Surface Mount Fuses
350 Volt Surface Mount Fuse
EBF Fuse
Fast-Acting Type 446/447 Series
• Ideal for use in electronic lighting ballast, power supply and power
inverter applications.
• Rated for use in 125, 250, 277 and 350 VAC circuits.
• Based on the proven reliability of the automotive MINI
®
Fuse; avail-
able from 2 through 10 amperes.
®
®
ELECTRICAL CHARACTERISTICS:
Opening
Time
4 hours,
Minimum
0.15 sec. Min., 5 Sec. Max
AGENCY APPROVALS:
Recognized under the Components
Program of Underwriters Laboratories and CSA Certified. Approved by
METI to 5 amperes.
AGENCY FILE NUMBERS:
UL: E71611, CSA LR 29862.
INTERRUPTING RATINGS:
100 amperes at 350 VAC, 50 amperes
at 125 VDC and 450 amperes at 60VDC
% of Ampere
Rating
100%
200%
Reference Dimensions
(Inches):
LF
350V
Recommended
Pad Layout:
4.03
(.159")
5.91
(.233")
8.81
(.347")
447 Mounting
Holes:
1.27
(.050") Dia
10.11
(.398")
PAT
1.44
(.057")
3.81
(.150")
A6
04
ENVIRONMENTAL SPECIFICATIONS:
Operating Temperature:
–40°C to +125°C.
PHYSICAL SPECIFICATIONS:
Materials:
Body: Plastic Body
Terminations: Tin-Lead (95/5) plated Zn, Ni barrier
10.92
(.430")
1.52
(.060")
Soldering Parameters:
Reflow Solder — 235°C, 5 seconds maximum.
No-clean process recommended.
Wave Solder — Not recommended.
Non-plated terminal surfaces may not meet
MIL-STD-202, Method 208.
PACKAGING SPECIFICATIONS:
24mm Tape and Reel per EIA-RS481
(Equivalent to IEC 286, part 3); 800 fuses per reel,
add packaging suffix, ZR.
Shelf Life: Up to 1 year in Factory sealed packaging.
(.295")
7.49
Average Time Current Curves
1000
ORDERING INFORMATION:
Catalog
Number
0446
002.
0446
003.
0446
004.
0446
005.
0446
07.5
0446
010.
Ampere
Rating
(A)
2
3
4
5
7.5
10
Voltage
Rating
(VAC)
350
350
350
350
350
350
Nominal
Cold
Resistance(Ω)
0.0560
0.0340
0.0240
0.0180
0.0110
0.0073
Nominal
Melting I
2
t
(A
2
sec)
2.8
9.4
17
25
68
93
100
TIME IN SECONDS
10
EBF Fuse
Fast-Acting Type 447 Series
•
Through-hole version of the 446 series.
®
®
1
ELECTRICAL CHARACTERISTICS:
Same as 446 Series.
Dimensions:
Contact Littelfuse for specifications.
Soldering Parameters:
Contact Littelfuse for soldering parameters.
Inside terminal face of each lead is non-plated zinc. Non-plated zinc
terminal faces may not meet MIL-STD-202, method 208. To ensure that
the fuse is acceptable for the application, appropriate application testing
should be performed.
0.1
Packaging Specifications:
Bulk Pack (4,000 pieces per pack)
0.01
0.1
1
10
100
CURRENT IN AMPERES
1000
2A
3A
4A
5A
7 1/2A
10A
w w w. l i t t e l f u s e . c o m
602
8.76
(.345")
1.50 (.059") MAX
3.2
5.59 (.126")
(.220")
3.2 (.126")
0.81
(.032")
7
(.032")
0.81
277
