ZTT Series
Ceramic Resonator
The ZTT Series ceramic resonator offers a wide frequency range
and extended temperature range capabilities with built in load
capacitance.
Request a Sample
OPERATING CONDITIONS / ELECTRICAL CHARACTERISTICS
ZTT Series
Part Number *
ZTT
□.□□
MG
ZTT
□.□□
MG
ZTT
□.□□
MG
ZTT
□.□□
MT
ZTT
□□.□□
MT
ZTT
□□.□□
MX
•
•
•
•
•
Low Profile
Wide Frequency Range
Extended temperature
range
RoHS Compliant (Note 7
Exemption)
Built-in load capacitance
•
•
Frequency Range
(MHz)
2.00 ~ 2.99
3.00 ~ 3.49
3.50 ~ 8.00
6.01 ~ 6.99
7.00 ~ 13.00
13.01 ~ 50.00
Frequency
Accuracy
@25⁰C (%)
±0.5
±0.5
±0.5
±0.5
±0.5
±0.5
Stability in
Temperature
-20 ~ +80⁰C (%)
±0.3
±0.3
±0.3
±0.3
±0.3
±0.3
Aging for
Ten
Years (%)
±0.3
±0.3
±0.3
±0.3
±0.3
±0.3
Resonant
Resistance
(Ω) MAX
80
50
30
30
25
30
Withstanding voltage (5 seconds max.) : 100V DC
Insulation Resistance 100M Ω Min. (at 10V DC)
Part Numbering Guide: ZTT-4.00MG
ZTT
-
Frequency
-
Suffix
ZTT
4.00 MHz
MG (2~8M Hz)
MT (6.01 ~ 13 MHz)
MX (13.01 ~ 50 MHz)
Package Dimensions (mm)
Figure 1)
ZTT
□.□□
MG
Side and Front Views
Figure 2)
ZTT
□.□□
MG
Test Circuit
Figure 3)
ZTT
□.□□
MX
Side and Front Views
Figure 4)
ZTT
□.□□
MT & ZTT
□.□□
MX
Test Circuit
Note: ECS does not
approve the use of it’s
products in Automotive,
Military, Avionics, Life
Sustaining or Life Support
systems or any other
related medical
applications without
written approval from ECS
Inc.
