1954155: DescriptionPluggable Terminal Blocks ZEC 1,0/ 8-ST-3,5 C1 R1,8BD1-8; CategoryThe connector; File Size79KB，3 Pages; ManufacturerPHOENIX CONTACT; Websitehttps://www.phoenixcontact.com; Environmental Compliance

Download Datasheet Parametric View All

1954155 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	1954155	-	-	View	Buy Now

1954155 Overview

Pluggable Terminal Blocks ZEC 1,0/ 8-ST-3,5 C1 R1,8BD1-8

1954155 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	PHOENIX CONTACT
Reach Compliance Code	compliant
Terminal and terminal strip types	BARRIER STRIP TERMINAL BLOCK

Preview

Download Datasheet

View All

https://www.phoenixcontact.com/hq/products/1954155

Printed-circuit board connector - ZEC 1,0/ 8-ST-3,5 C1

R1,8BD1-8 - 1954155

Please be informed that the data shown in this PDF Document is generated from our Online Catalog. Please find the complete data in the user's

documentation. Our General Terms of Use for Downloads are valid

(http://phoenixcontact.com/download)

Plug component, Nominal current: 8 A, Number of positions: 8, Pitch: 3.5 mm, Connection method: Spring-

cage connection, Color: green, Contact surface: Tin, Mounting: Direct plug-in method

Key Commercial Data

Packing unit

GTIN

Custom tariff number

Note

4017918896386

85366990

Made to Order (non-returnable)

50 STK

Technical data

Dimensions

Pitch

Dimension a

3.50 mm

24.5 mm

General

Range of articles

Type of contact

Number of positions

Connection method

Rated voltage (III/3)

Connection in acc. with standard

Nominal current I

Nominal cross section

ZEC 1,0/..-ST

Female connector

Spring-cage connection

160 V

EN-VDE

1 mm²

Connection data

Conductor cross section solid min.

Conductor cross section solid max.

Conductor cross section flexible min.

Conductor cross section flexible max.

Conductor cross section flexible, with ferrule without plastic sleeve min.

0.2 mm²

1 mm²

0.2 mm²

1 mm²

0.25 mm²

Conductor cross section flexible, with ferrule without plastic sleeve max. 1 mm²

11/14/2016 Page 1 / 3
