CPF
www.vishay.com
Vishay Dale
Metal Film Resistors, Axial, Industrial Power, Precision, Flameproof
FEATURES
•
•
•
•
•
•
•
High power rating, small size
Flameproof, high temperature silicone coating
Special filming and coating processes
Excellent high frequency characteristics
Low noise
Low voltage coefficient
Material categorization:
for definitions of compliance please see
www.vishay.com/doc?99912
Available
Available
Note
*
This datasheet provides information about parts that are RoHS-compliant and / or parts that are non-RoHS-compliant. For example, parts
with lead (Pb) terminations are not RoHS-compliant. Please see the information / tables in this datasheet for details.
STANDARD ELECTRICAL SPECIFICATIONS
GLOBAL
MODEL
HISTORICAL
MODEL
MAXIMUM WORKING
VOLTAGE
(1)
V
POWER RATING
P
70 °C
W
RESISTANCE
RANGE
5 to 150K
5 to 150K
1 to 150K
0.5 to 150K
0.5 to 150K
0.1 to 150K
5 to 150K
5 to 150K
1 to 150K
0.5 to 150K
0.5 to 150K
0.1 to 150K
8 to 150K
8 to 150K
1 to 150K
1 to 150K
1 to 150K
0.1 to 150K
TOLERANCE
±%
0.1, 0.25, 0.5, 1
0.1, 0.25, 0.5, 1, 2, 5
0.5, 1, 2, 5
1, 2, 5
1
2, 5
0.1, 0.25, 0.5, 1
0.1, 0.25, 0.5, 1, 2, 5
0.5, 1, 2, 5
1, 2, 5
1
2, 5
0.1, 0.25, 0.5, 1
0.1, 0.25, 0.5, 1, 2, 5
0.5, 1, 2, 5
1, 2, 5
1
2, 5
TEMPERATURE
COEFFICIENT
± ppm/°C
25
50
100
150
200
200
25
50
100
150
200
200
25
50
100
150
200
200
CPF1
CPF-1
250
1
CPF2
CPF-2
350
2
CPF3
CPF-3
500
3
Note
(1)
Continuous working voltage shall be
P
x
R
or maximum working voltage, whichever is less
GLOBAL PART NUMBER INFORMATION
New Global Part Numbering: CPF1562R00FKR36 (preferred part numbering format)
C
GLOBAL MODEL
CPF1
CPF2
CPF3
P
F
1
5
6
2
R
0
0
F
K
R
3
6
PACKAGING
SPECIAL
Blank = standard
(Dash number)
(Up to 3 digits)
From
1 to 999
as applicable
RESISTANCE VALUE
R
=
Ω
K
= kΩ
R10000
= 0.1
Ω
10R000
= 10
Ω
150K00
= 150 kΩ
TOLERANCE
CODE
B
= ± 0.1 %
C
= ± 0.25 %
D
= ± 0.5 %
F
=±1%
G
=±2%
J
=±5%
TEMPERATURE
COEFFICIENT
E
= 25 ppm
H
= 50 ppm
K
= 100 ppm
L
= 150 ppm
N
= 200 ppm
E14
= lead (Pb)-free, bulk
E36
= lead(Pb)-free, T/R (full)
EE6
= lead (Pb)-free,
T/R (1000 pieces)
B14
= tin/lead, bulk
R36
= tin/lead, T/R (full)
RE6
= tin/lead, T/R (1000 pieces)
Historical Part Number example: CPF-15620FT-1 R36 (will continue to be accepted)
CPF-1
HISTORICAL MODEL
5620
RESISTANCE VALUE
F
TOLERANCE CODE
T-1
TEMP. COEFFICIENT
R36
PACKAGING
Note
• For additional information on packaging, refer to the Through-Hole Resistor Packaging document (www.vishay.com/doc?31544).
