INTERCONNECTS
SERIES 310, 350, 410, 450 • .100” GRID (.018” DIA. PINS),
SMT GULL WING HEADERS & SOCKETS • SINGLE AND DOUBLE ROW STRIPS
Left Hand
Footprint
•
Headers (350 & 450) use MM #3404 pins. See
page 212 for details
.100
Number of Pins
X .100"
.018 DIA.
•
Sockets (310 & 410) use MM #1005 receptacles
Right Hand
Footprint
.110
.085
.142
and accept pin diameters from .015”-.025”.
See page 166 for details
.189
.200
.175
P.C.B.
.100
.180
.045
•
Contact is rated at 3 amps
•
Coplanarity .005” (single row max. 10 pins;
double row max. 20 pins). For higher pin
counts, contact Technical Support
suitable for all soldering operations
Coplanarity .005”. For pin counts >10 positions, consult
Technical Support.
FIG. 1
.200
.100
Number of Pins
X .100" / 2
.090
•
Insulators are high temperature thermoplastic,
ORDERING INFORMATION
.045
.110
.100
.018
DIA.
.142
FIG. 1L
FIG. 1R
FIG. 2
Single Row Header, Left Hand Footprint, Odd or Even # of pins
350 XX 1_ _ 00 106000
Specify number of pins
02-64
.189
.280
Footprint
.265
P.C.B.
.100
Single Row Header, Right Hand Footprint, Even # of pins
350 XX 1_ _ 00 107000
Specify number of pins
02-64
Coplanarity .005”. For pin counts >20 positions, consult
Technical Support.
FIG. 2
Left Hand
Footprint
.100
Number of Pins
X .100"
Double Row Header, Even # of pins
450 XX 2_ _ 00 106000
Specify number of pins
04-72
90
200
µ”
Sn/Pb
SPECIFY PLATING CODE XX=
Right Hand
Footprint
.095
10
10
µ”
Au
40
200
µ”
Sn
.146
.095
.110
.220
Pin Plating
.183
P.C.B.
.100
.200
.045
FIG. 3L
FIG. 3R
FIG. 4
RoHS - 2
Single Row Socket, Left Hand Footprint, Odd or Even # of pins
310 XX 1_ _ 41 105000
Specify number of pins
02-64
.200
Coplanarity .005”. For pin counts >10 positions, consult
Technical Support.
FIG. 3
.200
.100
Number of Pins
X .100" / 2
.045
.095
.146
.110
.220
.300
.288
P.C.B.
.100
.100
Single Row Socket, Right Hand Footprint, Even # of pins
310 XX 1_ _ 41 107000
Specify number of pins
02-64
.100
Specify number of pins
XX=Plating Code
See Below
91
10
µ”
Au
04-72
For
Electrical, Mechanical
& Enviromental Data,
See page 264
Footprint
2011/65/EU
Coplanarity .005”. For pin counts >20 positions, consult
Technical Support.
FIG. 4
SPECIFY PLATING CODE XX=
Sleeve (Pin)
Contact (Clip)
93
30
µ”
Au
41
200
µ”
Sn
10
µ”
Au
43
200
µ”
Sn
30
µ”
Au
200
µ”
Sn/Pb 200
µ”
Sn/Pb
Mill-Max Mfg. Corp. • 190 Pine Hollow Road, P.O. Box 300, Oyster Bay, NY 11771 • 516-922-6000 • Fax: 516-922-9253 • www.mill-max.com
PAGE 51 | INTERCONNECTS
Double Row Socket, Even # of pins
410 XX 2_ _ 41 105000
