This document was generated on 02/19/2018
PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
Part Number:
Status:
Overview:
Description:
1722533111
Active
Ultra-Fit Power Connectors
Ultra-Fit Crimp Terminal, Female, 0.38µm Gold (Au) Plating, 20-22 AWG
Documents:
Drawing (PDF)
Product Specification 1723230001-TS-000 (PDF)
Product Specification PS-172323-0001-001 (PDF)
General
Product Family
Series
Application
Comments
Crimp Quality Equipment
Overview
Product Literature Order No
Product Name
UPC
Physical
Durability (mating cycles max)
Gender
Material - Metal
Material - Plating Mating
Material - Plating Termination
Net Weight
Packaging Type
Plating min - Mating
Plating min - Termination
Termination Interface: Style
Wire Insulation Diameter
Wire Size AWG
Wire Size mm²
Electrical
Current - Maximum per Contact
Voltage - Maximum
Solder Process Data
Lead-freeProcess Capability
Material Info
Reference - Drawing Numbers
Application Specification
Product Specification
Sales Drawing
Application Specification AS-172323-0001-001 (PDF)
RoHS Certificate of Compliance (PDF)
Product Literature (PDF)
Series image - Reference only
Crimp Terminals
172253
Power
See Product Specification for maximum current rating by
circuit size and wire AWG
Yes
Ultra-Fit Power Connectors
987651-1008
Ultra-Fit
887191723785
200
Female
High Conductivity Copper
Gold over Nickel
Tin over Nickel
0.144/g
Reel
0.381µm
1.524µm
Crimp or Compression
1.30-1.50mm
20, 22
N/A
12.0A
400V AC (RMS)/DC
N/A
EU ELV
Not Relevant
EU RoHS
China RoHS
Compliant
REACH SVHC
Not Contained Per
-ED/01/2018 (15
January 2018)
Halogen-Free
Status
Low-Halogen
Need more information on product
environmental compliance?
Email productcompliance@molex.com
Please visit the Contact Us section for any
non-product compliance questions.
China ROHS
ELV
RoHS Phthalates
Green Image
Not Relevant
Not Contained
Search Parts in this Series
172253 Series
Use With
Ultra-Fit Receptacle Housing 172256 ,
172258 , 172260 , 172262
AS-172323-0001-001
1723230001-TS-000, PS-172323-0001-001
SD-172253-1000-000
This document was generated on 02/19/2018
PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
