This document was generated on 09/05/2018
PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
Part Number:
Status:
Overview:
Description:
Documents:
3D Model
Drawing (PDF)
Product Specification PS-64319-002-001 (PDF)
Application Specification AS-500993-002-001 (PDF)
General
Product Family
Series
Application
More Detailed Tech Information
5018203201
Active
CMC and CMX Sealed, Hybrid, Modular Connectors
CMC Wire-to-Wire Connector Plug Housing Assembly, 32 Circuits
Application Specification AS-501820-001-001 (PDF)
Application Specification AS-501820-001-JP-001
(PDF)
RoHS Certificate of Compliance (PDF)
Series image - Reference only
EU ELV
Compliant
EU RoHS
China RoHS
Compliant
REACH SVHC
Not Contained Per -
ED/30/2017 (7 July
2017)
Halogen-Free
Status
Low-Halogen
Need more information on product
environmental compliance?
Email productcompliance@molex.com
Please visit the Contact Us section for any
non-product compliance questions.
China ROHS
ELV
RoHS Phthalates
Green Image
Compliant
Not Reviewed
Overview
Product Name
UPC
Physical
Circuits (maximum)
Circuits Detail
Color - Resin
Gender
Glow-Wire Capable
Keying to Mating Part
Lock to Mating Part
Material - Resin
Net Weight
Number of Rows
Packaging Type
Panel Mount
Pitch - Mating Interface
Pitch - Termination Interface
Polarized to Mating Part
Ports
Stackable
Temperature Range - Operating
Electrical
Current - Maximum per Contact
Solder Process Data
Lead-freeProcess Capability
Material Info
Reference - Drawing Numbers
Application Specification
Product Specification
Sales Drawing
Crimp Housings
501820
Power, Wire-to-Wire
Sealed, high-density, modular connecting system for
Power Train and BodyElectronics applications in cars,
trucks, busses
CMC and CMX Sealed, Hybrid, Modular Connectors
CMC
822350236027
32
8 x 1.5mm & 24 x 0.635mm terminals
Grey
Plug
No
Yes
Yes
PBT
25356.000/mg
4
Tray
No
2.50mm, 3.50mm, 3.70mm
2.50mm, 3.50mm, 3.70mm
Yes
1
No
-40° to +100°C
12.0A
N/A
Search Parts in this Series
501820 Series
Mates With
64310-1211 , 64319-3211 , 501826-3201
Use With
501827 Crimp terminal, 501828 Crimp
Terminal
AS-500993-002-001, AS-501820-001-001,
AS-501820-001-JP-001
PS-64319-002-001
SD-501820-001
