84601-001: DescriptionRA PWR CONN ASSY; CategoryThe connector The connector; File Size71KB，1 Pages; ManufacturerAmphenol; Websitehttp://www.amphenol.com/

Download Datasheet Parametric Compare View All

84601-001 Overview

RA PWR CONN ASSY

84601-001 Parametric

Parameter Name	Attribute value
Maker	Amphenol
Reach Compliance Code	compliant
ECCN code	EAR99
Board mount options	PEG
body width	0.524 inch
body length	0.47 inch
Connector type	RECTANGULAR POWER CONNECTOR
Contact arrangement	S0P1
Contact to complete cooperation	NOT SPECIFIED
Contact point gender	FEMALE
Contact material	NOT SPECIFIED
Contact style	RND PIN-SKT
DIN compliance	NO
empty shell	NO
Filter function	NO
IEC compliance	NO
insulator material	GLASS FILLED LIQUID CRYSTAL POLYMER
MIL compliance	NO
Manufacturer's serial number	84601
Mixed contacts	NO
Installation option 1	LOCKING
Installation method	RIGHT ANGLE
Installation type	BOARD
Number of connectors	ONE
Options	GENERAL PURPOSE
Plating thickness	31u inch
Guideline	UL
reliability	COMMERCIAL
Shell material	GLASS FILLED LIQUID CRYSTAL POLYMER
Terminal length	0.169 inch
Termination type	SOLDER
Total number of contacts	1
UL Flammability Code	94V-0

Preview

Download Datasheet

View All

PDM: Rev:D

STATUS:

Released

Printed: May 19, 2011

.

84601-001 Related Products

	84601-001	84601-002LF	84601-002	84601-003	84601-003LF	84601-001LF
Description	RA PWR CONN ASSY	Rectangular Power Connector, 1 Contact(s), Female, Solder Terminal, LEAD FREE	Rectangular Power Connector, 1 Contact(s), Female, Solder Terminal	Rectangular Power Connector, 1 Contact(s), Female, Solder Terminal	Rectangular Power Connector, 1 Contact(s), Female, Solder Terminal, LEAD FREE	Rectangular Power Connector, 1 Contact(s), Female, Solder Terminal, LEAD FREE
Reach Compliance Code	compliant	compliant	compliant	compliant	compliant	compliant
Board mount options	PEG	PEG	PEG	PEG	PEG	PEG
body width	0.524 inch	0.524 inch	0.524 inch	0.524 inch	0.524 inch	0.524 inch
body length	0.47 inch	0.47 inch	0.47 inch	0.47 inch	0.47 inch	0.47 inch
Connector type	RECTANGULAR POWER CONNECTOR	RECTANGULAR POWER CONNECTOR	RECTANGULAR POWER CONNECTOR	RECTANGULAR POWER CONNECTOR	RECTANGULAR POWER CONNECTOR	RECTANGULAR POWER CONNECTOR
Contact arrangement	S0P1	S0P1	S0P1	S0P1	S0P1	S0P1
Contact to complete cooperation	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	AU ON NI	NOT SPECIFIED	NOT SPECIFIED
Contact point gender	FEMALE	FEMALE	FEMALE	FEMALE	FEMALE	FEMALE
Contact style	RND PIN-SKT	RND PIN-SKT	RND PIN-SKT	RND PIN-SKT	RND PIN-SKT	RND PIN-SKT
DIN compliance	NO	NO	NO	NO	NO	NO
empty shell	NO	NO	NO	NO	NO	NO
Filter function	NO	NO	NO	NO	NO	NO
IEC compliance	NO	NO	NO	NO	NO	NO
insulator material	GLASS FILLED LIQUID CRYSTAL POLYMER	GLASS FILLED LIQUID CRYSTAL POLYMER	GLASS FILLED LIQUID CRYSTAL POLYMER	GLASS FILLED LIQUID CRYSTAL POLYMER	GLASS FILLED LIQUID CRYSTAL POLYMER	GLASS FILLED LIQUID CRYSTAL POLYMER
MIL compliance	NO	NO	NO	NO	NO	NO
Manufacturer's serial number	84601	84601	84601	84601	84601	84601
Mixed contacts	NO	NO	NO	NO	NO	NO
Installation option 1	LOCKING	LOCKING	LOCKING	LOCKING	LOCKING	LOCKING
Installation method	RIGHT ANGLE	RIGHT ANGLE	RIGHT ANGLE	RIGHT ANGLE	RIGHT ANGLE	RIGHT ANGLE
Installation type	BOARD	BOARD	BOARD	BOARD	BOARD	BOARD
Number of connectors	ONE	ONE	ONE	ONE	ONE	ONE
Options	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE
Plating thickness	31u inch	31u inch	31u inch	31u inch	31u inch	31u inch
Guideline	UL	UL	UL	UL	UL	UL
reliability	COMMERCIAL	COMMERCIAL	COMMERCIAL	COMMERCIAL	COMMERCIAL	COMMERCIAL
Shell material	GLASS FILLED LIQUID CRYSTAL POLYMER	GLASS FILLED LIQUID CRYSTAL POLYMER	GLASS FILLED LIQUID CRYSTAL POLYMER	GLASS FILLED LIQUID CRYSTAL POLYMER	GLASS FILLED LIQUID CRYSTAL POLYMER	GLASS FILLED LIQUID CRYSTAL POLYMER
Terminal length	0.169 inch	0.138 inch	0.138 inch	0.106 inch	0.106 inch	0.169 inch
Termination type	SOLDER	SOLDER	SOLDER	SOLDER	SOLDER	SOLDER
Total number of contacts	1	1	1	1	1	1
UL Flammability Code	94V-0	94V-0	94V-0	94V-0	94V-0	94V-0
Maker	Amphenol	-	-	Amphenol	Amphenol	Amphenol
ECCN code	EAR99	EAR99	-	EAR99	EAR99	-
Contact material	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	-	NOT SPECIFIED	NOT SPECIFIED
Base Number Matches	-	1	1	1	1	-
