CABLE BREAKOUT BOOT
EIGHT ENTRY
Table of Dimensions, inch
(mm):
PART
NUMBER
(See Note*)
8S23-75FR
Body ID
Min. Exp.
(A)
1.50
(38)
Max. Rec’d
(B)
0.75
(19)
Leg ID
Min. Exp.
(C)
0.41
(10)
Max. Rec’d
(D)
0.13
(3)
Length Recovered
Min
(E), Body
2.65
(67)
(F), Leg
1.40
(36)
Rec’d. Wall
Ref
(W)
0.10
(2.5)
Note*:
Material:
Add “NA” to the end of Part Number if no adhesive is required
Heat shrinkable boot material in accordance with –3 polyolefin
Hot melt adhesive provided on the shrinkable portion of the boot is standard.
Factory applied sealant
:
Product Brand:
Raychem Products, North America
Tyco Electronics Corporation
300 Constitution Drive
Menlo Park, CA 94025 USA
Title:
Specification Control Drawing
Size
A
Tyco Electronics reserves the right to amend this
UNLESS OTHERWISE SPECIFIED
drawing at any time. Users should evaluate the
DIMENSIONS ARE IN INCHES.
suitability of the product for their application.
METRIC DIMENSIONS ARE SHOWN IN
BRACKETS
Drawn By:
Org. Date
:
Original file:
Cable Breakout Boot
Eight Entry
Cage Code
Document No.
06090
Rev.:
8SXXX-XXXFR
Rev. Date:
A
File :
Scale:
25-Mar-03
Sheet:
A.Ng
03/17/03
If this document is printed it becomes uncontrolled. Check for the latest revision.
R030159.doc
None
1 of 1
