ECS-2016MV
The ECS-2016MV is a miniature SMD HCMOS Oscillator with Multi
Volt capability of 1.6 ~ 3.6 V. The 2.0 x 1.6 x 0.85 mm ceramic
package is ideal for Low Power/Portable, Industrial and IOT.
applications.
ECS-2016MV SMD XO
Request a Sample
SMD Multi Volt Crystal Oscillator
OPERATING CONDITIONS / ELECTRICAL CHARACTERISTICS
PARAMETERS
Frequency Range
* Frequency Stability
Supply Voltage
Output Load
Output voltage Level
Rise & Fall time
Start Up Time
Phase Jitter
Duty Cycle
Standby Current
Operating Temp*
Storage Temp
CONDITIONS
MIN
ECS-2016MV
TYP
MAX
UNITS
•
•
•
•
•
2.0 x 1.6 mm Footprint
Extended Temp Range
RoHS Compliant
Wide Supply Voltage
Low Jitter
54.000
MHz
-40 ~ +85°C (CN Opt)
±25
ppm
1.6
3.6
V
CMOS
15
pF
V
OL:
10%V
dd
max./V
OH:
90%V
dd
min.V DC
10%V
dd
–
90%V
dd
6.5
ns
@90%V
dd
5
mS
12 KHz to 5 MHz
1
pS
@ ½ V
dd
45/55
%
10
µA
-40
+85
°C
-55
+125
°C
1.500
DIMENSIONS (mm)
CURRENT CONSUMPTION mA
Max
FREQ.
+1.8V
+2.5V
+3.3V
~ 19 MHz
2.5
4.5
6.0
~ 39.9 MHz
3.0
5.5
7.0
~ 50 MHz
3.5
6.5
8.0
~ 60 MHz
4.0
7.0
8.5
PAD CONNECTIONS
1
Tri-state
2
Gnd
3
Output
4
Vdd
Tri State Function
Pin 1
Output
0.7 * Vdd
Min
or
NC
Active
0.3 * Vdd
Max.
High Impedance
FREQUENCY
ABBREVIATION
250 = 25.000 MHz
See Developed
Frequencies Pg.2
Figure 1)
Top, Side, and Bottom views
Figure 2)
Suggested Land Pattern
PART NUMBERING GUIDE: Example ECS-2016MV-250-BN-TR
ECS
-
SERIES
-
* STABILITY
A= ±100 ppm
B = ±50 ppm
C= ±25 ppm
D = ±20 ppm
TEMP RANGE -
M = -20 ~ +70°C
N = -40 ~ +85°C
PACKAGING
2016MV
2.0 x 1.6 mm
Multi Volt Oscillator
-TR =
Tape
& Reel
1K/Reel
* Frequency Stability includes initial tolerance, temperature, supply voltage & load change reflow frequency shift, and aging.
Rev.2018
