MAX7316ATE+: DescriptionIC I/O EXPANDER I2C 16B 16TQFN; CategoryThe embedded processor and controller Microcontrollers and processors; File Size254KB，24 Pages; ManufacturerMaxim; Websitehttps://www.maximintegrated.com/en.html; Environmental Compliance

Download Datasheet Parametric Compare View All

MAX7316ATE+ Overview

IC I/O EXPANDER I2C 16B 16TQFN

MAX7316ATE+ Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	Maxim
Parts packaging code	QFN
package instruction	QCCN,
Contacts	16
Reach Compliance Code	compliant
ECCN code	EAR99
Factory Lead Time	1 week
JESD-30 code	R-XQCC-N16
JESD-609 code	e3
length	4.89 mm
Humidity sensitivity level	1
Number of I/O lines	8
Number of ports	1
Number of terminals	16
Maximum operating temperature	125 °C
Minimum operating temperature	-40 °C
Package body material	UNSPECIFIED
encapsulated code	QCCN
Package shape	RECTANGULAR
Package form	CHIP CARRIER
Peak Reflow Temperature (Celsius)	260
Certification status	Not Qualified
Maximum seat height	1.73 mm
Maximum supply voltage	3.6 V
Minimum supply voltage	2 V
Nominal supply voltage	3.3 V
surface mount	YES
technology	BICMOS
Temperature level	AUTOMOTIVE
Terminal surface	Matte Tin (Sn)
Terminal form	NO LEAD
Terminal pitch	0.635 mm
Terminal location	QUAD
Maximum time at peak reflow temperature	NOT SPECIFIED
width	3.9 mm
uPs/uCs/peripheral integrated circuit type	PARALLEL IO PORT, GENERAL PURPOSE
Base Number Matches	1

Preview

Download Datasheet

View All

19-3055; Rev 3; 1/05

10-Port I/O Expander with LED Intensity

Control, Interrupt, and Hot-Insertion Protection

General Description

The MAX7316 I

C/SMBus™-compatible serial interfaced

peripheral provides microprocessors with eight additional

I/O ports plus one output-only port and one input-only

port. Each I/O port can be individually configured as

either an open-drain current-sinking output rated to 50mA

at 5.5V or as a logic input with transition detection. The

output-only port can also be assigned as an interrupt out-

put for transition detection. The outputs are capable of

driving LEDs, or can provide logic outputs with external

resistive pullup up to 5.5V.

Eight-bit PWM current control is available for all nine out-

put ports. Four bits are global control and apply to all LED

outputs to provide coarse adjustment of current from fully

off to fully on in 14 intensity steps. Additionally each out-

put then has individual 4-bit control, which further divides

the globally set current into 16 more steps. Alternatively,

the current control can be configured as a single 8-bit

control that sets all outputs at once.

Each output has independent blink timing with two blink

phases. LEDs can be individually set to be on or off dur-

ing either blink phase or to ignore the blink control. The

blink period is controlled by an external clock input (up to

1kHz) on BLINK or by a register. The BLINK input can

also be used as a logic control to turn the LEDs on and

off, or as a general-purpose input.

The MAX7316 supports hot insertion. All port pins, the

INT

output, SDA, SCL,

RST,

BLINK, and the slave

address input ADO remain high impedance in power-

down (V+ = 0V) with up to 6V asserted upon them.

The MAX7316 is controlled through a 2-wire serial inter-

face, and can be set to one of four I

C addresses.

Features

♦

400kbps, 2-Wire Serial Interface, 5.5V Tolerant

♦

2V to 3.6V Operation

♦

Overall 8-Bit PWM LED Intensity Control

Global 16-Step Intensity Control

Plus Individual 16-Step Intensity Controls

♦

2-Phase LED Blinking

♦

High Output Current (50mA max per Port)

♦

Supports Hot Insertion

♦

Outputs are 5.5V-Rated Open Drain

♦

Inputs are Overvoltage Protected to 5.5V

♦

Transition Detection with Interrupt Output

♦

RST

Input Clears Serial Interface and Restores

Power-Up Default State

♦

Low Standby Current (1.2µA (typ), 3.3µA (max))

♦

Small 3mm x 3mm, Thin QFN Package

♦

-40°C to +125°C Temperature Range

MAX7316

Ordering Information

PIN-

TOP

PKG

PACKAGE MARK CODE

16 Thin QFN

MAX7316ATE -40°C to +125°C 3mm x 3mm AAV T1633-4

x 0.8mm

MAX7316AEE -40°C to +125°C 16 QSOP

—

PART

TEMP

RANGE

Typical Application Circuit

3.3V

Applications

LCD Backlights

LED Status Indication

Relay Drivers

Keypad Backlights

RGB LED Drivers

System I/O Ports

0.047μF

V+

SDA

MAX7316

SCL

BLINK

RST

INT/O8

AD0

μC

SDA

SCL

I/O

INT

Pin Configurations

SCL

TOP VIEW

INT/O8

GND

SDA

V+

BLINK

RST

GND

INPUT 1

INPUT 2

INPUT 3

MAX7316ATE

OUTPUT 1

SMBus is a trademark of Intel Corp.,

THIN QFN

Pin Configurations continued at end of data sheet.

________________________________________________________________

Maxim Integrated Products

AD0

For pricing, delivery, and ordering information, please contact Maxim/Dallas Direct! at

1-888-629-4642, or visit Maxim’s website at www.maxim-ic.com.
