73S8014R
Smart Card Interface
Simplifying System Integration™
DATA SHEET
September 2008
DESCRIPTION
The Teridian 73S8014R is a single smart card (ICC) interface
circuit, firmware compatible with 8024-type devices for
configurations where only asynchronous cards must be
supported. It is derived from the 73S8024RN industry-
standard electrical interface. The 73S8014R has been
optimized to match most of the typical Set-Top-Box / A/V
Conditional Access applications. Optimization essentially
involved a smaller pin-count, support for single I/O, and
maximum card current of 65mA (ISO-7816 / EMV
compliance).
The 73S8014R interfaces with the host processor through the
same bus (digital I/Os) as the 73S8024RN, which is
compatible with any other 8024-type IC.
As a result, the
73S8014R is a very attractive cost-reduction path from
traditional 8024 ICs.
The 73S8014R has been designed to
provide full electrical compliance with ISO 7816-3 and EMV
4.0 specifications.
Interfacing with the system controller is done through a
control bus, composed of digital inputs to control the
interface, and one interrupt output to inform the system
controller of the card presence and faults.
The card clock can be generated by an on-chip oscillator
using an external crystal or by connection to an externally
supplied clock signal.
The 73S8014R incorporates an ISO 7816-3
activation/deactivation sequencer that controls the card
signals. Level-shifters drive the card signals with the
selected card voltage (3V or 5V), coming from an internal
Low Drop-Out (LDO) voltage regulator. This LDO regulator is
powered by a dedicated power supply input V
PC
. Digital
circuitry is powered separately by a digital power supply V
DD
.
With its embedded LDO regulator, the 73S8024RN is a
cost-effective solution for any application where a 5V
(typically -5% +10%) power supply is available.
Emergency card deactivation is initiated upon card extraction
or upon any fault detected by the protection circuitry. The
fault can be a card over-current, VCC undervoltage or power
supply fault (V
DD
). The card over-current circuitry is a true
current detection function, as opposed to V
CC
voltage drop
detection, as usually implemented in non-Teridian 8024
interface ICs.
The V
DD
voltage fault has a threshold voltage that can be
adjusted with an external resistor network. It allows
automated card deactivation at a customized V
DD
voltage
threshold value. It can be used, for instance, to match the
system controller operating voltage range.
APPLICATIONS
•
•
Set-Top-Box Conditional Access and Pay-per-View
General purpose smart card readers
ADVANTAGES
•
Same advantages as the Teridian 73S80xxR family:
VCC card generated by an LDO regulator
Very low power dissipation (saves up to 1/2W)
Fewer external components are required
Better noise performance
True card over-current detection
Firmware compatibility with all 8024 ICs
Small format 20SO package
•
•
•
FEATURES
•
Card Interface:
Complies with ISO 7816-3 and EMV 4.0
Supports 3V / 5V cards
ISO 7816-3 Activation / Deactivation sequencer
Automated deactivation upon hardware fault (i.e. upon
drop on V
DD
power supply or card overcurrent)
The V
DD
voltage supervisor threshold value (fault) can
be externally adjusted
Over-current detection 130mA max
Card CLK clock frequency up to 20MHz
System Controller Interface:
3 Digital inputs control the card activation /
deactivation, card reset and card voltage
2 Digital inputs control the card clock frequency
1 Digital output, interrupt to the system controller,
reports to the host the card presence and faults
Crystal oscillator or host clock, up to 27MHz
Regulator Power Supply:
4.75V to 5.5V
Digital Interfacing: 2.7V to 5.5V
6kV ESD protection on the card interface
Package: SO 20-pin
RoHS compliant (6/6) lead-free package
•
•
•
•
•
•
Rev. 1.0
© 2008 Teridian Semiconductor Corporation
1
73S8014R Data Sheet
FUNCTIONAL DIAGRAM
VDD
VPC
DS_8014R_012
vdd circuits
VCC FAULT
VDDF_ADJ
INTERNAL POWER SUPPLY
VOLTAGE REFERENCE
VPD -
internal supply
VDD FAULT
vref
bias currents
LDO
REGULATOR
R-C
OSC.
