104CDMCCDS-3R3MC datasheet, PDF

Datasheet> All Categories > Passive components> 104CDMCCDS-3R3MC

104CDMCCDS-3R3MC: DescriptionFixed Inductors 3.3uH 20% 12mOhms Metal Composite; CategoryPassive components; File Size222KB，5 Pages; ManufacturerSUMIDA; Websitehttp://www.sumida.com/; Environmental Compliance

Download Datasheet Parametric Compare View All

104CDMCCDS-3R3MC Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	104CDMCCDS-3R3MC	-	-	View	Buy Now

104CDMCCDS-3R3MC Overview

Fixed Inductors 3.3uH 20% 12mOhms Metal Composite

104CDMCCDS-3R3MC Parametric

Parameter Name	Attribute value
Product Attribute	Attribute Value
Manufacturer	SUMIDA
Product Category	Fixed Inductors
RoHS	Details
Inductance	3.3 uH
Termination	-
Application	Power
Packaging	Cut Tape
Packaging	MouseReel
Packaging	Reel
Product	Fixed Inductors
Factory Pack Quantity	500
Unit Weight	0.077603 oz

Preview

Download Datasheet

View All

SMD Power Inductor

104CDMCC/DS

Description

• Metal compound molding type construction.

• Magnetically shielded.

• Low audible core noise.

• Suitable for large current.

• L W H: 11.5 10.3 4.0 mm Max.

• Product weight:2.2 g (Ref.)

• Moisture Sensitivity Level: 1

• RoHS compliance.

• Halogen Free available.

Environmental Data

• Operating temperature range: -55

+125

(including coil’s self temperature rise)

• Storage temperature range: -55

+125

• Solder reflow temperature: 260

peak.

Packaging

• Carrier tape and reel packaging.

• 500pcs per reel.

RoHS

Halogen

Free

Dimension - [mm]

5.7

2.0±8.3

.xaM 5.11

Land pattern and Schematics - [mm]

13.6

5.4

4.1

Applications

• Ideally used in notebook, ultrabook, tablet PC,

LCD display, Server application.

• High current, POL converters.

• Low profile, high current power supplies.

• Battery powered devices.

• DC/DC converters in distributed power

systems.

Page 1 of 5

Revised: 25-May-16

℃

℃ ½℃

× ×

1.0±5.2

5.0±0.2

51.0½0

104CDMCCDS-3R3MC Related Products

	104CDMCCDS-3R3MC	104CDMCCDS-2R2MC	104CDMCCDS-220MC	104CDMCCDS-R56MC	104CDMCCDS-R30MC	104CDMCCDS-330MC	104CDMCCDS-100MC	104CDMCCDS-6R8MC	104CDMCCDS-1R5MC	104CDMCCDS-R80MC
Description	Fixed Inductors 3.3uH 20% 12mOhms Metal Composite	Fixed Inductors 2.2uH 20% 7mOhms Metal Composite	Fixed Inductors 22uH 20% 66mOhms Metal Composite	Fixed Inductors 0.56uH 20% 1.8mOhms Metal Composite	Fixed Inductors 0.3uH 20% 1.1mOhms Metal Composite	Fixed Inductors 33uH 20% 92mOhms Metal Composite	Fixed Inductors 10uH 20% 30mOhms Metal Composite	Fixed Inductors 6.8uH 20% 25mOhms Metal Composite	Fixed Inductors 1.5uH 20% 4.2mOhms Metal Composite	Fixed Inductors 0.8uH 20% 3mOhms Metal Composite
Product Attribute	Attribute Value	Attribute Value	-	Attribute Value	Attribute Value	Attribute Value	-	Attribute Value	-	Attribute Value
Manufacturer	SUMIDA	SUMIDA	-	SUMIDA	SUMIDA	SUMIDA	-	SUMIDA	-	SUMIDA
Product Category	Fixed Inductors	Fixed Inductors	-	Fixed Inductors	Fixed Inductors	Fixed Inductors	-	Fixed Inductors	-	Fixed Inductors
RoHS	Details	Details	-	Details	Details	Details	-	Details	-	Details
Inductance	3.3 uH	2.2 uH	-	560 nH	300 nH	33 uH	-	6.8 uH	-	800 nH
Application	Power	-	-	Power	Power	Power	-	Power	-	Power
Packaging	Reel	Reel	-	Reel	Reel	Reel	-	Reel	-	Reel
Product	Fixed Inductors	Power Inductors	-	Fixed Inductors	Fixed Inductors	Fixed Inductors	-	Fixed Inductors	-	Fixed Inductors
Factory Pack Quantity	500	500	-	500	500	500	-	500	-	500
Unit Weight	0.077603 oz	0.077603 oz	-	0.077603 oz	0.077603 oz	0.077603 oz	-	0.077603 oz	-	0.077603 oz
