Features
n
RoHS compliant*
*R
oH
S
CO
R30
0
LE
AD
F
RE
E
n
Values from 0.02 to 9.10 ohms
n
Tolerance of 1 % or 5 %
n
Five package sizes available
n
Tape and reel packaging
CRL Series - Low Value Chip Resistors
Electrical Characteristics
Characteristic
Power Rating @ 70 °C
Operating Temperature Range
Derated to Zero Load at
Maximum Working Voltage
Resistance Range 1 %
R ≥ 0.10 Ω: E24 Series
R < 0.10 Ω: See Value Table
Resistance Range 5 %*
R ≥ 0.10 Ω: E24 Series
R < 0.10 Ω: See Value Table
Temperature Coefficient
0.05 Ω ≤ R ≤ 9.1 Ω
0.02 Ω < R <0.05 Ω
R = 0.02 Ω
(PR)
1/2
Model CRL0603
0.100 watt
Ro VE LEA
HS RS D
C ION FRE
OM S E
PL AR
IA E
NT
*
Model CRL0805
0.125 watt
Model CRL1206
0.250 watt
-55 to +125 °C
+125 °C
Model CRL2010
0.50 watt
Model CRL2512
1.00 watt
(PR)
1/2
(PR)
1/2
0.02 to 9.10
W
(PR)
1/2
0.02 to 9.10
W
(PR)
1/2
0.02 to 9.10
W
0.10 to 9.10
W
0.05 to 9.10
W
0.10 to 0.91
W
0.05 to 0.91
W
0.02 to 0.91
W
0.02 to 0.91
W
0.02 to 0.91
W
±200 PPM/°C
±400 PPM/°C
±600 PPM/°C
* For 5 % tolerance and resistance value ≥ 1 ohm, please see Bourns
®
Model CR Series.
Value Table
Value
(W)
0.020
0.022
0.024
0.027
0.030
0.033
0.036
0.039
0.040
0.043
0.047
0.050
0.051
0.056
0.060
0.062
0.068
0.070
0.075
0.080
0.082
0.090
0.091
CRL0603
1 %
Not Available
Not Available
Not Available
Not Available
Not Available
Not Available
Not Available
Not Available
Not Available
Not Available
Not Available
Not Available
Not Available
Not Available
Not Available
Not Available
Not Available
Not Available
Not Available
Not Available
Not Available
Not Available
Not Available
CRL0603
5 %
Not Available
Not Available
Not Available
Not Available
Not Available
Not Available
Not Available
Not Available
Not Available
Not Available
Not Available
Not Available
Not Available
Not Available
Not Available
Not Available
Not Available
Not Available
Not Available
Not Available
Not Available
Not Available
Not Available
CRL0805
1 %
Not Available
Not Available
Not Available
Not Available
Not Available
Not Available
Not Available
Not Available
Not Available
Not Available
Not Available
A
A
A
A
A
A
A
A
A
A
A
A
CRL0805
5 %
Not Available
Not Available
Not Available
Not Available
Not Available
Not Available
Not Available
Not Available
Not Available
Not Available
Not Available
A
A
A
A
A
A
A
A
A
A
A
A
CRL1206
1 %
A
A
A
A
A
A
A
A
A
A
A
P
A
A
A
A
A
A
A
A
A
A
A
CRL1206
5 %
A
A
A
A
A
A
A
A
A
A
A
P
A
A
A
A
A
A
A
A
A
A
A
CRL2010
1 %
P
A
A
A
P
A
A
A
P
A
A
P
A
A
A
A
A
A
A
A
A
A
A
CRL2010
5 %
P
A
A
A
P
A
A
A
P
A
A
P
A
A
A
A
A
A
A
A
A
A
A
CRL2512
1 %
P
A
A
A
P
A
A
A
P
A
A
P
A
A
A
A
A
A
A
A
A
A
A
CRL2512
5 %
P
A
A
A
P
A
A
A
P
A
A
P
A
A
A
A
A
A
A
A
A
A
A
P = Popular Value
A = Available Value (may have greater minimum order quantity)
*RoHS Directive 2002/95/EC Jan. 27, 2003 including annex and RoHS Recast 2011/65/EU June 8, 2011.
