ES1DL RQ

Description
Rectifiers 1A, 200V, SUPER FAST SM RECTIFIER
Categorysemiconductor    Discrete semiconductor
File Size355KB,4 Pages
ManufacturerTaiwan Semiconductor
Websitehttp://www.taiwansemi.com/
Environmental Compliance
Download Datasheet Parametric View All

ES1DL RQ Overview

Rectifiers 1A, 200V, SUPER FAST SM RECTIFIER

ES1DL RQ Parametric

Parameter NameAttribute value
Product AttributeAttribute Value
ManufacturerTaiwan Semiconductor
Product CategoryRectifiers
RoHSDetails
Mounting StyleSMD/SMT
Package / CaseSub SMA-2
Vr - Reverse Voltage200 V
If - Forward Current1 A
TypeFast Recovery Rectifiers
ConfigurationSingle
Vf - Forward Voltage0.95 V
Max Surge Current30 A
Ir - Reverse Current5 uA
Recovery Time35 ns
Minimum Operating Temperature- 55 C
Maximum Operating Temperature+ 150 C
PackagingCut Tape
PackagingReel
ProductRectifiers
Factory Pack Quantity10000
Unit Weight0.000670 oz
ES1AL - ES1JL
Taiwan Semiconductor
CREAT BY ART
1A, 50V - 600V Surface Mount Super Fast Rectifiers
FEATURES
- Glass passivated junction chip
- Ideal for automated placement
- Low profile package
- Low power loss, high efficiency
- Compliant to RoHS Directive 2011/65/EU and
in accordance to WEEE 2002/96/EC
- Halogen-free according to IEC 61249-2-21 definition
MECHANICAL DATA
Case:
Sub SMA
Molding compound, UL flammability classification rating 94V-0
Moisture sensitivity level: level 1, per J-STD-020
Part No. with suffix "H" means AEC-Q101 qualified
Packing code with suffix "G" means green compound (halogen-free)
Terminal:
Matte tin plated leads, solderable per JESD22-B102
Meet JESD 201 class 2 whisker test
Polarity:
Indicated by cathode band
Weight:
0.019 g (approximately)
Sub SMA
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
(T
A
=25°C unless otherwise noted)
PARAMETER
Marking code
Maximum repetitive peak reverse voltage
Maximum RMS voltage
Maximum DC blocking voltage
Maximum average forward rectified current
Peak forward surge current, 8.3 ms single half sine-wave
superimposed on rated load
Maximum instantaneous forward voltage (Note 1)
@1A
Maximum reverse current @ rated V
R
Typical junction capacitance (Note 2)
Maximum reverse recovery time (Note 3)
Typical thermal resistance
Operating junction temperature range
Storage temperature range
Note 1: Pulse test with PW=300μs, 1% duty cycle
Note 2: Measured at 1 MHz and Applied V
R
=4.0 Volts.
Note 3: Reverse Recovery Test Conditions: I
F
=0.5A, I
R
=1.0A, I
RR
=0.25A
T
J
=25°C
T
J
=125°C
V
RRM
V
RMS
V
DC
I
F(AV)
I
FSM
V
F
I
R
C
J
t
rr
R
θJL
R
θJA
T
J
T
STG
10
35
35
85
- 55 to +150
- 55 to +150
0.95
5
100
8
SYMBOL
ES
1AL
EAL
50
35
50
ES
1BL
EBL
100
70
100
ES
1CL
ECL
150
105
150
ES
1DL
EDL
200
140
200
1
30
1.3
1.7
ES
1FL
EFL
300
210
300
ES
1GL
EGL
400
280
400
ES
1HL
EHL
500
350
500
ES
1JL
EJL
600
420
600
V
V
V
A
A
V
μA
pF
ns
°C/W
°C
°C
UNIT
