BDY57: Description25 A, 125 V, NPN, Si, POWER TRANSISTOR, TO-3; Categorysemiconductor Discrete semiconductor; File Size152KB，3 Pages; ManufacturerETC

Download Datasheet Parametric Compare View All

BDY57 Overview

25 A, 125 V, NPN, Si, POWER TRANSISTOR, TO-3

BDY57 Parametric

Parameter Name	Attribute value
Number of terminals	2
Transistor polarity	NPN
Maximum collector current	25 A
Maximum Collector-Emitter Voltage	125 V
state	ACTIVE
packaging shape	ROUND
Package Size	FLANGE MOUNT
Terminal form	PIN/PEG
terminal coating	NOT SPECIFIED
Terminal location	BOTTOM
Packaging Materials	METAL
structure	SINGLE
Shell connection	COLLECTOR
Number of components	1
transistor applications	SWITCHING
Transistor component materials	SILICON
Transistor type	GENERAL PURPOSE POWER
Minimum DC amplification factor	20
Rated crossover frequency	7 MHz

Preview

Download Datasheet

View All

BDY57 – BDY58

NPN SILICON TRANSISTORS, DIFFUSED MESA

LF Large Signal Power Amplification

High Current Fast Switching

ABSOLUTE MAXIMUM RATINGS

Symbol

V

CEO

V

CBO

V

EBO

I

C

I

B

P

TOT

T

J

T

S

Collector-Emitter Voltage

Collector-Base Voltage

Emitter-Base Voltage

Collector Current

Base Current

Power Dissipation

Junction Temperature

Storage Temperature

Ratings

BDY57

BDY58

BDY57

BDY58

BDY57

BDY58

BDY57

BDY58

BDY57

BDY58

@ T

C

= 25°

BDY57

BDY58

BDY57

BDY58

Value

80

125

120

160

10

25

6

Unit

V

A

Watts

175

-65 to +200

°C

THERMAL CHARACTERISTICS

Symbol

R

thJ-C

Ratings

Thermal Resistance, Junction to Case

BDY57

BDY58

Value

1

Unit

°C/W

COMSET SEMICONDUCTORS

1/3

BDY57 Related Products

	BDY57	BDY58
Description	25 A, 125 V, NPN, Si, POWER TRANSISTOR, TO-3	25 A, 125 V, NPN, Si, POWER TRANSISTOR, TO-3
Number of terminals	2	2
Transistor polarity	NPN	NPN
Maximum collector current	25 A	25 A
Maximum Collector-Emitter Voltage	125 V	125 V
state	ACTIVE	ACTIVE
packaging shape	ROUND	ROUND
Package Size	FLANGE MOUNT	FLANGE MOUNT
Terminal form	PIN/PEG	PIN/PEG
terminal coating	NOT SPECIFIED	NOT SPECIFIED
Terminal location	BOTTOM	BOTTOM
Packaging Materials	METAL	METAL
structure	SINGLE	SINGLE
Shell connection	COLLECTOR	COLLECTOR
Number of components	1	1
transistor applications	SWITCHING	SWITCHING
Transistor component materials	SILICON	SILICON
Transistor type	GENERAL PURPOSE POWER	GENERAL PURPOSE POWER
Minimum DC amplification factor	20	20
Rated crossover frequency	7 MHz	7 MHz
