Faster.
Easier.
Better.
XM and XS Series — Accessories
Enclosures and Racks
Vertical Lacing/PDU Mounting Panel
Vertical Manager — Box Style
With door.
Vertical Manager — Finger Style
With door.
XVMP
Panel Width
01
02
3.5"
7"
XVM
Frame Height
42
45
48
42RU
45RU
48RU
01
Frame Height
42
45
48
42RU
45RU
48RU
XVM
Color
01
02
Black
CO White
02
Frame Height
42
45
48
42RU
45RU
48RU
Color
01
02
Black
CO White
Color
01
02
Black
CO White
Description
Belden Part Number
Other Accessories
Ring Kits
Cable Management Ring Plastic (Qty = 5) 3" x 1.5" Reversible
Cable Management Ring Kit (Qty = 5) 6.5" Wide x 3" Deep
Cable Management Ring Kit (Qty = 5) 2.5" Wide x 3" Deep
Fiber Slack Management Spools 6" deep (includes 2 spools)
Fiber Slack Management Spools 2" deep for lacing panels (includes 2 spools)
Quick Mount Base (Qty=10) includes Fastener, for 1/4" Holes
Velcro Cable Ties, 25 per Roll, 8"L
Velcro Cable Ties, 25 per Roll, 12"L
Vertical Ground Bars
Vertical Ground Bar, Insulated, 42RU
Vertical Ground Bar, Insulated, 45RU
Vertical Ground Bar, Insulated, 48RU
XMR01
XMR02
XMR03
BHSP020
BHSP030
XTCM01
AX100783
AX100784
XVGB0142
XVGB0145
XVGB0148
Vertical Managers:
Lacing/PDU Panel
Box Style
Finger Style
Zero U — Vertical Patch Panel and Connectivity
Features
• Attach to mounting rails
• 24" wide enclosure can accept up to four x 7
positions vertical patch panels
• 30" wide enclosure can accept up to four x 14
positions vertical patch panels
• Vertical patch panels are fully compatible with
Belden copper and fiber connectivity (FX UHD,
FX Ultra Frames and Cassettes)
Description
Belden Part Number
Zero U — Vertical Patch Panel and Connectivity
Vertical Patch Panel (7 positions), Compatible with 24" and 30" Wide XS Enclosures
Vertical Patch Panel (14 positions), Compatible with 30" Wide XS Enclosures
FXUHD KeyConnect Frame Blank
FXUHD KeyConnect Frame 6‐Port, Black (Empty)
FXUHD KeyConnect Frame 8‐Port, Black (Empty)
10GX KeyConnect Couplers for Vertical Mount Patch Panel, 8‐Port, Black
CAT6+ KeyConnect Couplers for Vertical Mount Patch Panel, 8‐Port, Black
XZUK01
XZUK02
FFZH00BB
FFZH06KC
FFZH08KC
AX105366
AX105367
Belden Zero U - Vertical patch panel allows for optimal use
of mounting space into XS Series enclosures by providing
high-density connectivity options along the equipment
mounting rails.
www.belden.com
1.800.BELDEN.1
(800.235.3361)
21
