUTPUT AND DISPLAY ENABLE	DECADE COUNTER/DIVIDER WITH DECODED 7-SEGMENT DISPLAY OUTPUT AND DISPLAY ENABLE
Is it lead-free?	-	Lead free	Lead free
Is it Rohs certified?	-	conform to	conform to
Maker	-	STMicroelectronics	STMicroelectronics
Parts packaging code	-	SOIC	DIP
package instruction	-	SO-16	PLASTIC, DIP-16
Contacts	-	16	16
Reach Compliance Code	-	compli	compli
Is Samacsys	-	N	N
Other features	-	JOHNSON COUNTER; SCHMITT TRIGGER ON CLOCK I/P; 7 SEGMENT DISPLAY DRIVER; DISPLAY ENABLE	JOHNSON COUNTER; SCHMITT TRIGGER ON CLOCK I/P; 7 SEGMENT DISPLAY DRIVER; DISPLAY ENABLE
Counting direction	-	UP	UP
series	-	4000/14000/40000	4000/14000/40000
JESD-30 code	-	R-PDSO-G16	R-PDIP-T16
JESD-609 code	-	e4	e3
Load capacitance (CL)	-	50 pF	50 pF
Load/preset input	-	YES	YES
Logic integrated circuit type	-	DISPLAY DRIVER COUNTER	DISPLAY DRIVER COUNTER
Operating mode	-	SYNCHRONOUS	SYNCHRONOUS
Number of digits	-	5	5
Number of functions	-	1	1
Number of terminals	-	16	16
Maximum operating temperature	-	125 °C	125 °C
Minimum operating temperature	-	-55 °C	-55 °C
Package body material	-	PLASTIC/EPOXY	PLASTIC/EPOXY
encapsulated code	-	SOP	DIP
Encapsulate equivalent code	-	SOP16,.25	DIP16,.3
Package shape	-	RECTANGULAR	RECTANGULAR
Package form	-	SMALL OUTLINE	IN-LINE
Peak Reflow Temperature (Celsius)	-	NOT SPECIFIED	NOT SPECIFIED
power supply	-	3/15 V	3/15 V
propagation delay (tpd)	-	700 ns	700 ns
Certification status	-	Not Qualified	Not Qualified
Maximum seat height	-	1.75 mm	5.1 mm
Maximum supply voltage (Vsup)	-	20 V	20 V
Minimum supply voltage (Vsup)	-	3 V	3 V
Nominal supply voltage (Vsup)	-	5 V	5 V
surface mount	-	YES	NO
technology	-	CMOS	CMOS
Temperature level	-	MILITARY	MILITARY
Terminal surface	-	Nickel/Palladium/Gold (Ni/Pd/Au)	Matte Tin (Sn)
Terminal form	-	GULL WING	THROUGH-HOLE
Terminal pitch	-	1.27 mm	2.54 mm
Terminal location	-	DUAL	DUAL
Maximum time at peak reflow temperature	-	NOT SPECIFIED	NOT SPECIFIED
Trigger type	-	POSITIVE EDGE	POSITIVE EDGE
width	-	3.9 mm	7.62 mm
minfmax	-	8 MHz	8 MHz
Base Number Matches	-	1	1
