• Monolithic structure for higher reliability, compact size, & lightweight
• Magnetically shielded design to eliminate cross coupling
• Excellent solderability and heat resistance for reflow soldering
• Perfect shape for PCB mounting with no polarity
RoHS
Compliant
1.6 x 0.8 x 0.8mm
| | | | | | | | | | | | | | |
APPLICATIONS:
• Resonance circuit, traps and filter circuits
• RF choke for cordless phones and radio equipment
• Communications, video and audio equipment, computer and
remote Control.
STANDARD SPECIFICATIONS:
PARAMETERS
ABRACON P/N:
Operating temperature:
Storage temperature:
Part No.
AIML-0603-xxx
-55°C to + 125°C
-55°C to + 125°C
L(µH)
Tolerance
(%)
J, K
J, K
J, K
J, K
J, K
J, K
J, K
J, K
J, K
J, K
J, K
J, K
J, K
J, K
J, K
J, K
J, K
J, K
J, K
J, K
J, K
J, K
J, K
J, K
J, K
J, K
J, K
J, K
J, K
J, K
J, K
J, K
J, K
J, K
Q
(min)
Test Freq.
(MHz)
50
50
50
50
25
25
25
25
25
25
25
25
25
25
25
25
10
10
10
10
10
10
10
10
10
4
4
4
2
2
1
1
1
1
SRF(MHz)
(min)
600
550
500
450
400
350
300
280
260
255
250
245
240
205
180
165
125
110
105
95
90
80
70
60
50
45
40
35
33
22
20
18
15
12
DCR(Ω)
(max)
0.20
0.30
0.30
0.30
0.50
0.50
0.60
0.60
0.80
0.80
0.85
1.00
1.35
1.55
1.70
2.10
0.60
0.80
0.80
0.95
1.15
1.35
1.55
1.70
2.10
1.55
1.70
2.10
2.55
2.75
1.70
1.85
2.10
2.75
Ir(mA)
(max)
50
50
50
50
50
50
50
50
50
50
35
35
35
35
35
35
25
25
25
25
15
15
15
15
15
5
5
4
3
3
1
1
1
1
AIML-0603-47N
0.047
15
AIML-0603-56N
0.056
15
AIML-0603-68N
0.068
15
AIML-0603-82N
0.082
15
AIML-0603-R10
0.100
15
AIML-0603-R12
0.120
15
AIML-0603-R15
0.150
15
AIML-0603-R18
0.180
15
AIML-0603-R22
0.220
15
AIML-0603-R27
0.270
15
AIML-0603-R33
0.330
15
AIML-0603-R39
0.390
15
AIML-0603-R47
0.470
15
AIML-0603-R56
0.560
15
AIML-0603-R68
0.680
15
AIML-0603-R82
0.820
15
AIML-0603-1R0
1.000
35
AIML-0603-1R2
1.200
35
AIML-0603-1R5
1.500
35
AIML-0603-1R8
1.800
35
AIML-0603-2R2
2.200
35
AIML-0603-2R7
2.700
35
AIML-0603-3R3
3.300
35
AIML-0603-3R9
3.900
35
AIML-0603-4R7
4.700
35
AIML-0603-5R6
5.600
35
AIML-0603-6R8
6.800
35
AIML-0603-8R2
8.200
35
AIML-0603-100
10.000
35
AIML-0603-120
12.000
35
AIML-0603-150
15.000
20
AIML-0603-180
18.000
20
AIML-0603-220
22.000
20
AIML-0603-270
27.000
20
Test Conditions and equipments
L, Q:
HP4291 Impedance Analyzer
DCR:
HP4263A LCR meter
SRF:
HP4291 Impedance analyzer
Ir:
HP4291 Impedance Analyzer, DC power HP6632 and Adapter HP16200.
∆L/L
(initial)
≥
-5%
Unless otherwise specified
Temperature :
Ordinary Temperature (5 to 35ºC)
Humidity :
Ordinary Humidity (25 to 85% RH)
ABRACON IS
ISO 9001:2008
ISO 9001 / QS 9000
CERTIFIED
Revised: 01.26.12
30332 Esperanza, Rancho Santa Margarita, California 92688
tel 949-546-8000
|
fax 949-546-8001|
www.abracon.com
Visit www.abracon.com for Terms & Conditions of Sale
MULTILAYER FERRITE CHIP INDUCTOR
AIML-0603
OPTIONS AND PART IDENTIFICATION:
RoHS
Compliant
1.6 x 0.8 x 0.8mm
| | | | | | | | | | | | | | |
AIML-0603-
Inductance Code
Please refer to the
table above
Tolerance
J: ±5%
K: ±10%
-
Packaging
T: Tape and Reel (4kpcs / reel)
OUTLINE DRAWING:
Dimension: mm [inch]
Series
AIML-0603
L
1.60±0.15
[0.063±0.006]
W
0.80±0.15
[0.031±0.006]
T
0.80±0.15
[0.031±0.006]
a1,a2
0.30±0.20
[0.012±0.008]
MATERIAL:
REFLOW PROFILE:
1
2
3
4
Part Name
Base Material
Internal Conductor
Terminal Electrode
Terminal Electrode
Material
Ferrite (Ni-Cu-Zn series)
Ag
Ag
Ni-Sn
ABRACON IS
ISO 9001:2008
ISO 9001 / QS 9000
CERTIFIED
Revised: 01.26.12
30332 Esperanza, Rancho Santa Margarita, California 92688
tel 949-546-8000
|
fax 949-546-8001|
www.abracon.com
Visit www.abracon.com for Terms & Conditions of Sale
MULTILAYER FERRITE CHIP INDUCTOR
AIML-0603
TAPE & REEL:
T: 4,000pcs / reel
RoHS
Compliant
1.6 x 0.8 x 0.8mm
| | | | | | | | | | | | | | |
Codes
AIML-0603
A
B
C
D
E
F
G
H
ΦJ
t(max)
1.05±0.10
1.9±0.10
8.0±0.3
3.5±0.05
1.75±0.1
4.0±0.05
2.0±0.05
4.0±0.1
1.5+0.1/-0
1.0±0.05
A
B
C
D
E
W
t
R
178±2
60±2
13.0±0.5
21.0±0.8
2.0±0.5
10.0±1.15
1.2±0.2
1.0±0.25
Peeling strength of cover tape
0.3~0.7N (30gf~70gf)
Test condition:
1) peel angle: 165°~180°
vs.
carrier tape.
2) peel speed: 300 mm/min±10%.
Dimension: mm
ATTENTION:
Abracon Corporation’s products are COTS – Commercial-Off-The-Shelf products; suitable for Commercial, Industrial and, where designated, Automotive Applications.
Abracon’s products are not specifically designed for Military, Aviation, Aerospace, Life-dependant Medical applications or any application requiring high reliability where component
failure could result in loss of life and/or property. For applications requiring high reliability and/or presenting an extreme operating
environment,
written consent and authorization from
Abracon Corporation is required. Please contact Abracon Corporation for more information.
ABRACON IS
ISO 9001:2008
ISO 9001 / QS 9000
CERTIFIED
Revised: 01.26.12
30332 Esperanza, Rancho Santa Margarita, California 92688
tel 949-546-8000
|
fax 949-546-8001|
www.abracon.com
Visit www.abracon.com for Terms & Conditions of Sale