GND
VCC
CMDVCC
RSTIN
5V/#V
TEST
CONTROLLER
AND
REGISTERS
FAULT LOGIC
1.5MHz
RESET
BUFFER
RST
OFF
CKDIV1
CKDIV2
XTALIN
XTAL
OSC
XTALOUT
vdd circuits
CLOCK
SC
SEQUENCER
CLOCK
BUFFER
CLK
CLOCK
GENERATION
VDD CKT
PRES
I/O
IOUC
SMART CARD I/O BUFFER
vcc circuits
GND
Figure 1: 73S8014R Block Diagram
2
Rev. 1.0
DS_8014R_012
73S8014R Data Sheet
Table of Contents
1
2
Pinout ................................................................................................................................................................ 5
Electrical Specifications .................................................................................................................................. 8
2.1
Absolute Maximum Ratings ........................................................................................................................ 8
2.2
Recommended Operating Conditions ......................................................................................................... 8
2.3
Package Thermal Parameters .................................................................................................................... 9
2.4
Smart Card Interface Requirements ........................................................................................................... 9
2.5
Characteristics: Digital Signals.................................................................................................................. 11
2.6
DC Characteristics .................................................................................................................................... 12
2.7
Voltage Fault Detection Circuits ................................................................................................................ 13
3
Applications Information ............................................................................................................................... 14
3.1
Example 73S8014R Schematics .............................................................................................................. 14
3.2
System Controller Interface....................................................................................................................... 16
3.3
Power Supply and Voltage Supervision .................................................................................................... 16
3.4
Card Power Supply ................................................................................................................................... 17
3.5
On-Chip Oscillator and Card Clock ........................................................................................................... 17
3.6
Activation Sequence ................................................................................................................................. 18
3.7
Deactivation Sequence ............................................................................................................................. 19
3.8
Fault Detection and
OFF
........................................................................................................................... 20
3.9
I/O Circuitry and Timing ............................................................................................................................ 20
4
Equivalent Circuits ......................................................................................................................................... 22
5
Mechanical Drawing ....................................................................................................................................... 27
6
Ordering Information ..................................................................................................................................... 28
7
Related Documentation ................................................................................................................................. 28
8
Contact Information ....................................................................................................................................... 28
Rev. 1.0
3
73S8014R Data Sheet
DS_8014R_012
Figures
Figure 1: 73S8014R Block Diagram .......................................................................................................................... 2
Figure 2: 73S8014R 20-SOP Pin Out........................................................................................................................ 5
Figure 3: 73S8014R – Typical Application Schematic ............................................................................................ 15
Figure 4: Activation Sequence – RSTIN Low When
CMDVCC
Goes Low ............................................................. 18
Figure 5: Activation Sequence – RSTIN High When
CMDVCC
Goes Low............................................................. 19
Figure 6: Deactivation Sequence ............................................................................................................................ 19
Figure 7: Timing Diagram – Management of the Interrupt Line
OFF
...................................................................... 20
Figure 8: I/O and I/OUC State Diagram................................................................................................................... 21
Figure 9: I/O – I/OUC Delays – Timing Diagram ..................................................................................................... 21
Figure 10: Open Drain type –
OFF
.......................................................................................................................... 22
Figure 11: Power Input/Output Circuit, VDD, VPC, VCC ........................................................................................ 22
Figure 12: Smart Card CLK Driver Circuit ............................................................................................................... 23
Figure 13: Smart Card RST Driver Circuit ............................................................................................................... 23
Figure 14: Smart Card IO Interface Circuit .............................................................................................................. 24
Figure 15: Smart Card IOUC Interface Circuit ......................................................................................................... 24
Figure 16: General Input Circuit .............................................................................................................................. 25
Figure 17: Oscillator Circuit ..................................................................................................................................... 25
Figure 18: VDDF_ADJ ............................................................................................................................................. 26
Figure 19: Mechanical Drawing 20-Pin SO Package .............................................................................................. 27
Tables
Table 1: 73S8014R 20-Pin SOP Pin Definitions ....................................................................................................... 6
Table 2: Absolute Maximum Device Ratings ............................................................................................................. 8
Table 3: Recommended Operating Conditions ......................................................................................................... 8
Table 4: Package Thermal Parameters ..................................................................................................................... 9
Table 5: DC Smart Card Interface Requirements ..................................................................................................... 9
Table 6: Digital Signals Characteristics ................................................................................................................... 11
Table 7: DC Characteristics ..................................................................................................................................... 12
Table 8: Voltage Fault Detection Circuits ................................................................................................................ 13
Table 9: Order Numbers and Packaging Marks ...................................................................................................... 28
4
Rev. 1.0
DS_8014R_012
73S8014R Data Sheet
1 Pinout
The 73S8014R is supplied as a 20-pin SO package.
OFF
RSTIN
I/OUC
VPC
CLKDIV2
CMDVCC
5V/#V
GND
XTALIN
XTALOUT
1
2
3
4
5
6
7
8
9
10
20
19
18
17
16
15
14
13
12
11
CLKDIV1
PRES
VCC
CLK
GND
RST
I/O
VDD
VDDF_ADJ
GND
73S8014R
Figure 2: 73S8014R 20-SOP Pin Out
Rev. 1.0
