296UD104B1N datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Passive components> The resistor> 296UD104B1N

296UD104B1N: DescriptionPotentiometers 100Kohms 20% PC Formed to Rear; CategoryPassive components The resistor; File Size340KB，2 Pages; ManufacturerCTS; Environmental Compliance

Download Datasheet Parametric View All

296UD104B1N Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	296UD104B1N	-	-	View	Buy Now

296UD104B1N Overview

Potentiometers 100Kohms 20% PC Formed to Rear

296UD104B1N Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
package instruction	PCB Mount, 5034
Reach Compliance Code	unknown
ECCN code	EAR99
structure	Rotary
Maximum operating temperature	80 °C
Minimum operating temperature	-10 °C
Package height	8.7 mm
Package length	12.5 mm
Package form	PCB Mount
Package width	16.4 mm
Rated power dissipation(P)	0.15 W
resistance	100000 Ω
Resistor type	POTENTIOMETER
rotation angle	300 deg
size code	5034
technology	CARBON COMPOSITION
Tolerance	20%
Operating Voltage	250 V
Base Number Matches	1

Preview

Download Datasheet

View All

Electrocomponents

Series 296

Data Sheet

Rotary Potentiometer

Commercial

12mm Diameter

Carbon Composition

Rotary Potentiometer

Features

• Miniature 12mm size

• Low cost

• Snap-in bracket for PC board mounting

• Detent available

• Insulated shaft available

• RoHS compliant

Electrical and Mechanical Specifications

Resistance Range

500 ohms through 1 Megohms

Resistance Tolerance

±30%, ±20%, ±10%

Power Rating

0.15 watts @ 50°C

Dielectric Strength

500 VDC for 1 minute

Maximum Operating Voltage

350 VDC

Insulation Resistance

100 Megohms minimum @ 250 VDC

Rotational Angle

Mechanical angle: 300°

Effective angle: 280°

Rotational Torque

20 – 216 gf-cm

Stop Strength

5.76 kg-cm minimum (VR without detent)

3 kg-cm minimum (VR with detent)

Mounting Information

P.C. board mounting

Type "X": Shaft parallel to P.C. board

Type "U": Shaft vertical to P.C. board

Type "H": Same as "X" except hook terminals

Detent

Detent @ 50% rotation

Push-Pull strength on shaft

8 kg for 10 seconds

Rotational life

10K cycles

Operating temperature

-10°C ~ 80°C

Solder Heat Resistance

260°C for 5 seconds

1-2

CTS Electrocomponents

www.ctscorp.com

2/06/09
