MM74HC4066M: DescriptionQUAD 1-CHANNEL, SGL POLE SGL THROW SWITCH, PDSO14; CategoryAnalog mixed-signal IC The signal circuit; File Size122KB，10 Pages; ManufacturerFairchild; Websitehttp://www.fairchildsemi.com/; Environmental Compliance; Related ProductsFound19parts with similar functions to MM74HC4066M

Download Datasheet Parametric Compare View All

MM74HC4066M Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	MM74HC4066M	-	-	View	Buy Now

MM74HC4066M Overview

QUAD 1-CHANNEL, SGL POLE SGL THROW SWITCH, PDSO14

MM74HC4066M Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	Fairchild
Parts packaging code	SOIC
package instruction	0.150 INCH, MS-120, SOIC-14
Contacts	14
Reach Compliance Code	unknow
Is Samacsys	N
Analog Integrated Circuits - Other Types	SPST
JESD-30 code	R-PDSO-G14
JESD-609 code	e3
length	8.65 mm
Humidity sensitivity level	1
normal position	NO
Number of channels	1
Number of functions	4
Number of terminals	14
Nominal off-state isolation	42 dB
On-state resistance matching specifications	10 Ω
Maximum on-state resistance (Ron)	170 Ω
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
output	SEPARATE OUTPUT
Package body material	PLASTIC/EPOXY
encapsulated code	SOP
Encapsulate equivalent code	SOP14,.25
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Peak Reflow Temperature (Celsius)	260
power supply	2/12 V
Certification status	Not Qualified
Maximum seat height	1.75 mm
Maximum supply voltage (Vsup)	12 V
Minimum supply voltage (Vsup)	2 V
Nominal supply voltage (Vsup)	4.5 V
surface mount	YES
Maximum disconnect time	36 ns
Maximum connection time	20 ns
switch	MAKE-BEFORE-BREAK
technology	CMOS
Temperature level	INDUSTRIAL
Terminal surface	Matte Tin (Sn)
Terminal form	GULL WING
Terminal pitch	1.27 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED
width	3.9 mm
Base Number Matches	1

Preview

Download Datasheet

View All

MM74HC4066 Quad Analog Switch

August 1984

Revised January 2005

MM74HC4066

Quad Analog Switch

General Description

The MM74HC4066 devices are digitally controlled analog

switches utilizing advanced silicon-gate CMOS technology.

These switches have low “ON” resistance and low “OFF”

leakages. They are bidirectional switches, thus any analog

input may be used as an output and visa-versa. Also the

MM74HC4066 switches contain linearization circuitry

which lowers the “ON” resistance and increases switch lin-

earity. The MM74HC4066 devices allow control of up to

12V (peak) analog signals with digital control signals of the

same range. Each switch has its own control input which

disables each switch when LOW. All analog inputs and out-

puts and digital inputs are protected from electrostatic

damage by diodes to V

and ground.

Features

Typical switch enable time: 15 ns

Wide analog input voltage range: 0–12V

Low “ON” resistance: 30 typ. (MM74HC4066)

Low quiescent current: 80

A maximum (74HC)

Matched switch characteristics

Individual switch controls

Ordering Code:

Package

Order Number

MM74HC4066M

MM74HC4066MX_NL

MM74HC4066SJ

MM74HC4066MTC

MM74HC4066N

Number

M14A

M14D

MTC14

N14A

Package Description

14-Lead Small Outline Integrated Circuit (SOIC), JEDEC MS-012, 0.150" Narrow

Pb-Free 14-Lead Small Outline Integrated Circuit (SOIC), JEDEC MS-012, 0.150" Narrow

Pb-Free 14-Lead Small Outline Package (SOP), EIAJ TYPE II, 5.3mm Wide

14-Lead Thin Shrink Small Outline Package (TSSOP), JEDEC MO-153, 4.4mm Wide

14-Lead Plastic Dual-In-Line Package (PDIP), JEDEC MS-001, 0.300" Wide

Devices also available in Tape and Reel. Specify by appending the suffix letter “X” to the ordering code.

Pb-Free package per JEDEC J-STD-020B.

Schematic Diagram

Connection Diagram

Truth Table

Input

CTL

Switch

I/O–O/I

“OFF”

“ON”

Top View

DS005355

www.fairchildsemi.com
