DDZ9690Q-7 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Discrete semiconductor> diode> DDZ9690Q-7

DDZ9690Q-7: DescriptionZener Diodes 500mW 3.3Vz 0.05mA 2uA Zener Diode; CategoryDiscrete semiconductor diode; File Size431KB，7 Pages; ManufacturerDiodes Incorporated; Environmental Compliance

Download Datasheet Parametric Compare View All

DDZ9690Q-7 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	DDZ9690Q-7	-	-	View	Buy Now

DDZ9690Q-7 Overview

Zener Diodes 500mW 3.3Vz 0.05mA 2uA Zener Diode

DDZ9690Q-7 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	Diodes Incorporated
package instruction	R-PDSO-G2
Reach Compliance Code	compliant
ECCN code	EAR99
Factory Lead Time	16 weeks
Other features	HIGH RELIABILITY
Configuration	SINGLE
Diode component materials	SILICON
Diode type	ZENER DIODE
Maximum forward voltage (VF)	0.9 V
JESD-30 code	R-PDSO-G2
JESD-609 code	e3
Humidity sensitivity level	1
Number of components	1
Number of terminals	2
Maximum operating temperature	150 °C
Minimum operating temperature	-65 °C
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Peak Reflow Temperature (Celsius)	260
polarity	UNIDIRECTIONAL
Maximum power dissipation	0.5 W
Guideline	AEC-Q101
Nominal reference voltage	5.6 V
Maximum reverse current	2 µA
Reverse test voltage	4 V
surface mount	YES
technology	ZENER
Terminal surface	Matte Tin (Sn)
Terminal form	GULL WING
Terminal location	DUAL
Maximum time at peak reflow temperature	30
Maximum voltage tolerance	5%
Working test current	0.05 mA
Base Number Matches	1

Preview

Download Datasheet

View All

DDZ9678 - DDZ9717

SURFACE MOUNT LOW CURRENT ZENER DIODE

Features



500mW Power Dissipation on FR-4 PCB at T

= +75°C

Specified at a Low Test Current (50µA), Ideal For Low Bias and

Portable Battery-Powered Applications

Ideally Suited for Automated Assembly Processes

Totally Lead-Free & Fully RoHS Compliant (Notes 1 & 2)

Halogen and Antimony Free. “Green” Device (Note 3)

Qualified to AEC-Q101 Standards for High Reliability

PPAP Capable (Note 4)

Mechanical Data



Case: SOD123

Case Material: Molded Plastic.

UL Flammability Classification Rating 94V-0

Moisture Sensitivity: Level 1 per J-STD-020

Terminal Connections: Cathode Band

Terminals: Finish - Matte Tin Annealed over Alloy 42 Leadframe.

Solderable per MIL-STD-202, Method 208

Weight: 0.01 grams (Approximate)

SOD123

Top View

Ordering Information

(Note 5)

Part Number

(Type Number)-7*

(Type Number)Q-7*

(Type Number)Q-13*

Notes:

Compliance

Standard

Automotive

Case

SOD123

Packaging

3,000/Tape & Reel

10,000/Tape & Reel

* Refer to the Electrical Characteristics Table for Type Number

1. No purposely added lead. Fully EU Directive 2002/95/EC (RoHS) & 2011/65/EU (RoHS 2) compliant.

2. See http://www.diodes.com/quality/lead_free.html for more information about Diodes Incorporated’s definitions of Halogen- and Antimony-free, "Green"

and Lead-free.

3. Halogen- and Antimony-free "Green” products are defined as those which contain <900ppm bromine, <900ppm chlorine (<1500ppm total Br + Cl) and

<1000ppm antimony compounds.

4. Automotive products are AEC-Q101 qualified and are PPAP capable. Automotive, AEC-Q101 and standard products are electrically and thermally the

same, except where specified. For more information, please refer to http://www.diodes.com/quality/product_compliance_definitions/.

5. For packaging details, go to our website at http://www.diodes.com/products/packages.html.

Marking Information

xx = Product Type Marking Code -

(See Electrical Characteristics Table)

YM = Date Code Marking

Y = Year (ex: E = 2017)

M = Month (ex: 9 = September)

Date Code Key

Year

2008

Code

Month

Code

2009

Jan

2010

Feb

2011

Mar

2012

Apr

2013

May

2014

Jun

2015

Jul

2016

Aug

2017

Sep

2018

Oct

2019

Nov

2020

Dec

DDZ9678 - DDZ9717

Document number: DS30410 Rev. 16 - 2

1 of 7

www.diodes.com

September 2017