Specifications are subject to change without notice.
The device characteristics and parameters in this data sheet can and do vary in different applications and actual device performance may vary over time.
Users should verify actual device performance in their specific applications.
3312 - 2 mm SMD Trimming Potentiometer
CRL Series - Low Value Chip Resistors
Environmental Characteristics
Description
Short Time Overload
Load Life
Resistance to
Soldering Heat
Thermal Shock
2.5 x (PR) for 5 seconds.
(IEC 115-1 4.13)
1/2
Method
Limit
1 % Tolerance:
DR ≤
±(1 % + 0.001
W)
5 % Tolerance:
DR ≤
±(2 % + 0.001
W)
1 % Tolerance:
DR ≤
±(1 % + 0.001
W)
5 % Tolerance:
DR ≤
±(2 % + 0.001
W)
1 % Tolerance:
DR ≤
±(0.5 % + 0.001
W)
5 % Tolerance:
DR ≤
±(1 % + 0.001
W)
1 % Tolerance:
DR ≤
±(0.5 % + 0.001
W)
5 % Tolerance:
DR ≤
±(1 % + 0.001
W)
(PR)
1/2
for 1000 hours; 1.5 hours on; 0.5 hours off.
(IEC 115-1 4.25.1)
260 °C for 10 seconds.
(IEC 115-1 4.18)
5 cycles from -55 °C to +125 °C, 30 minutes at temperature.
(IEC 115-1 4.19)
Chip Dimensions
Dimension
L
W
H
I1
I2
Dimensional Drawings
Dimensional Drawing
I
1
I
1
Model
CRL0603
1.60 ± 0.10
(0.063 ± 0.004)
0.80 ± 0.10
(0.031 ± 0.004)
0.45 ± 0.10
(0.018 ± 0.004)
0.30 ± 0.20
(0.012 ± 0.008)
0.30 ± 0.20
(0.012 ± 0.008)
Model
CRL0805
2.00 ± 0.15
(0.079 ± 0.006)
1.25 ± 0.10
(0.049 ± 0.004)
0.50 ± 0.10
(0.020 ± 0.004)
0.40 ± 0.20
(0.016 ± 0.008)
0.40 ± 0.20
(0.016 ± 0.008)
Model
CRL1206
3.20 ± 0.15
(0.126 ± 0.006)
1.60 ± 0.15
(0.063 ± 0.006)
0.60 ± 0.10
(0.024 ± 0.004)
0.50 ± 0.25
(0.020 ± 0.010)
0.50 ± 0.25
(0.020 ± 0.010)
Model
CRL2010
5.00 ± 0.20
(0.197 ± 0.008)
2.50 ± 0.20
(0.098 ± 0.008)
0.60 ± 0.10
(0.024 ± 0.004)
0.60 ± 0.25
(0.024 ± 0.010)
0.60 ± 0.25
(0.024 ± 0.010)
Model
CRL2512
6.30 ± 0.20
(0.248 ± 0.008)
3.10 ± 0.20
(0.122 ± 0.008)
0.60 ± 0.10
(0.024 ± 0.004)
0.60 ± 0.25
(0.024 ± 0.010)
0.60 ± 0.20
(0.024 ± 0.008)
How to Order
CRL 0603 - F W - R090 E LF
H
I2
L
I2
W
DIMENSIONS:
MM
(INCHES)
Derating Curve
Rated power in percentage (%)
100
80
60
40
20
0
-55
0
70
125
Model
(CRL = Chip Resistor Low Value)
Size
• 0603
• 0805
• 1206
• 2010
• 2512
Resistance Tolerance
F = ±1 %
J = ±5 %
TCR (PPM/°C)
W = ±200 (0.05 Ω ≤ R ≤ 9.1 Ω)
V = ±400 (0.02 Ω < R <0.05 Ω)
U = ±600 (0.02 Ω)
Resistance Value (1 % or 5 %)
• R stands for decimal point. Three significant digits: (R090 = 0.09
W;
9R10 = 9.10
W)
Packaging
• CRL0603, CRL0805, CRL1206: E = Paper Tape, Plastic Reel, 5,000 pcs.
