CLD-DS89 Rev 6A
Product family data sheet
Cree
®
XLamp
®
CXA2590 LED
ProDuCt DEsCriPtion
The XLamp
®
CXA2590 LeD expands
Cree’s family of High Density (HD) LeD
arrays, featuring a 19-mm optical source
and enabling lighting manufacturers to
create a new generation of products
that delivers the same intensity and
light quality as up to 150-W ceramic
metal halide (CMH) at up to 50 percent
lower power. The new HD class of CXA
arrays provides unrivaled lumen density
that can reduce system cost for the
next generation of LeD spotlights.
The
CX Family LeD Design Guide
provides basic information on the
requirements to use the CXA2590 LeD
successfully in luminaire designs.
fEAturEs
•
Available in 4-step, 3-step and 2-step
easyWhite
®
bins at 2700 K, 3000 K,
3500 K, 4000 K and 5000 K and
4-step EasyWhite bins at 5700 K and
6500 K CCT
•
Available in ANSI white bins at
4000 K, 5000 K, 5700 K and 6500 K
CCT
•
Available in 70-, 80- and 93-minimum
CRI options
•
Forward voltage option: 72-v class
• 85 °C binning and characterization
• Maximum drive current: 1800 mA
• 115° viewing angle, uniform
chromaticity profile
•
Top-side solder connections
•
Thermocouple attach point
• NEMA SSL-3 2011 standard flux bins
•
RoHS and ReACh compliant
•
UL
®
recognized component
(e349212)
tAbLE of ContEnts
Characteristics ............................................2
Operating Limits ..........................................2
Flux Characteristics, easyWhite
®
Order
Codes and Bins ...........................................3
Flux Characteristics, ANSI White Order
Codes and Bins ...........................................5
Relative Spectral Power Distribution .........6
electrical Characteristics ............................6
Relative Luminous Flux ...............................7
Typical Spatial Distribution.........................8
Performance Groups - Brightness .............8
Performance Groups - Chromaticity ..........9
Cree easyWhite
®
Bins Plotted on the
1931 CIe Color Space .............................. 12
Cree ANSI White Bins Plotted on the
1931 CIe Color Space .............................. 12
Bin and Order Code Formats ................... 13
Mechanical Dimensions .......................... 13
Thermal Design ........................................ 14
Notes ........................................................ 15
Packaging ................................................. 16
WWW.CREE.Com/XLAmp
Copyright © 2014-2017 Cree, Inc. All rights reserved. The information in this document is subject to change without notice. Cree
®
, XLamp
®
and
EasyWhite
®
are registered trademarks and the Cree logo is a trademark of Cree, Inc. UL
®
and the UR logo are registered trademarks of UL LLC.
Cree, Inc.
4600 Silicon Drive
Durham, NC 27703
USA Tel: +1.919.313.5300
XLamp
®
CXa2590 LED
ChArACtEristiCs
Characteristics
viewing angle (FWHM)
eSD withstand voltage (HBM per Mil-Std-883D)
DC forward current
Reverse current
Forward voltage (@ 1200 mA, T
j
= 85 °C)
Forward voltage (@ 1200 mA, T
j
= 25 °C)
unit
degrees
v
mA
mA
v
v
69
80
Minimum
typical
115
8000
1800*
0.1
Maximum
*
Refer to the Operating Limits section.
oPErAting LiMits
The maximum current rating of the CXA2590 depends on the case temperature (Tc) when the LeD has reached thermal equilibrium under
steady-state operation. The graph shown below assumes that the system design employs good thermal management (thermal interface
material and heat sink) and may vary when poor thermal management is employed. Please refer to the Mechanical Dimensions section
on page 13 for the location of the Tc measurement point.
Another important factor in good thermal management is the temperature of the Light emitting Surface (LeS). Cree recommends a
maximum LES temperature of 135 °C to ensure optimal LED lifetime. Please refer to the Thermal Design section on page 14 for more
information on LeS temperature measurement.
CXA2590
2000
1800
1600
1400
1200
If (mA)
1000
800
600
400
200
0
0
25
50
75
100
125
150
Case Temperature (°C)
Copyright © 2014-2017 Cree, Inc. All rights reserved. The information in this document is subject to change without notice. Cree
®
, XLamp
®
and EasyWhite
®
are registered trademarks and the Cree logo is a
trademark of Cree, Inc. UL
®
and the UR logo are registered trademarks of UL LLC.
2
XLamp
®
CXa2590 LED
fLuX ChArACtEristiCs, EAsyWhitE
®
orDEr CoDEs AnD bins (i
f
= 1200 mA,
t
J
= 85 °C)
The following table provides order codes for XLamp CXA2590 LeDs. For a complete description of the order code nomenclature, please
see the Bin and Order Code Formats section (page 13).
