Solid State Devices, Inc.
14701 Firestone Blvd * La Mirada, Ca 90638
Phone: (562) 404-4474 * Fax: (562) 404-1773
ssdi@ssdi-power.com * www.ssdi-power.com
1N7066 thru 1N7068
Series
Designer’s Data Sheet
Part Number/Ordering Information
1N70 __ __ __
│ │ └
Screening
2/
│ │
__
= Not Screened
│ │
TX = TX Level
│ │
TXV = TXV Level
│ │
S = S Level
│ │
│ └
Package Type
__
= Axial Leaded
│
SMS = Surface Mount Square Tab
│
FL = Flat Leads
│
│
└
Voltage/Family
66 = 100V
67 = 150V
68 = 200V
1/
10 AMP
HYPERFAST RECOVERY RECTIFIER
100
─
200 VOLTS, 30 ns
FEATURES:
Hyper fast reverse recovery: 30ns maximum
4/
High surge current: 350 A maximum
Hermetically sealed
Low forward voltage drop .95 @10A
Void free ceramic frit glass construction
High temperature category I eutectic metallurgical bond
Available in axial leaded, square tab, and flat leads versions
TX, TXV, and S-level screening available
2/
Available as a QPL product per MIL-PRF-19500/768
Axial lead higher current replacements for:
1N5807, 1N5809, 1N5811
Possible SMS replacements for stud mount:
1N5812, 1N5814, 1N5816
MAXIMUM RATINGS
3/
RATING
Peak Repetitive Reverse Voltage
and DC Blocking Voltage
Average Rectified Forward Current
(Axial T
L
≤
55°C; SMS T
EC
≤
100°C)
5/
SYMBOL
1N7066
1N7067
1N7068
V
RRM
V
RWM
V
R
I
O
I
FSM
VALUE
100
150
200
10
350
-65 to +175
8
4.5
UNIT
V
A
A
°C
°C/W
Peak Surge Current
(8.3 ms pulse, half sine wave, superimposed on Io, V
RWM
= rated,
allow junction to reach equilibrium between pulses, T
A
= 25°C)
Operating & Storage Temperature
T
J
and T
STG
Junction to Lead for Axial & FL, L =.125"
R
θJL
Thermal Resistance
Junction to End Tab for Surface Mount
R
θJE
NOTES:
1/ For ordering information, price, operating curves, and
availability- contact factory.
2/ Screening based on MIL-PRF-19500. Screening flows available
on request.
3/ Unless otherwise specified, all electrical characteristics @ 25°C.
4/ I
F
= 1A, I
R
= 1A, I
RR
= 0.1A, T
A
= 25°C
5/ Operating at higher I
O
currents may be achieved based on
specific application and device mounting if T
J
is maintained below
175°C.
Axial Leaded
SMS
Flat Leads (FL)
NOTE:
All specifications are subject to change without notification.
SCD's for these devices should be reviewed by SSDI prior to release.
DATA SHEET #: RC0119K
DOC
Solid State Devices, Inc.
14701 Firestone Blvd * La Mirada, Ca 90638
Phone: (562) 404-4474 * Fax: (562) 404-1773
ssdi@ssdi-power.com * www.ssdi-power.com
1N7066 thru 1N7068
Series
SYMBOL
V
F1
V
F2
V
F3
V
F4
V
F5
V
F6
I
R1
I
R2
I
R3
BV
R
C
J
t
RR
ELECTRICAL CHARACTERISTICS
3/
CHARACTERISTICS
Instantaneous Forward Voltage Drop
300
μs
pulse
I
F
= 6.0 Adc
I
F
= 10 Adc
I
F
= 20 Adc
I
F
= 6.0 Adc, T
A
= +125°C
I
F
= 6.0 Adc, T
A
= +150°C
I
F
= 6.0 Adc, T
A
= -55°C
T
A
= +25°C
T
A
= +125°C
T
A
= +150°C
1N7066
1N7067
1N7068
MIN
-
-
-
-
-
-
-
-
-
110
160
210
-
-
MAX
0.900
0.950
1.050
0.850
0.780
1.050
1
100
500
-
-
-
80
30
UNIT
Vdc
Reverse Leakage Current
At rated V
R
, 300
μs
pulse
Breakdown Voltage
I
R
= 100 µA
Junction Capacitance
V
R
= 10 Vdc, f = 1 MHz
Reverse Recovery Time
I
F
= 1 A, I
R
= 1 A, I
RR
= 0.1 A
μA
μA
μA
V
pF
ns
NOTE:
All specifications are subject to change without notification.
SCD's for these devices should be reviewed by SSDI prior to release.
DATA SHEET #: RC0119K
DOC
Solid State Devices, Inc.
14701 Firestone Blvd * La Mirada, Ca 90638
Phone: (562) 404-4474 * Fax: (562) 404-1773
ssdi@ssdi-power.com * www.ssdi-power.com
1N7066 thru 1N7068
Series
Package Outlines
:
AXIAL LEADED
DIMENSIONS (inches)
DIM.
A
B
C
D
SMS
DIMENSIONS (inches)
.165
.155
.042
1.30
DIM.
A
B
C
D
Minimum
.135
.135
.036
.900
Maximum
Minimum
.172
.180
.020
.002
Maximum
.180
.220
.028
---
FLAT LEADS (FL)
DIMENSIONS (inches)
DIM.
Minimum Maximum
ØA
.135
.165
B
.065
.085
C
.015
.021
D
.084
.104
E
F
G
H
I
.620
.660
FEATURES FOR FLAT LEADS PACKAGE
Solid silver leads
Provide stress relief (customizable to customer specifications)
Ideal for welding to BUS bar
Typical application: solar array bypass / blocking diodes for photovoltaic (PV) panels
REF .090
.295
.335
REF R.03
REF 120°
NOTE:
All specifications are subject to change without notification.
SCD's for these devices should be reviewed by SSDI prior to release.
DATA SHEET #: RC0119K
DOC
