Input current at nominal input line = 1.45A (Output Power = 60W)
*Models available with -1 option (positive logic)
1
Total output power not to exceed 60 Watts
WPA60
REV A 5/2003
SPECIFICATIONS, ALL MODELS
Specifications are at T
A
= +25°C, Airflow = 300LFM (1.5m/s) at nominal input voltage unless otherwise specified.
PARAMETER
INPUT
Voltage Range
Reflected Ripple Current
INPUT CONTROL
Temperature Shutdown
Temperature Hysteresis
Quiescent Standby Current
Undervoltage Lockout
Undervoltage Shutdown
CONDITIONS
WPA60R48D315
MIN
36
TYP
48
MAX
75
675
UNITS
VDC
mApk-pk
INPUT
PCB
Vin = 48VDC
120
5
8
32.5
2
10
°C
°C
mA
V
V
SPECIFICATIONS
Specifications are at T
A
= +25°C, Airflow = 300LFM (1.5m/s) at nominal input voltage unless otherwise specified.
PARAMETER
ISOLATION
Rated Voltage
Resistance
Capacitance
Leakage Current
OUTPUT
Rated Power
Voltage Setpoint Accuracy
Temperature Coefficient
Output Voltage
(Over all conditions of I/P voltage
load & temperature)
Ripple & Noise
(NOTE 1)
Output Adjust Range
Trim Up
Trim Down
Short Circuit and
Overcurrent Protection
Max Capacitive Load
Overvoltage Protection
GENERAL
Switching Frequency
MTTF per ML-HDBK-217
Ground Benign
Package Weight
TEMPERATURE
Operation/Specification
Storage
Shutdown Temperature
CONDITIONS
MIN
2000
TYP
MAX
UNITS
VDC
240 VAC
10
1000
90
MΩ
pF
µArms
60
±1.5
±0.005
V1
v2
BW = 5Hz to 20MHz
2
8
90
10
10
120
10,000
15
W
%
%/°C
% of Nom
% of Nom
mVp-p
%
%
%
µF
%
GENERAL
350
Circuit Stress Method
TA = +25° Unmodified Database
1,000,000
30
KHz
Hr
g
PCB Temperature
PCBTemperature
PCB Temperature
-40
-55
+120
+100
+125
°C
°C
°C
NOTE 1:
Measured at 20 MHz bandwidth across a 6µf multi layer ceramic capacitor located approximately 1” from output terminals.
Product: www.cdpoweronline.com
WPA60
REV A 5/2003
2
PERFORMANCE CURVES
Rev B of the WPA60 Datasheet will include extensive performance curves and graphs.
Product: www.cdpoweronline.com
WPA60
REV A 5/2003
3
MECHANICAL
PIN CONNECTIONS
#
1
2
3
4
5
6
7
Function
+Vin
On/Off
-Vin
+Vout1
RTN (-Vout1 and -Vout2)
Trim
+Vout2
BOTTOM VIEW
(PIN SIDE UP)
NOTES:
All dimensions are in inches
(millimeters).
All through hole pins are Ø
0.040"[1.02] with Ø 0.078" [1.98]
shoulder
Pin placement tolerance: +.010
Pin material: Brass
Pin Finish: Tin/Lead over Nickel
Converter weight: [30g]
Max height 12.5mm
SIDE VIEW
ORDERING INFORMATION
To Find Model Number
WPA60R48D
yz
-
Device Family
60 Watt, Dual Output,
Quarter Brick, 48VDC Input Range
Model Number
Selected from Product Selection Chart (above)
y = 15 = 1.5V, 18 = 1.8V, 22 = 2.2V, 25 = 2.5V,
33 = 3.3V, 05 - 5.0V,
z = 10 = 1.0V, 12 = 1.2V, 15 = 1.5V, 18 - 1.8V
25 = 2.5V, 33 = 3.3V
Remote On/Off Logic
Positive Logic - No Number
Negative Logic - 1
Model Numbers
WPA60R48D1510
WPA60R48D1812
WPA60R48D2215
WPA60R48D2518
WPA60R48D3312
WPA60R48D3318
WPA60R48D3325
WPA60R48D0515
WPA60R48D0533
WPA60R48D1510-1
WPA60R48D1812-1
WPA60R48D2215-1
WPA60R48D2518-1
WPA60R48D3312-1
WPA60R48D3318-1
WPA60R48D3325-1
WPA60R48D0515-1
WPA60R48D0533-1
Part Numbers
6064965
6064957
6064956
6064955
6064953
6064952
6064951
6064966
6064954
6064993
6064992
6064991
6064990
6064989
6064988
6064987
6064994
6064986
Power Electronics Division, Americas
3400 E Britannia Drive, Tucson, Arizona 85706
Tel: 800.547.2537 Fax: 520.295.4197
C&D Technologies, EMEA/Asia/Pacific
Milton Keynes MK14 5BU UK
Tel: +44 (0)1908 615232 Fax: +44 (0)1908 617545
Any data, prices, descriptions or specifications presented herein are subject to revision by C&D Technologies, Inc. without notice. While such information is believed to
be accurate as indicated herein, C&D Technologies, Inc. makes no warranty and hereby disclaims all warranties, express or implied, with regard to the accuracy or
completeness of such information. Further, because the product(s) featured herein may be used under conditions beyond its control, C&D Technologies, Inc. hereby
disclaims all warranties, either express or implied, concerning the fitness or suitability of such product(s) for any particular use or in any specific application or arising
from any course of dealing or usage of trade. The user is solely responsible for determining the suitability of the product(s) featured herein for user’s intended purpose
and in user’s specific application. C&D Technologies, Inc. does not warrant or recommend that any of its products be used in any life support or aviation or aerospace