• CRL2010, CRL2512: E = Embossed Plastic Tape, Plastic Reel, 4,000 pcs.
Termination
LF = Tin-plated (RoHS compliant)
(°C) Ambient temperature
Specifications are subject to change without notice.
The device characteristics and parameters in this data sheet can and do vary in different applications and actual device performance may vary over time.
Users should verify actual device performance in their specific applications.
3312 - 2 mm SMD Trimming Potentiometer
CRL Series - Low Value Chip Resistors
Packaging Dimensions - Tape
Dimension
A
B
W
F
P0
Model
CRL0603
1.10 ± 0.10
(0.043 ± 0.004)
1.90 ± 0.10
(0.075 ± 0.004)
8.00 ± 0.20
(0.315 ± 0.008)
3.50 ± 0.05
(0.138 ± 0.002)
4.00 ± 0.10
(0.157 ± 0.004)
Model
CRL0805
1.65 +0.20 / -0.10
(0.065 +0.008 / -.004)
2.40 +0.20 / -0.10
(0.094 +0.008 / -.004)
8.00 ± 0.20
(0.315 ± 0.008)
3.50 ± 0.05
(0.138 ± 0.002)
4.00 ± 0.10
(0.157 ± 0.004)
Model
CRL1206
1.95 +0.10 / -0.05
(0.077 +0.004 / -.002)
3.50 ± 0.10
(0.138 ± 0.004)
8.00 ± 0.20
(0.315 ± 0.008)
3.50 ± 0.05
(0.138 ± 0.002)
4.00 ± 0.10
(0.157 ± 0.004)
Model
CRL2010
2.80 ± 0.20
(0.110 ± 0.008)
5.50 ± 0.20
(0.217 ± 0.008)
12.0 ± 0.30
(0.472 ± 0.012)
5.50 ± 0.05
(0.217 ± 0.002)
4.00 ± 0.10
(0.157 ± 0.004)
Model
CRL2512
3.50 ± 0.20
(0.138 ± 0.008)
6.70 ± 0.20
(0.264 ± 0.008)
12.00 ± 0.30
(0.472 ± 0.012)
5.50 ± 0.05
(0.217 ± 0.002)
4.00 ± 0.10
(0.157 ± 0.004)
Packaging Dimensions - Reel
Dimension
N
D
T
Model
CRL0603
80.00 ± 1.00
(3.150 ± 0.040)
20.50
(0.807)
10.00 ± 1.50
(0.394 ± 0.059)
4.0 ± 0.1
(.157 ± .004)
A
B
F
W
13.0 ± 0.5
(0.512 ± .020)
N
P0
1.5 +0.1/-0
(.056 + .004/-0)
1.75 ± 0.1
(.059 ± .004)
2.0 ± 0.5
(.080 ± .020)
2.0 ± 0.05
(.079 ± .002)
Model
CRL0805
80.00 ± 1.00
(3.150 ± 0.040)
20.50
(0.807)
10.00 ± 1.50
(0.394 ± 0.059)
Model
CRL1206
80.00 ± 1.00
(3.150 ± 0.040)
20.50
(0.807)
10.00 ± 1.50
(0.394 ± 0.059)
Model
CRL2010
80.00 ± 0.20
(3.150 ± 0.008)
20.00
MIN.
(0.787)
16.70 MAX.
(0.657)
Model
CRL2512
80.00 ± 0.20
(3.150 ± 0.008)
20.00
MIN.
(0.787)
16.70 MAX.
(0.657)
DIMENSIONS:
MM
(INCHES)
D
178.0 ± 2.0
(7.008 ± .080)
T
REV. 11/15
Specifications are subject to change without notice.
The device characteristics and parameters in this data sheet can and do vary in different applications and actual device performance may vary over time.
Users should verify actual device performance in their specific applications.
