Fuseholders
For Low Voltage 3AG or SFE Fuse Applications
RoHS
Pb
Twist-Lock
In-Line Type
155 100U Series
SPECIFICATIONS:
Electrical:
Intended for use at 32 volts or less with fuses rated up to 20
amperes when the proper spring is installed for fuse size.
Molded Parts:
Black Thermoplastic (UL 94V2).
Body halves have a .14" diameter hole for insulated wire.
Ambient Temperature:
– 40°C to +75°C.
Contact Rivet:
Brass. Tin finish. Designed to accommodate #14 AWG
stranded wire.
Assembled:
Includes fuse listed and 19" loop of #14 AWG red vinyl insulat-
ed wire.
Unassembled:
For assembly to #14 AWG wire.
155 100A Series
55.63
(2.19")
15.24 (.60")
OPTIONS:
150
215 is similar to
155
120A except no fuse is supplied. It is intended for
use with 3AG fuses rated up to 20 amperes.
UNIVERSAL IN-LINE FUSEHOLDER 155
100:
Supplied with 8" loop of #14 AWG red vinyl insulated wire and two springs in
different lengths to accommodate SFE sized fuses.
ORDERING INFORMATION:
Unassembled
For Fuse Size
1
/
4
" x
5
/
8
"
1
/
4
" x
3
/
4
"
1
/
4
" x
7
/
8
"
1
/
4
" x
7
/
8
"
1
/
4
" x 1
1
/
16
"
1
/
4
" x 1
1
/
4
"
Assembled
Catalog Number
155
104A
155
106A
155
17.5A
155
109A
155
114A
155
120A
Fuse Installed
SFE 4
SFE 6
SFE 7
1
/
2
SFE 9
SFE 14
SFE 20
Catalog Number
155
104U
155
106U
155
17.5U
155
109U
155
114U
* Please refer to Fuseology section for information on proper fuseholder de-rating.
155
120U
RoHS
Pb
Heavy-Duty Bayonet Knob
In-Line Type
155 000U Series
SPECIFICATIONS:
Electrical:
Intended for use at 32 volts or less with fuses rated up to 20
amperes when the proper spring is installed for full size.
Molded Parts:
Body and knob are Black Thermoset (UL 94V0). Both
body and knob have a .20" diameter hole for insulated wire.
Knob:
Bayonet-lock type metal insert.
Ambient Temperature:
– 40°C to +125°C.
Contact Rivet:
Brass. Tin plated. Designed to accommodate #14 AWG
stranded wire.
Assembled:
Includes fuse listed and 19" loop of #14 AWG red vinyl
insulated wire.
Unassembled:
For assembly to #14 AWG wire.
155 000A Series
52.83
(2.08")
17.53 (.69")
OPTIONS:
150
079 is similar to
155
020A except no fuse is supplied. It is intended
for use with 3AG fuses rated up to 20 amperes.
ORDERING INFORMATION:
Assembled
Catalog Number
Fuse Installed
155
004A
SFE 4
155
006A
SFE 6
155
07.5A
SFE 7
1
/
2
155
009A
SFE 9
155
014A
SFE 14
155
020A
SFE 20
Unassembled
Catalog Number For Fuse Size
1
UNIVERSAL IN-LINE FUSEHOLDER 150
145:
/
4
" x
5
/
8
"
155
004U
1
Supplied with 15" loop of #14 AWG red vinyl insulated wire and three
155
006U
/
4
" x
3
/
4
"
1
155
07.5U
/
4
" x
7
/
8
"
springs in different lengths to accommodate SFE sized fuses.
1
155
009U
/
4
" x
7
/
8
"
Fuseholders with other wire sizes or lengths available on special order.
1
155
014U
/
4
" x 1
1
/
16
"
* Please refer to Fuseology section for information on proper fuseholder de-rating.
1
155
020U
/
4
" x 1
1
/
4
"
RoHS
Pb
2AG or 5 x 20mm Inline Fuseholders
SPECIFICATIONS:
Electrical:
This fuseholder, part number 150274, is intended for use with
2AG and 5 x 20mm fuses. Maximum current ratings are 5 amperes at 32V for
the 2AG size fuses and 10 amperes at 32V for the 5 x 20mm size fuses.
Body:
Black Thermoplastic.
Terminals:
Brass.
Wire:
16 Awg size; nominal o.d. 0.104"; color red.
Lead Pull Test:
Will withstand 10 lb. pull.
Ambient Temperature:
– 40°C to +80°C.
WIRE LENGTH: 13"
+
0.5"
ORDERING INFORMATION:
Catalog Number:
150
274
* Please refer to Fuseology section for information on proper fuseholder de-rating.
478
10.67 (.42") DIA.
46.74
(1.84")
w w w. l i t t e l f u s e . c o m
