RoHS Compliant
ALUMINIUM ELECTROLYTIC CAPACITOR
FEATURES
◆
◆
◆
Safety vent construction design
Load life of 5000 hours at 105°C
For electronic ballast circuits, switching power supply, automotive and other
long life required applications
HL Series
OUTLINE
mm
D
F
d
10
5.0
0.6
13
16
7.5
0.8
18
SPECIFICATIONS
Items
Capacitance Tolerance
(120Hz, 25°C)
Rated Working Voltage Range
Operation Temperature
160 ~ 400Vdc
-40°C ~ +105°C
Characteristics
±
20% (M)
450Vdc
-40°C ~ +105°C
(After 2 minutes applying the DC working voltage)
Leakage Current (25°C)
◆
I
≤
0.06CV + 10 (u A)
I : Leakage Current (u A)
W.V.
◆
C : Rated Capacitance (u F)
160
200
160
0.15
160
3
6
200
250
200
0.15
200
3
6
250
300
250
0.15
250
3
6
◆
V : Working Voltage (V)
350
400
350
0.20
350
5
6
400
450
400
0.24
400
5
6
450
500
450
0.24
450
6
-
Surge Voltage (25°C)
S.V.
W.V.
Dissipation Factor (120Hz, 25°C)
tan
δ
W.V.
- 25°C / + 25°C
Temperature Characteristics
- 40°C / + 25°C
◆
Impedance ratio at 120Hz
After 5000 hours application of WV at +105°C, the capacitor shall meet the following limits:
Capacitance Change
Load Test
tan
δ
Leakage Current
≤ ±
20% of initial value
≤
200% of initial specified value
≤
initial specified value
After 1000 hours, no voltage applied at +105°C, the capacitor shall meet the following limits:
Capacitance Change
Shelf Test
tan
δ
Leakage Current
≤ ±
25% of initial value
≤
200% of initial specified value
≤
200% of initial specified value
DIMENSIONS
WV
uF
3.3
4.7
10
22
33
47
68
100
150
220
330
10 x 20
10 x 20
13 x 20
13 x 25
16 x 26
16 x 31
16 x 31
18 x 31
]
10 x 20
13 x 20
13 x 20
13 x 25
16 x 26
16 x 35
18 x 31
10 x 20
13 x 20
13 x 20
13 x 25
16 x 26
16 x 31
18 x 31
18 x 41
10 x 20
13 x 20
13 x 25
16 x 26
16 x 31
18 x 31
160
200
250
350
400
]
]
10 x 20
13 x 25
16 x 26
16 x 31
18 x 35
18 x 41
D x L (mm)
450
10 x 20
13 x 20
13 x 20
16 x 26
16 x 31
18 x 31
18 x 41
PERMISSIBLE RIPPLE CURRENT
WV
uF
3.3
4.7
10
22
33
47
68
100
150
220
330
160
190
265
355
475
637
750
960
1.52
1.30
0.93
0.61
0.28
0.22
0.22
0.22
160
210
265
355
475
650
780
]
1.52
0.98
0.93
0.61
0.28
0.22
0.22
105
165
210
282
385
520
645
820
3.50
2.40
1.90
1.70
0.79
0.64
0.44
0.35
100
165
230
313
410
530
Item
RC
160
Imp
RC
200
Imp
RC
250
Imp
RC
RC: mA (rms) at 120Hz 105°C
Imp: mΩ (ohm) at 100KHz 25°C
350
Imp
RC
400
Imp
]
]
3.00
2.10
1.00
0.74
0.49
0.40
105
185
230
300
420
545
2.90
1.32
0.95
0.75
0.49
0.36
RC
60
80
110
200
275
340
460
450
Imp
6.50
3.60
3.00
1.75
1.20
0.96
0.80
