8T49N283C-998NLGI8

Description
IC TRANSLATOR UNIV FREQ 56VFQFN
Categorysemiconductor    Analog mixed-signal IC
File Size308KB，23 Pages
ManufacturerIDT (Integrated Device Technology, Inc.)
Websitehttp://www.idt.com/
Environmental Compliance
Download Datasheet Parametric Compare View All

8T49N283C-998NLGI8 Online Shopping

Suppliers Part Number Price MOQ In stock
8T49N283C-998NLGI8 - - View Buy Now

8T49N283C-998NLGI8 Overview

IC TRANSLATOR UNIV FREQ 56VFQFN

8T49N283C-998NLGI8 Parametric

Parameter NameAttribute value
PLLWith bypass
entercrystal
outputLVCMOS，LVPECL
Number of circuits1
Ratio - Input:Output1：8
Differential - Input:OutputNo/Yes
Frequency - maximum1GHz
Frequency divider/multiplieryes/no
Voltage - Power2.375 V ~ 3.465 V
Operating temperature-40°C ~ 85°C
Installation typesurface mount
Package/casing56-VFQFN Exposed Pad
Supplier device packaging56-VFQFN（8x8）

Preview

Download Datasheet
8T49N105
Code
(ddd)
-000
-001
-002
-006
-007
-999
Mode
CONFIG
0
1
0
1
0
1
0
1
0
1
0
1
Input Frequency (MHz)
CLK
LoBW
LoBW
LoBW
LoBW
LoBW
LoBW
25
19.44
25
25
61.44
61.44
125
125
76.92307692
100
25
19.44
XTAL_IN
40
40
40
40
40
40
40
40
40
40
40
40
Manual
Manual
Manual
Manual
Manual
Manual
Pin
Pin
Pin
Pin
Pin
Pin
Switchover Type
Switchover Mode
Output Style / Power-up State
P = LVPECL, D = LVDS
Q
P/on
D/off
D/on
D/off
D/on
D/off
P/on
D/off
D/on
D/off
P/off
D/off
Output Frequency
(MHz)
Q
125
622.08
125
125
61.44
61.44
100
100
76.92307692
100
125
622.08
NOTE: Please contact IDT (see last page) if a different configuration is desired.
1/16/2017 Product Ordering Guide
Page 1
©2017 Integrated Device Technology, Inc.

8T49N283C-998NLGI8 Related Products

8T49N283C-998NLGI8 8T49N281C-998NLGI 8T49N222B-123NLGI 8T49N282C-998NLGI 8T49N283C-999NLGI8 8T49N222B-109NLGI 8T49N283C-998NLGI 8T49N283C-999NLGI
Description IC TRANSLATOR UNIV FREQ 56VFQFN IC TRANSLATOR UNIV FREQ 56VFQFN IC TRANSLATOR UNIV FREQ 48VFQFN IC TRANSLATOR UNIV FREQ 72VFQFN IC TRANSLATOR UNIV FREQ 56VFQFN IC TRANSLATOR UNIV FREQ 48VFQFN IC TRANSLATOR UNIV FREQ 56VFQFN IC TRANSLATOR UNIV FREQ 56VFQFN
PLL With bypass With bypass With bypass With bypass With bypass With bypass With bypass With bypass
enter crystal crystal HCSL, LVDS, LVHSTL, LVPECL, crystal crystal crystal crystal crystal crystal
output LVCMOS，LVPECL LVCMOS，LVPECL LVDS LVPECL LVCMOS，LVPECL LVDS LVCMOS，LVPECL LVCMOS，LVPECL
Number of circuits 1 1 1 1 1 1 1 1
Ratio - Input:Output 1：8 1：8 3：2 1：8 1：8 1：2 1：8 1：8
Differential - Input:Output No/Yes No/Yes Yes Yes No/Yes No/Yes No/Yes No/Yes No/Yes
Frequency - maximum 1GHz - 156.25MHz 1GHz 1GHz 156.25MHz 1GHz 1GHz
Frequency divider/multiplier yes/no yes/no yes/no yes/no yes/no yes/no yes/no yes/no
Voltage - Power 2.375 V ~ 3.465 V 2.375 V ~ 3.465 V 2.375 V ~ 3.465 V 2.375 V ~ 3.465 V 2.375 V ~ 3.465 V 2.375 V ~ 3.465 V 2.375 V ~ 3.465 V 2.375 V ~ 3.465 V
Operating temperature -40°C ~ 85°C -40°C ~ 85°C -40°C ~ 85°C -40°C ~ 85°C -40°C ~ 85°C -40°C ~ 85°C -40°C ~ 85°C -40°C ~ 85°C
Installation type surface mount surface mount surface mount surface mount surface mount surface mount surface mount surface mount
Package/casing 56-VFQFN Exposed Pad 56-VFQFN Exposed Pad 48-VFQFN Exposed Pad 72-VFQFN Exposed Pad 56-VFQFN Exposed Pad 48-VFQFN Exposed Pad 56-VFQFN Exposed Pad 56-VFQFN Exposed Pad
Supplier device packaging 56-VFQFN（8x8） 56-VFQFN（8x8） 48-VQFN（7x7） 72-VFQFPN（10x10） 56-VFQFN（8x8） 48-VQFN（7x7） 56-VFQFN（8x8） 56-VFQFN（8x8）