Cri
Min
typ
Minimum Luminous flux
group
AD
70
6500 K
AB
80
---
AD
AD
70
5700 K
AB
80
---
AD
AD
70
5000 K
AB
80
---
AD
AD
70
4000 K
Z4
80
---
AB
Z2
80
3500 K
---
Z4
AB
X4
93
95
Y2
6430
6978
8500
7390
7945
8500
6010
9225
8020
8020
9225
6522
35H
35H
7945
8020
40H
75
BB
9500
10,310
9000
9000
9767
9767
40H
8500
9225
50H
75
BB
9500
10,310
9000
9000
9767
9767
50H
CXA2590-0000-
000R00AD50H
CXA2590-0000-
000R00BB50H
CXA2590-0000-
000R0HAB50H
CXA2590-0000-
000R0HAD50H
CXA2590-0000-
000R00AD40H
CXA2590-0000-
000R00BB40H
CXA2590-0000-
000R0HZ440H
CXA2590-0000-
000R0HAB40H
CXA2590-0000-
000R00Z235H
CXA2590-0000-
000R00Z435H
CXA2590-0000-
000R00AB35H
CXA2590-0000-
000R0YX435H
CXA2590-0000-
000R0YY235H
35G
CXA2590-0000-
000R0HZ440G
CXA2590-0000-
000R0HAB40G
CXA2590-0000-
000R00Z235G
CXA2590-0000-
000R00Z435G
CXA2590-0000-
000R00AB35G
CXA2590-0000-
000R0YX435G
CXA2590-0000-
000R0YY235G
35F
CXA2590-0000-
000R0HAB50G
CXA2590-0000-
000R0HAD50G
8500
9225
57F
75
BB
9500
10,310
9000
9000
9767
9767
57F
8500
9225
65F
75
BB
9500
10,310
Flux (lm)
@ 85 °C
9000
Flux (lm)
@ 25 °C*
9767
65F
group
2-step
order Code
group
3-step
order Code
group
4-step
order Code
CXA2590-0000-
000R00AD65F
CXA2590-0000-
000R00BB65F
CXA2590-0000-
000R0HAB65F
CXA2590-0000-
000R0HAD65F
CXA2590-0000-
000R00AD57F
CXA2590-0000-
000R00BB57F
CXA2590-0000-
000R0HAB57F
CXA2590-0000-
000R0HAD57F
CXA2590-0000-
000R00AD50F
CXA2590-0000-
000R00BB50F
CXA2590-0000-
000R0HAB50F
CXA2590-0000-
000R0HAD50F
CXA2590-0000-
000R00AD40F
CXA2590-0000-
000R00BB40F
CXA2590-0000-
000R0HZ440F
CXA2590-0000-
000R0HAB40F
CXA2590-0000-
000R00Z235F
CXA2590-0000-
000R00Z435F
CXA2590-0000-
000R00AB35F
CXA2590-0000-
000R0YX435F
CXA2590-0000-
000R0YY235F
nominal
CCt
50F
50G
50F
40F
40G
40F
35G
35F
Notes
•
Cree maintains a tolerance of ±7% on flux and power measurements, ±0.005 on chromaticity (CCx, CCy) measurements and a tolerance of ±2 on CRI
measurements. See the Measurements section (page 15).
•
Cree XLamp CXA2590 LED order codes specify only a minimum flux bin and not a maximum. Cree may ship reels in flux bins higher than the minimum
specified by the order code without advance notice. Shipments will always adhere to the chromaticity bin restrictions specified by the order code.
*
Flux values @ 25 °C are calculated and for reference only.
Copyright © 2014-2017 Cree, Inc. All rights reserved. The information in this document is subject to change without notice. Cree
®
, XLamp
®
and EasyWhite
®
are registered trademarks and the Cree logo is a
trademark of Cree, Inc. UL
®
and the UR logo are registered trademarks of UL LLC.
