5962-87716022A datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The signal circuit> 5962-87716022A

5962-87716022A: DescriptionSingle-Ended Multiplexer, 1 Func, 8 Channel, BIPolar, CQCC20, CERAMIC, LCC-20; CategoryThe signal circuit; File Size1MB，14 Pages; ManufacturerRochester Electronics; Websitehttps://www.rocelec.com/

Download Datasheet Parametric Compare View All

5962-87716022A Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	5962-87716022A	-	-	View	Buy Now

5962-87716022A Overview

Single-Ended Multiplexer, 1 Func, 8 Channel, BIPolar, CQCC20, CERAMIC, LCC-20

5962-87716022A Parametric

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Is it Rohs certified?	incompatible
Maker	Rochester Electronics
Parts packaging code	QLCC
package instruction	QCCN,
Contacts	20
Reach Compliance Code	unknown
Other features	OVERVOLTAGE PROTECTION
Analog Integrated Circuits - Other Types	SINGLE-ENDED MULTIPLEXER
JESD-30 code	S-CQCC-N20
length	8.89 mm
Nominal Negative Supply Voltage (Vsup)	-15 V
Number of channels	8
Number of functions	1
Number of terminals	20
Nominal off-state isolation	60 dB
On-state resistance matching specifications	80 Ω
Maximum on-state resistance (Ron)	400 Ω
Maximum operating temperature	125 °C
Minimum operating temperature	-55 °C
Package body material	CERAMIC, METAL-SEALED COFIRED
encapsulated code	QCCN
Package shape	SQUARE
Package form	CHIP CARRIER
Peak Reflow Temperature (Celsius)	NOT APPLICABLE
Certification status	Not Qualified
Filter level	MIL-STD-883
Maximum seat height	2.54 mm
Nominal supply voltage (Vsup)	15 V
surface mount	YES
Maximum disconnect time	400 ns
Maximum connection time	2000 ns
technology	BIPOLAR
Temperature level	MILITARY
Terminal form	NO LEAD
Terminal pitch	1.27 mm
Terminal location	QUAD
Maximum time at peak reflow temperature	NOT APPLICABLE
width	8.89 mm
Base Number Matches	1
