0695060.PXPS Overview

FUSE MCASE+ 32VDC SLOTTED 60A

0695060.PXPS Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	Littelfuse
Reach Compliance Code	compliant
ECCN code	EAR99
body width	6.2 mm
body height	17.5 mm
Body length or diameter	10.7 mm
Circuit protection type	ELECTRIC FUSE
Maximum operating temperature	125 °C
Minimum operating temperature	-40 °C
physical size	10.7mm x 6.2mm x 17.5mm
Rated breaking capacity	1000 A
Rated current	60 A
Rated voltage	32 V
Terminal shape	END CAP

Preview

Download Datasheet

View All

Cartridge Fuses

MCASE+™ Cartridge Fuses Rated 32V

The Unslotted MCASE+™ Fuse is a cartridge style fuse up to 40A with female terminals

for 2.8 mm male terminals. The Slotted MCASE+™ Fuse is available in amperages up to

60A and can mate with larger male terminals (e.g., 6.3mm) or even mount directly to onto a

busbar. It has a miniaturized footprint for optimal usage of space. It is a time delayed fuse and

can handle inrush currents.

Specifications

MCASE+™ Cartridge Fuses

Voltage Rating:

Interrupting Ratings:

Operating Temperature Range:

Housing Material:

Cover Material:

Fuse Insertion Force:

Extraction Force:

Conforms to:

32 VDC

1000A @ 32 VDC

-40˚C to +125˚C

PPA-GF33

PA66

50N (11.2lbf) Typical

4N Min. (0.9 lb). | 24.5N Max. (5.5 lb)

SAE 2741 and ISO 8820-4 in reference to electrical, mechanical

and environmental performance requirements

Ordering Information

Part Number

0695xxx

.

PXPS

Slotted

0695xxx

.

PXP

Unslotted

Package Size

2000

Time-Current Characteristics

% of Rating

110

135

200

350

600

Opening Time Min / Max

100hrs / –

60s / 1800s

2s / 60s

0.2s / 7s

0.04s / 1s

Cold Resistance

(mΩ)

5.1

3.4

2.5

1.8

1

5.1

3.4

2.5

1.8

1.1

0.8

0.6

Ratings

Part Number

0695015.

PXP

0695020.

PXP

0695025.

PXP

Type

Unslotted

Slotted

Current Rating*

Housing

(A)

Material Color

15

20

25

30

40

15

20

25

30

40

50

60

Max. Voltage

Drop (mV)

125

120

125

120

I

2

t

(A

2

s)

310

750

1300

970

1550

310

750

1300

970

1550

4000

8500

Time-Current Characteristic Curves

MCASE FUSE TIME‐CURRENT CHARACTERISTIC CURVES

15A

20A

25A

30A

40A

50A

60A

0695030.

PXP

0695040.

PXP

0695015.

PXPS

0695020.

PXPS

0695025.

PXPS

0695030.

PXPS

0695040.

PXPS

1000

100

0695050.

PXPS

0695060.

PXPS

10

TIME IN SECONDS

Temperature Rerating Curve

Rerating

Factor

110 %

* The performance of the male terminal is critical to ensuring the fuse will function as

designed. The current-carrying capability of the mating terminal must be verified to

ensure proper system operation.

1

105 %

100 %

0.1

95 %

90 %

0.01

10

100

CURRENT IN AMPERES

1000

10000

85 %

-50

-40

-30

-20

-10

0

10

20

30

40

50

60

70

80

90

100

110

120

130

Temperature [

o

C]

Littelfuse products are not designed for, and shall not be used for, any purpose (including, without limitation, automotive, military, aerospace, medical, life-saving, life-sustaining or nuclear facility applications, devices intended for

surgical implant into the body, or any other application in which the failure or lack of desired operation of the product may result in personal injury, death, or property damage) other than those expressly set forth in applicable Littelfuse

product documentation. Warranties granted by Littelfuse shall be deemed void for products used for any purpose not expressly set forth in applicable Littelfuse documentation. Littelfuse shall not be liable for any claims or damages

arising out of products used in applications not expressly intended by Littelfuse as set forth in applicable Littelfuse documentation. The sale and use of Littelfuse products is subject to Littelfuse Terms and Conditions of Sale, unless

otherwise agreed by Littelfuse.