3
XLamp
®
CXa2590 LED
fLuX ChArACtEristiCs, EAsyWhitE
®
orDEr CoDEs AnD bins (i
f
= 1200 mA,
t
J
= 85 °C) - Continued
nominal
CCt
Cri
Min
typ
Minimum Luminous flux
group
Y4
80
3000 K
---
Z2
Z4
X2
93
95
X4
Y4
80
2700 K
---
Z2
Z4
W4
93
95
X2
5590
6067
6010
6910
7390
7945
5225
6522
7499
8020
8622
5671
27H
27H
Flux (lm)
@ 85 °C
6910
7390
7945
5590
Flux (lm)
@ 25 °C*
7499
8020
8622
6067
30H
30H
group
2-step
order Code
CXA2590-0000-
000R00Y430H
CXA2590-0000-
000R00Z230H
CXA2590-0000-
000R00Z430H
CXA2590-0000-
000R0YX230H
CXA2590-0000-
000R0YX430H
CXA2590-0000-
000R00Y427H
CXA2590-0000-
000R00Z227H
CXA2590-0000-
000R00Z427H
CXA2590-0000-
000R0YW427H
CXA2590-0000-
000R0YX227H
27G
30G
group
3-step
order Code
CXA2590-0000-
000R00Y430G
CXA2590-0000-
000R00Z230G
CXA2590-0000-
000R00Z430G
CXA2590-0000-
000R0YX230G
CXA2590-0000-
000R0YX430G
CXA2590-0000-
000R00Y427G
CXA2590-0000-
000R00Z227G
CXA2590-0000-
000R00Z427G
CXA2590-0000-
000R0YW427G
CXA2590-0000-
000R0YX227G
27F
30F
group
4-step
order Code
CXA2590-0000-
000R00Y430F
CXA2590-0000-
000R00Z230F
CXA2590-0000-
000R00Z430F
CXA2590-0000-
000R0YX230F
CXA2590-0000-
000R0YX430F
CXA2590-0000-
000R00Y427F
CXA2590-0000-
000R00Z227F
CXA2590-0000-
000R00Z427F
CXA2590-0000-
000R0YW427F
CXA2590-0000-
000R0YX227F
30G
30F
27G
27F
Notes
•
Cree maintains a tolerance of ±7% on flux and power measurements, ±0.005 on chromaticity (CCx, CCy) measurements and a tolerance of ±2 on CRI
measurements. See the Measurements section (page 15).
•
Cree XLamp CXA2590 LED order codes specify only a minimum flux bin and not a maximum. Cree may ship reels in flux bins higher than the minimum
specified by the order code without advance notice. Shipments will always adhere to the chromaticity bin restrictions specified by the order code.
*
Flux values @ 25 °C are calculated and for reference only.
Copyright © 2014-2017 Cree, Inc. All rights reserved. The information in this document is subject to change without notice. Cree
®
, XLamp
®
and EasyWhite
®
are registered trademarks and the Cree logo is a
trademark of Cree, Inc. UL
®
and the UR logo are registered trademarks of UL LLC.
4
XLamp
®
CXa2590 LED
fLuX ChArACtEristiCs, Ansi WhitE orDEr CoDEs AnD bins (i
f
= 1200 mA,
t
J
= 85 °C)
The following table provides order codes for XLamp CXA2590 LeDs. For a complete description of the order code nomenclature, please
see the Bin and Order Code Formats section (page 13).
Cri
Min
70
6500 K
80
---
typ
75
group
AD
BB
AB
AD
AD
BB
AB
AD
AD
BB
AB
AD
AD
BB
Minimum Luminous flux
Flux (lm)
@ 85 °C
9000
9500
8500
9000
9000
9500
8500
9000
9000
9500
8500
9000
9000
9500
Flux (lm)
@ 25 °C*
9767
10,310
9225
9767
9767
10,310
9225
9767
9767
10,310
9225
9767
9767
10,310
Chromaticity regions
order Code
CXA2590-0000-000R00AD0e1
CXA2590-0000-000R00BB0e1
CXA2590-0000-000R0HAB0e1
CXA2590-0000-000R0HAD0e1
CXA2590-0000-000R00AD0e2
CXA2590-0000-000R00BB0e2
CXA2590-0000-000R0HAB0e2
CXA2590-0000-000R0HAD0e2
CXA2590-0000-000R00AD0e3
CXA2590-0000-000R00BB0e3
CXA2590-0000-000R0HAB0e3
CXA2590-0000-000R0HAD0e3
CXA2590-0000-000R00AD0e5
CXA2590-0000-000R00BB0e5
nominal
CCt
1A0, 1B0, 1C0, 1D0, 65F
1A0, 1B0, 1C0, 1D0, 65F
70
5700 K
80
75
2A0, 2B0, 2C0, 2D0, 57F
---
2A0, 2B0, 2C0, 2D0, 57F
70
5000 K
80
75
3A0, 3B0, 3C0, 3D0, 50F
---
3A0, 3B0, 3C0, 3D0, 50F
4000 K
70
75
5A0, 5B0, 5C0, 5D0, 40F
Notes
•
Cree maintains a tolerance of ±7% on flux and power measurements, ±0.005 on chromaticity (CCx, CCy) measurements and a tolerance of ±2 on CRI
measurements. See the Measurements section (page 15).
•
Cree XLamp CXA2590 LED order codes specify only a minimum flux bin and not a maximum. Cree may ship reels in flux bins higher than the minimum
specified by the order code without advance notice. Shipments will always adhere to the chromaticity bin restrictions specified by the order code.
*
Flux values @ 25 °C are calculated and for reference only.
Copyright © 2014-2017 Cree, Inc. All rights reserved. The information in this document is subject to change without notice. Cree
®
, XLamp
®
and EasyWhite
®
are registered trademarks and the Cree logo is a
trademark of Cree, Inc. UL
®
and the UR logo are registered trademarks of UL LLC.
5
京公网安备 11010802033920号
EEWORLD
