76650-0209: DescriptionHeaders & Wire Housings KK-156 Connector Kit V & RA Hdr Rec 3Ckt; CategoryThe connector; File Size30KB，2 Pages; ManufacturerMolex; Websitehttps://www.molex.com/molex/home; Environmental Compliance

Download Datasheet Parametric View All

76650-0209 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	76650-0209	-	-	View	Buy Now

76650-0209 Overview

Headers & Wire Housings KK-156 Connector Kit V & RA Hdr Rec 3Ckt

76650-0209 Parametric

Parameter Name	Attribute value
Product Attribute	Attribute Value
Manufacturer	Molex
Product Category	Headers & Wire Housings
RoHS	Details
Product	Connector Kits
Type	Header Kit
Number of Positions	3 Position
Pitch	3.96 mm
Mounting Style	-
Termination Style	-
Mounting Angle	-
Contact Gender	-
Contact Plating	-
Packaging	Bulk
Application	Wire to Board
Contact Type	-
Current Rating	4 A
Voltage Rating	250 V
Contact Material	-
Flammability Rating	UL 94 V-0
Row Spacing	-
Housing Gender	-
Factory Pack Quantity	1
Wire Gauge	24 AWG - 18 AWG

Preview

Download Datasheet

View All

1801 Morgan Street

Rockford, Illinois 61102

800-435-2931

www.molexkits.com

Datasheet for 76650-0209

General Information

Part Number:

76650-0209

Manufacturer:

Title:

Description:

Product Family:

Certificates:

Molex / Waldom

KK-156 Connector Kit

.156 Pitch Single Row Vertical and Right Angle Header and Receptacle, 3 Circuit

KK™

(Molex parts within this kit) EU and China RoHS, UL and CSA

Country of Origin:

Kit assembled in U.S.A.

Specifications

Design

Configuration:

Pitch:

Connector Type:

Mounting

Orientation:

Circuit Sizes:

Current Rating:

Voltage:

Wire size:

Product Highlights

The KK system of "building block" connectors can be used to create thousands of

different configurations, allowing each user to build a system that is precisely suited

to their application. KK has become known as a versatile interconnecting system

developed to meet the challenge of modularization.

Features and Benefits

• Standard cantilever terminals

• Cantilever design provides high contact

pressure

• Wiping action cleans oxides when

connector is mated

• Locking ramps for improved retention

when mated

Applications

• Vending and Gaming Machines

• Production Equipment

• Industrial Instruments

• Energy and Power

Wire-to-Board

3.96mm (.156")

Receptacle and Header

Vertical and Right Angle

3

4 Amps

250 Volts

24-18 AWG

For additional Molex / Waldom Design and Solution kits please go to www.molexkits.com

Page 1 of 2
