Features
■
Formerly
■
Available in E6 series
■
Unit height of 3.8 mm
■
Current up to 7.2 A
■
RoHS compliant*
Applications
model
■
Input/output of DC/DC converters
■
Power supplies for:
*R
oH
S
100
•
•
•
•
Portable communication equipment
Camcorders
LCD TVs
Car radios
PM104SH Series - Shielded SMD Power Inductors
Electrical Specifications
Inductance 100 kHz
General Specifications
Q
Ref.
14
12
14
12
13
24
24
20
22
22
24
24
20
22
20
Test
Frequency
(MHz)
7.96
7.96
7.96
7.96
7.96
7.96
2.52
2.52
2.52
2.52
2.52
0.796
0.796
0.796
0.796
SRF
Min.
(MHz)
65.0
50.0
35.0
30.0
36.0
20.0
16.0
12.0
10.0
8.0
7.0
6.0
5.0
4.0
3.0
RDC
(mΩ)
5.2
12.5
15.0
22.0
35.0
25.0
37.0
55.8
86.0
121.0
166.0
220.0
358.0
565.0
773.0
I rms
Max.
(A)
7.20
6.10
5.50
4.60
3.90
3.80
2.80
2.20
1.80
1.65
1.10
1.30
0.90
0.65
0.55
I sat
Typ.
(A)
7.00
6.00
5.50
4.80
4.00
3.60
2.70
2.30
1.80
1.60
1.30
1.10
0.80
0.65
0.52
Bourns Part No.
PM104SH-1R5-RC
PM104SH-2R5-RC
PM104SH-3R8-RC
PM104SH-5R2-RC
PM104SH-7R0-RC
PM104SH-100-RC
PM104SH-150-RC
PM104SH-220-RC
PM104SH-330-RC
PM104SH-470-RC
PM104SH-680-RC
PM104SH-101-RC
PM104SH-151-RC
PM104SH-221-RC
PM104SH-331-RC
(µH)
1.5
2.5
3.8
5.2
7.0
10.0
15.0
22.0
33.0
47.0
68.0
100.0
150.0
220.0
330.0
Tol. %
± 30
± 30
± 30
± 30
± 30
± 30
± 30
± 30
± 30
± 30
± 30
± 30
± 30
± 30
± 30
Test Voltage .......................................1 V
Reflow Soldering .. 230 °C, 50 sec. max.
Operating Temperature
................................-40 °C to +125 °C
(Temperature rise included)
Storage Temperature .. -40 °C to +125 °C
Resistance to Soldering Heat
............................... 260 °C for 10 sec.
Materials
Core ....................Ferrite DR and RI core
Wire ............................Enameled copper
Base .....................................LCP E4008
Terminal ....................................Ag/Ni/Sn
Rated Current
...................Ind. drop 35 % typ. at Isat
Temperature Rise
.....................40 °C max. at rated Irms
Packaging .................. 1000 pcs. per reel
Product Dimensions
Electrical Schematic
Inductor Connection
10.0 ± 0.3
(.394 ± .012)
10.0 ± 0.3
(.394 ± .012)
LCR METER
3.8 ± 0.3
(.150 ± .012)
7.4
TYP.
(.291)
3.4
(.134)
TYP.
3.2
(.126)
TYP.
3.4
TYP.
(.134)
DIMENSIONS:
MM
(INCHES)
Recommended Layout
7.2
(.283)
REF.
1.8
(.071)
REF.
1.8
(.071)
REF.
*RoHS Directive 2002/95/EC Jan. 27, 2003 including annex and RoHS Recast 2011/65/EU June 8, 2011.
Specifications are subject to change without notice.
Customers should verify actual device performance in their specific applications.
3.6
(.142)
REF.
PM104SH Series - Shielded SMD Power Inductors
Packaging Specifications
330
DIA.
(12.99)
2.0 ± 0.5
(.079 ± .020)
30.4
(1.20)
13.0 ± 0.5
(.512 ± .020)
DIA.
50.0
(1.969)
13.0 ± 0.5
DIA.
(.512 ± .020)
26
(1.02)
COVER
TAPE
EMBOSSED
CAVITY
21.0 ± 0.8
(.827 ± .031)
EMBOSSED
CARRIER
24.0
(.945)
END
4
(.157)
START
16
(.63)
NO COMPONENT
NO COMPONENT
COMPONENTS
160
(6.299)
400
(15.748)
USER DIRECTION OF FEED
QTY: 1000 PCS. PER REEL
DIMENSIONS:
MM
(INCHES)
REV. 05/11
Specifications are subject to change without notice.
Customers should verify actual device performance in their specific applications.
