IHB
www.vishay.com
Vishay Dale
Filter Inductors, High Current, Radial Leaded
FEATURES
• Printed circuit mounting
• Wide range of inductance and current ratings
• Pre-tinned leads
• Optional polyolefin tubing and printing available
at additional cost
• Material categorization: For definitions of compliance
please see
www.vishay.com/doc?99912
ELECTRICAL SPECIFICATIONS
Inductance:
Measured at 1.0 V with zero DC current
Dielectric:
2500 V
RMS
between winding and 0.250"
[6.35 mm] of insulating covering edge (with optional
insulating covering)
Current Rating:
Maximum continuous operating current
based on a + 50 °C temperature rise
Operating Temperature:
- 55 °C to + 130 °C (no load),
- 55 °C to + 80 °C (at full rated current)
MECHANICAL SPECIFICATIONS
Terminals:
Extensions of the winding wire, solder coated to
within 0.063" [1.60 mm] of body
Mounting:
Center hole for mechanical mounting, insulated
bushings recommended for center hole mounting
DIMENSIONS
in inches [millimeters]
F
(2)
B
D Dia.
0.500 ± 0.062
[12.70 ± 1.57]
E
(1)
A Dia.
MODEL
IHB-1
IHB-2
IHB-3
IHB-4
IHB-5
IHB-6
A (MAX.)
0.660 [16.76]
0.825 [20.96]
1.100 [27.94]
1.600 [40.64]
1.600 [40.64]
2.000 [50.80]
B (MAX.)
0.840 [21.34]
0.840 [21.34]
0.840 [21.34]
1.030 [26.16]
1.450 [36.83]
1.500 [38.10]
D (MIN.)
0.115 [2.92]
0.115 [2.92]
0.115 [2.92]
0.175 [4.45]
0.175 [4.45]
0.240 [6.10]
Notes
(1)
E varies between components, see individual model specifications for details, tolerance of ± 0.035
(2)
F varies between components, see individual model specifications for details
STANDARD ELECTRICAL SPECIFICATIONS
MODEL
IHB-1
IHB-1
IHB-1
IHB-1
IHB-1
IHB-1
IHB-1
IHB-1
IHB-1
IHB-1
IHB-1
IHB-1
IHB-1
IHB-1
IHB-1
IHB-1
IHB-1
IHB-1
IHB-1
IHB-1
IND. AT 1 kHz
(μH)
1.0
1.2
1.5
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10
12
15
18
22
27
33
39
TOL.
(%)
± 20
± 20
± 20
± 20
± 20
± 20
± 20
± 20
± 20
± 20
± 20
± 20
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
DCR MAX.
()
0.003
0.003
0.004
0.004
0.005
0.005
0.005
0.006
0.007
0.007
0.008
0.009
0.010
0.011
0.015
0.016
0.020
0.030
0.040
0.046
RATED DC CURRENT
(A)
14.9
14.9
12.9
12.9
11.6
11.6
11.6
10.6
9.8
9.8
9.2
8.6
8.2
7.8
6.7
6.5
5.8
4.7
4.1
3.8
LEAD “E” SPACING
0.450 [11.43]
0.450 [11.43]
0.450 [11.43]
0.450 [11.43]
0.450 [11.43]
0.450 [11.43]
0.450 [11.43]
0.450 [11.43]
0.450 [11.43]
0.450 [11.43]
0.450 [11.43]
0.450 [11.43]
0.450 [11.43]
0.450 [11.43]
0.450 [11.43]
0.450 [11.43]
0.450 [11.43]
0.450 [11.43]
0.475 [12.07]
0.475 [12.07]
MAXIMUM LEAD “F”
DIAMETER
0.045 [1.15]
0.045 [1.15]
0.045 [1.15]
0.045 [1.15]
0.045 [1.15]
0.045 [1.15]
0.045 [1.15]
0.045 [1.15]
0.045 [1.15]
0.045 [1.15]
0.045 [1.15]
0.045 [1.15]
0.045 [1.15]
0.045 [1.15]
0.040 [1.02]
0.040 [1.02]
0.040 [1.02]
0.032 [0.812]
0.028 [0.723]
0.028 [0.723]
Revision: 26-Mar-14
Document Number: 34015
1
