2219/15C SL005 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Wire/cable> 2219/15C SL005

2219/15C SL005: DescriptionCABLE 15COND 22AWG SHLD 100'; CategoryWire/cable; File Size222KB，4 Pages; ManufacturerAlpha Wire; Websitehttp://www.alphawire.com/zh-CN/; Environmental Compliance

Download Datasheet Parametric View All

2219/15C SL005 Overview

CABLE 15COND 22AWG SHLD 100'

2219/15C SL005 Parametric

Parameter Name	Attribute value
Cable type	multi-core
Number of conductors	15
Wire gauge	22 AWG
Number of wire strands	7/30
conductor material	Copper, tin plated
Sheath (insulation) material	Polyvinyl chloride (PVC)
Sheath (insulation) diameter	0.451"（11.46mm）
Shield type	foil
length	100.0'（30.5m）
Casing color	slate color
grade	-
characteristic	drain wire
Voltage	150V
Operating temperature	-20°C ~ 80°C
use	communication, control
Sheath (insulation) thickness	0.0350"（0.889mm）
conductor insulation	Polyvinyl chloride (PVC)
shielding material	aluminum
Shielding range	100%

Preview

Download Datasheet

View All

Alpha Wire | 711 Lidgerwood Avenue, Elizabeth, NJ 07207

Tel: 1-800-52 ALPHA (25742), Web: www.alphawire.com

Customer Specification

PART NO. 2219/15C

Construction

Diameters (In)

1) Component 1

a) Conductor

b) Insulation

(1) Color Code

Pair

c) Pair

(1) Twists:

2) Cable Assembly

a) Twists:

3) Shield:

a) Foil Direction

b) Drain Wire

4) Jacket

a) Color(s)

Color

BLACK-RED

BLACK-WHITE

BLACK-GREEN

BLACK-BLUE

BLACK-BROWN

15 X 1 PAIR

22 (7/30) AWG TC

0.010" Wall, Nom. PVC

Alpha Wire Color Code A

Pair

Color

BLACK-YELLOW

BLACK-ORANGE

RED-GREEN

RED-WHITE

RED-BLUE

Pair

Color

RED-YELLOW

RED-BROWN

RED-ORANGE

GREEN-BLUE

GREEN-WHITE

0.030

0.050

2/Cond Cabled Together

8.0 Twists/foot (min)

15 Components Cabled

2.2 Twists/foot (min)

Alum/Mylar Tape, 25% Overlap, Min.

Foil Facing Out

22 (7/30) AWG TC

0.035" Wall, Nom.,PVC

SLATE

ALPHA WIRE-* P/N 2219/15C 15PR 22 AWG

SHIELDED 75C (UL) TYPE CM OR AWM 2576 --- LLXXXXXX

0.451 (0.475 Max.)

b) Print

CSA TYPE CMG FT4 CE ROHS

* = Factory Code

[Note: Product may have c(UL) or CSA markings depending upon plant of manufacture.]

Applicable Specifications

1) UL

AWM/STYLE 2576

VW-1

2) CSA International

CMG

FT4

3) CE:

EU Low Voltage Directive 2006/95/EC

60°C

80°C / 150 V

75°C

RMS

Environmental

EU/China ROHS CERTIFICATE OF COMPLIANCE

To Whom It May Concern:

Alpha Wire Part Number: 2219/15C

2219/15C , RoHS-Compliant Commencing With 8/1/2005 Production

Note: all colors and put-ups

This document certifies that the Alpha part number cited above is manufactured in accordance with Directive 2011/65/EU of the European

Parliament, better known as the RoHS Directive (commonly known as RoHS 2), with regards to restrictions of the use of certain hazardous

substances used in the manufacture of electrical and electronic equipment. This certification extends to amending Directive 2015/863/EU which

expanded the list of restricted substances to 10 items (commonly known as RoHS 3) The reader is referred to these Directives for the specific

definitions and extents of the Directives. No Exemptions are required for RoHS Compliance on this item. Additionally, Alpha certifies that the listed

part number is in compliance with China RoHS “Marking for Control of Pollution by Electronic Information Products” standard SJ/T 11364-2014.

Substance

Lead

Mercury

Cadmium

Hexavalent Chromium

Polybrominated Biphenyls (PBB)

Polybrominated Diphenyl Ethers (PBDE) ,

Including Deca-BDE

Bis(2-ethylhexyl) phthalate (DEHP)

Butyl benzyl phthalate (BBP)

Dibutyl phthalate (DBP)

Diisobutyl phthalate (DIBP)

0.1% by weight (1000 ppm)

Maximum Control Value

0.1% by weight (1000 ppm)

0.01% by weight (100 ppm)

0.1% by weight (1000 ppm )

0.1% by weight (1000 ppm)

The information provided in this document and disclosure is correct to the best of Alpha Wire's knowledge, information and belief at the date of its

release. The information provided is designed only as a general guide for the safe handling, storage, and any other operation of the product itself or

the one that it will become part of. The intent of this document is not to be considered a warranty or quality specification. Regulatory information is

for guidance purposes only. Product users are responsible for determining the applicability of legislation and regulations based on their individual

usage of the product.

Authorized Signatory for the Alpha Wire:

Dave Watson, Director of Engineering & QA

Alpha Wire

711 Lidgerwood Ave.

Elizabeth, NJ 07207

Tel: 1-908-925-8000

12/1/2018