Revision: 15-Dec-16
Document Number: 31021
1
For technical questions, contact:
ff2aresistors@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
CPF
www.vishay.com
Vishay Dale
HISTORICAL TC CODE
T-9
T-2
T-1
T-0
T-00
TEMPERATURE COEFFICIENT
25 ppm/°C
50 ppm/°C
100 ppm/°C
150 ppm/°C
200 ppm/°C
TEMPERATURE COEFFICIENT CODES
GLOBAL TC CODE
E
H
K
L
N
TECHNICAL SPECIFICATIONS
PARAMETER
Rated Dissipation at 70 °C
Limiting Element Voltage
Insulation Voltage
Thermal Resistance
Insulation Resistance
Category Temperature Range
Note
(1)
Rated voltage
P
x
R
GLOBAL
MODEL
CPF1
L
1 max.
d
(1)
UNIT
W
V
V
eff
K/W
°C
CPF1
1
250
900
85
CPF2
2
350
900
60
10
10
-65 °C / +230 °C
CPF3
3
500
900
50
DIMENSIONS
1.50 ± 0.125
(1)
(38.10 ±
3.18)
L
D
DIMENSIONS
in inches (millimeters)
L
D
L
1 max.
d
0.240 ± 0.020 0.090 ± 0.008 0.310 0.025 ± 0.002
(6.10 ± 0.51) (2.29 ± 0.20) (7.87) (0.64 ± 0.05)
0.344 ± 0.031 0.145 ± 0.015 0.425 0.032 ± 0.002
(8.74 ± 0.79) (3.68 ± 0.38) (10.80) (0.81 ± 0.05)
0.555 ± 0.041 0.180 ± 0.015 0.650 0.032 ± 0.002
(14.10 ± 1.04) (4.57 ± 0.381) (16.51) (0.81 ± 0.05)
CPF2
CPF3
Note
(1)
Lead length for product in bulk pack. For product supplied in
tape and reel, the actual lead length would be based on the body
size, tape spacing and lead trim.
HEAT RISE (°C ABOVE AMBIENT)
% RATED POWER
120
100
80
60
40
250
CPF1
200
150
100
CPF2
CPF3
20
50
0
- 55
0
0
1
2
3
4
5
APPLIED POWER IN W
- 25
0
30
60
90
70
120
150 180
210
240
AMBIENT TEMP. IN °C
DERATING
THERMAL RESISTANCE
Note
• Surface temperatures were taken with an infrared pyrometer in
+25 °C still air. Resistors were supported by their leads in test
clips at a point 0.500" (12.70 mm) out from the resistor body
ends.
MATERIAL SPECIFICATIONS
Element
Core
Coating
Termination
Proprietary nickel-chrome alloy
Cleaned high purity ceramic
Special high temperature conformal coat
Standard lead material is solder-coated
Solderable and weldable per
MIL-STD-1276, Type C
MECHANICAL SPECIFICATIONS
Terminal Strength
2 pound pull test
Continuous satisfactory coverage
when tested in accordance with
MIL-STD-202, Method 208
Solderability
Revision: 15-Dec-16
Document Number: 31021
2
For technical questions, contact:
ff2aresistors@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
CPF
www.vishay.com
Vishay Dale
MARKING
Temperature Coefficient: T00 = 200 ppm, T0 = 150 ppm, T1 = 100 ppm, T2 = 50 ppm, T9 = 25 ppm
CPF1, CPF2, CPF3: (5 lines)
DALE
CPF-1
49.9 k
1 % T2
1208
Manufacturer’s name
Style and size
Value
Tolerance and TC
4-digit date code
PERFORMANCE
TEST
Thermal Shock
Short Time Overload
Low Temperature Operation
Moisture Resistance
Resistance to Soldering Heat
Shock
Vibration
Terminal Strength
Dielectric Withstanding Voltage
Life
MAX.
R
(TYPICAL TEST LOTS)
± 1.0 %
± 0.5 %
± 0.5 %
± 1.5 %
± 0.5 %
± 0.5 %
± 0.5 %
± 0.5 %
± 0.5 %
± 2.0 %
Revision: 15-Dec-16
Document Number: 31021
3
For technical questions, contact:
ff2aresistors@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
