Interface Modules
Diode modules & component carriers
INTERFACES
DM Diode Module
35 or 32 mm DIN Rail Mount
Technical Information
Diode
Rated Current
1N4007 or equivalent
1A
1N5408 or equivalent
3A
P600M or equivalent
6A
Maximum Blocking Voltage - 1000V DC
Rated Bus Current: 10A
(12A at 30˚C (86˚F) Temperature Rise)
Wire Range ...........0.5-4 mm
2
; 22-12 AWG
Voltage ..................250V AC
Torque ...................0.5-4 Nm / 4 lbs-in.
Stripping Length ...8 mm
TS35x7.5 56mm (2.21 in.)
TS32x15 61mm (2.40 in.)
L
87
m
m
3
.4
(3
.)
in
SCREW CLAMP *
1 AMP
Part Number
8971.2
5702.2
5703.2
8973.2
8974.2
8975.2
8842.2
5704.2
5705.2
8850.2
5706.2
5707.2
3 AMP
Part Number
8971.3
5702.3
5703.3
8973.3
8974.3
8975.3
8842.3
5704.3
5705.3
8850.3
5706.3
5707.3
6 AMP
Part Number
8971.4
5702.4
5703.4
8973.4
8974.4
8975.4
8842.4
5704.4
5705.4
8850.4
5706.4
5707.4
Type
DM4-S
DM8-S
DM12-S
DM16-S
DM20-S
DM24-S
DM6-A-S
DM14-A-S
DM22-A-S
DM6-K-S
DM14-K-S
DM22-K-S
Type
DM4-S3
DM8-S3
DM12-S3
DM16-S3
DM20-S3
DM24-S3
DM6-A-S3
DM14-A-S3
DM22-A-S3
DM6-K-S3
DM14-K-S3
DM22-K-S3
Type
DM4-S6
DM8-S6
DM12-S6
DM16-S6
DM20-S6
DM24-S6
DM6-A-S6
DM14-A-S6
DM22-A-S6
DM6-K-S6
DM14-K-S6
DM22-K-S6
Ordering Information
Series Connection, 1A diodes
Series Connection, 1A diodes
Series Connection, 1A diodes
Series Connection, 1A diodes
Series Connection, 1A diodes
Series Connection, 1A diodes
Bussed Anodes, 1A diodes
Bussed Anodes, 1A diodes
Bussed Anodes, 1A diodes
Bussed Cathodes, 1A diodes
Bussed Cathodes, 1A diodes
Bussed Cathodes, 1A diodes
Ordering Information
Series Connection, 3A diodes
Series Connection, 3A diodes
Series Connection, 3A diodes
Series Connection, 3A diodes
Series Connection, 3A diodes
Series Connection, 3A diodes
Bussed Anodes, 3A diodes
Bussed Anodes, 3A diodes
Bussed Anodes, 3A diodes
Bussed Cathodes, 3A diodes
Bussed Cathodes, 3A diodes
Bussed Cathodes, 3A diodes
Ordering Information
Series Connection, 6A diodes
Series Connection, 6A diodes
Series Connection, 6A diodes
Series Connection, 6A diodes
Series Connection, 6A diodes
Series Connection, 6A diodes
Bussed Anodes, 6A diodes
Bussed Anodes, 6A diodes
Bussed Anodes, 6A diodes
Bussed Cathodes, 6A diodes
Bussed Cathodes, 6A diodes
Bussed Cathodes, 6A diodes
No. of Diodes
4
8
12
16
20
24
6
14
22
6
14
22
No. of Diodes
4
8
12
16
20
24
6
14
22
6
14
22
No. of Diodes
4
8
12
16
20
24
6
14
22
6
14
22
Diode
1N4007
1N4007
1N4007
1N4007
1N4007
1N4007
1N4007
1N4007
1N4007
1N4007
1N4007
1N4007
Diode
1N5408
1N5408
1N5408
1N5408
1N5408
1N5408
1N5408
1N5408
1N5408
1N5408
1N5408
1N5408
Diode
P600M
P600M
P600M
P600M
P600M
P600M
P600M
P600M
P600M
P600M
P600M
P600M
Module Length (L)
in mm(in.)
24 (0.95)
44 (1.73)
64 (2.52)
92 (3.62)
112 (4.41)
132 (5.20)
30 (1.18)
50 (1.97)
70 (2.75)
30 (1.18)
50 (1.97)
70 (2.75)
Module Length (L)
in mm(in.)
24 (0.95)
44 (1.73)
64 (2.52)
92 (3.62)
112 (4.41)
132 (5.20)
30 (1.18)
50 (1.97)
70 (2.75)
30 (1.18)
50 (1.97)
70 (2.75)
Module Length (L)
in mm(in.)
24 (0.95)
44 (1.73)
64 (2.52)
92 (3.62)
112 (4.41)
132 (5.20)
30 (1.18)
50 (1.97)
70 (2.75)
30 (1.18)
50 (1.97)
70 (2.75)
Std. Pk.
1
1
1
1
1
1
1
1
1
1
1
1
Std. Pk.
1
1
1
1
1
1
1
1
1
1
1
1
Std. Pk.
1
1
1
1
1
1
1
1
1
1
1
1
Figure
A
A
A
A
A
A
B
B
B
C
C
C
Figure
A
A
A
A
A
A
B
B
B
C
C
C
Figure
A
A
A
A
A
A
B
B
B
C
C
C
Figure A
Figure B
Figure C
* Spring Terminal is available; add suffix S to end of part number. Example: Part Number 8971.2/S for Spring Terminal.
Altech Corp.
®
• 35 Royal Road • Flemington, NJ 08822-6000 • Phone (908)806-9400 • FAX (908)806-9490 • www.altechcorp.com
DATA SUBJECT TO CHANGE WITHOUT NOTICE
